Double Row Cylindrical Roller Thrust Bearings assembly K 89318 M

Double Row Cylindrical Roller Thrust Bearings assembly K 89318 M

The K 89318 M is a double-row cylindrical roller thrust bearing measuring 90mm by 155mm by 12mm, built from tough chrome steel for heavy-duty use. It handles radial loads up to 59625 lbf and spins smoothly at speeds up to 2000 RPM.

Its machined brass cage ensures durability, while the double-row design provides extra stability under high thrust loads. The bearing operates well in temperatures from -30°C to 110°C.

This model is interchangeable with SKF bearings, making it a practical choice for replacements. Ideal for industrial machinery like gearboxes or presses where heavy radial and thrust loads are common.

Weighing 0.97kg, it’s robust yet manageable for its size. Compliant with RoHS and REACH standards for safe and reliable performance.

Get A Free Quote
    Description Features Application Q&A Featured Products Our Process

Product Parameters

  • Part Number K 89318 M
  • Size 90 mm x 155 mm x 12 mm
  • System of Measurement Metric
  • Roller Bearing Type Cylindrical
  • Bearing Type Roller
  • For Load Direction Thrust
  • Number of Rows 2
  • Bore Dia 90 mm
  • Bore Dia Tolerance +0.072mm to +0.292mm
  • Outer Dia 155 mm
  • Outer Dia Tolerance -0.52mm to -1.15mm
  • Diameter Roller 12 mm
  • Raceway Diameter (min.) Roller And Cage Thrust Assembly 98 mm
  • Raceway Diameter (max.) Roller And Cage Thrust Assembly 151 mm
  • Roller Material Chrome Steel
  • Cage Material Machined brass cage
  • Dynamic Radial Load 59625 lbf
  • Static Radial Load 261000 lbf
  • Max Speed 2000 rpm
  • Temperature Range -30° to 110 °C
  • RoHS Compliant
  • REACH Compliant
  • Weight 0.97 kg
  • Shaft Washer WS 89318
  • Housing Washer GS 89318

Features

Why Choose K 89318 M Bearing for Precision Tasks?

K 89318 M Bearing features a double-row cylindrical roller design, offering high precision in thrust applications.
Its chrome steel rollers and machined brass cage ensure smooth operation under heavy loads.

With a dynamic radial load capacity of 59,625 lbf, K 89318 M Bearing handles demanding conditions effortlessly.
The bearing maintains performance within a temperature range of -30° to 110°C, suitable for various environments.

K 89318 M Bearing’s design reduces friction, enhancing efficiency and extending service life.
Its interchangeable compatibility with SKF makes it a versatile choice for many applications.

Application

Industrial Uses of K 89318 M Bearing
K 89318 M Bearing is commonly used in heavy machinery, such as hydraulic presses and industrial gearboxes, where its double-row design handles significant thrust loads. The machined brass cage ensures smooth operation even under high stress.

In automotive applications, K 89318 M Bearing supports components like differential systems and transmissions, providing reliable performance under demanding conditions. Its metric sizing makes it a versatile choice for various vehicle models.

For automation systems, K 89318 M Bearing’s cylindrical rollers offer precision in robotic arms and assembly lines. The chrome steel construction enhances durability, making it suitable for continuous operation.

What Makes K 89318 M Bearing a Preferred Choice?
K 89318 M Bearing excels in high-load scenarios, such as construction equipment, where its static radial load capacity ensures stability. The brass cage reduces friction, extending the bearing’s lifespan.

In wind turbines, K 89318 M Bearing’s ability to handle dynamic radial loads makes it ideal for rotor shafts. Its temperature tolerance also ensures reliable performance in varying weather conditions.

For marine applications, K 89318 M Bearing’s corrosion-resistant materials suit propeller shafts and steering systems. The precise tolerances guarantee smooth operation in harsh environments.

Built for Heavy-Duty Use: K 89318 M Bearing
K 89318 M Bearing is a go-to solution for mining equipment, where its robust design withstands extreme loads. The chrome steel rollers provide excellent wear resistance.

In agricultural machinery, K 89318 M Bearing supports PTO shafts and harvesters, ensuring efficient power transmission. Its high-speed capability makes it suitable for demanding tasks.

For railway systems, K 89318 M Bearing’s durability and load capacity make it ideal for axle boxes. The brass cage minimizes maintenance needs, reducing downtime.

Light-Duty vs Heavy-Duty: Best Uses for K 89318 M Bearing
In light-duty applications like conveyor systems, K 89318 M Bearing offers reliable performance with minimal maintenance. Its precision design ensures smooth operation.

For heavy-duty industrial presses, K 89318 M Bearing’s high static load capacity provides stability under extreme pressure. The brass cage enhances longevity in tough conditions.

In packaging machinery, K 89318 M Bearing’s versatility shines, handling both light and moderate loads efficiently. Its metric dimensions ensure compatibility with various equipment types.
