Double Row Cylindrical Roller Thrust Bearings assembly K 89320 M

Double Row Cylindrical Roller Thrust Bearings assembly K 89320 M

The K 89320 M is a double-row cylindrical roller thrust bearing, measuring 100mm by 170mm by 13mm, built to handle heavy loads with ease. Made from chrome steel, it offers excellent durability and can withstand dynamic radial loads up to 67500 lbf.

Its two rows of rollers and machined brass cage ensure smooth operation at speeds up to 1900 RPM. The bearing performs reliably in temperatures ranging from -30°C to 110°C, making it suitable for demanding environments.

This model is interchangeable with SKF bearings, providing a versatile replacement option. Ideal for industrial machinery, gearboxes, or heavy equipment where high thrust loads are common.

Weighing 1.18kg, it’s robust yet manageable for its size. Compliant with RoHS and REACH standards, it meets safety and environmental requirements.

Get A Free Quote
    Description Features Application Q&A Featured Products Our Process

Product Parameters

  • Part Number K 89320 M
  • Size 100 mm x 170 mm x 13 mm
  • System of Measurement Metric
  • Roller Bearing Type Cylindrical
  • Bearing Type Roller
  • For Load Direction Thrust
  • Number of Rows 2
  • Bore Dia 100 mm
  • Bore Dia Tolerance +0.072mm to +0.292mm
  • Outer Dia 170 mm
  • Outer Dia Tolerance -0.58mm to -1.21mm
  • Diameter Roller 13 mm
  • Raceway Diameter (min.) Roller And Cage Thrust Assembly 109 mm
  • Raceway Diameter (max.) Roller And Cage Thrust Assembly 166 mm
  • Roller Material Chrome Steel
  • Cage Material Machined brass cage
  • Dynamic Radial Load 67500 lbf
  • Static Radial Load 308250 lbf
  • Max Speed 1900 rpm
  • Temperature Range -30° to 110 °C
  • RoHS Compliant
  • REACH Compliant
  • Weight 1.18 kg
  • Shaft Washer WS 89320
  • Housing Washer GS 89320

Features

Performance Features of K 89320 M Bearing

K 89320 M Bearing is built with a double-row cylindrical roller design, ideal for handling heavy thrust loads.
Its chrome steel rollers and machined brass cage ensure durability and smooth operation under pressure.

The bearing’s dynamic radial load capacity reaches 67,500 lbf, making it suitable for demanding industrial applications.
With a maximum speed of 1,900 rpm, it balances performance and reliability.

K 89320 M Bearing operates efficiently in temperatures ranging from -30° to 110°C.
Its precise dimensions and tolerances ensure compatibility and ease of installation.

The machined brass cage in K 89320 M Bearing reduces friction and extends service life.
This design also minimises maintenance needs, saving time and costs.

K 89320 M Bearing is interchangeable with SKF models, offering flexibility in replacements.
Its robust construction ensures long-term performance in various industrial environments.

Application

Industrial Uses of K 89320 M Bearing
K 89320 M Bearing is commonly used in heavy machinery, such as hydraulic presses and large gearboxes, where its double-row design handles significant thrust loads. The machined brass cage ensures smooth operation even under high stress.

Where Is K 89320 M Bearing Used?
In automotive applications, K 89320 M Bearing supports components like heavy-duty transmissions, providing reliable performance under constant axial forces. Its metric sizing makes it a versatile choice for various vehicle designs.

Built for Heavy-Duty Use: K 89320 M Bearing
For industrial automation, K 89320 M Bearing excels in robotic arms and conveyor systems, where precision and durability are key. The chrome steel rollers enhance its lifespan in demanding environments.

Automotive vs Aerospace: Applications of K 89320 M Bearing
While K 89320 M Bearing is popular in automotive transmissions, it also finds use in aerospace landing gear systems. Its high static radial load capacity makes it suitable for critical applications.

Key Fields for K 89320 M Bearing
In wind turbines, K 89320 M Bearing handles the axial loads generated by rotor blades, ensuring stable energy production. The temperature range allows it to perform reliably in varying weather conditions.
