Double Row Cylindrical Roller Thrust Bearings 89412 TN

Double Row Cylindrical Roller Thrust Bearings 89412 TN

The 89412 TN is a double-row cylindrical roller thrust bearing measuring 60mm by 130mm by 42mm, crafted from sturdy chrome steel for durability. It handles heavy thrust loads up to 69750 lbf and operates smoothly at speeds up to 2400 RPM.

Its two-row design provides extra stability, while the glass fibre reinforced PA66 cage ensures quiet and efficient performance. The bearing works reliably in temperatures ranging from -30°C to 110°C.

This model is interchangeable with SKF bearings, making it a practical choice for replacements. Ideal for heavy-duty applications like industrial gearboxes or large machinery where high thrust loads are expected.

Weighing 2.82kg, it’s built to last while maintaining precision. Compliant with RoHS and REACH standards for safe and eco-friendly use.

Get A Free Quote
    Description Features Application Q&A Featured Products Our Process

Product Parameters

  • Part Number 89412 TN
  • Size 60 mm x 130 mm x 42 mm
  • Brand TFL
  • Interchangeable brand SKF
  • System of Measurement Metric
  • Roller Bearing Type Cylindrical
  • Bearing Type Roller
  • For Load Direction Thrust
  • Number of Rows 2
  • Bore Dia 60 mm
  • Bore Dia Tolerance -0.015mm to 0
  • Outer Dia 130 mm
  • Outer Dia Tolerance -0.025mm to 0
  • Width 42 mm
  • Height Tolerance -0.30mm to +0.02mm
  • Outside Diameter Shaft Washer 130 mm
  • Bore Diameter Housing Washer 62 mm
  • Height Shaft Washer 14 mm
  • Chamfer Dimension Housing Washer r1,2 (min.) 1.5 mm
  • Washer Material Chrome Steel
  • Roller Material Chrome Steel
  • Cage Material Glass fibre reinforced PA66 cage
  • Dynamic Radial Load 69750 lbf
  • Static Radial Load 265500 lbf
  • Max Speed 2400 rpm
  • Temperature Range -30° to 110 °C
  • RoHS Compliant
  • REACH Compliant
  • Weight 2.82 kg
  • Roller And Cage Thrust Assembly K 89412 TN
  • Shaft Washer WS 89412
  • Housing Washer GS 89412
Double Row Cylindrical Roller Thrust Bearings 89412 TN dimension drawing
Download DWG Download PDF

Features

Performance Features of 89412 TN Bearing

89412 TN Bearing features a double-row cylindrical roller design, ideal for handling high thrust loads.
Its chrome steel construction ensures durability and resistance to wear in demanding applications.

The glass fibre reinforced PA66 cage maintains roller alignment, enhancing performance and longevity.
With a dynamic radial load capacity of 69,750 lbf, it excels in heavy-duty industrial settings.

89412 TN Bearing operates smoothly within a temperature range of -30° to 110°C.
Its precision tolerances and robust materials ensure reliable performance at speeds up to 2,400 rpm.

Application

Industrial Uses of 89412 TN Bearing
89412 TN Bearing is commonly used in heavy machinery, such as hydraulic presses and large gearboxes, where its double-row design handles significant thrust loads. The chrome steel construction ensures durability even in demanding industrial environments.

Where Is 89412 TN Bearing Used?
In automotive applications, 89412 TN Bearing supports components like transmission systems and differential units, providing reliable performance under high stress. Its metric sizing makes it a versatile choice for various vehicle models.

Built for Heavy-Duty Use: 89412 TN Bearing
For automation and robotics, 89412 TN Bearing offers precise movement in robotic arms and assembly lines. The glass fibre reinforced PA66 cage enhances its performance in high-speed operations.

Light-Duty vs Heavy-Duty: Best Uses for 89412 TN Bearing
In consumer electronics, 89412 TN Bearing can be found in high-performance printers and industrial fans, where its robust design ensures long-lasting operation. The temperature range of -30° to 110°C makes it suitable for diverse environments.

Essential Roles of 89412 TN Bearing
Medical equipment like MRI machines benefit from 89412 TN Bearing’s reliability and smooth operation. The stainless steel components ensure minimal wear, even in continuous-use scenarios.
