Double Row Angular Contact Ball Bearings (General) 3313 A-2Z

Brand: TFL Bearing Interchangeable: SKF 3313 A-2Z 65 mm × 140 mm × 58.7 mm Metric Shielded
Part number: 3313 A-2Z
Double Row Angular Contact Ball Bearings (General) 3313 A-2Z
In Stock
Price on request
Send your part number and quantity for a quote
Get a Quote WhatsApp
  • ISO 9001 quality system
  • RoHS & REACH compliant
  • Pre-shipment inspection
  • Lead time confirmed with your quote
Dimensions
Bore Dia65 mm
Bore Dia Tolerance-0.012mm to 0
Outer Dia140 mm
Outer Dia Tolerance-0.015mm to 0
Width58.7 mm
Width Tolerance-0.05mm to 0
Chamfer Dimension2.1 mm
Performance
Dynamic Radial Load32,850 lbf
Static Radial Load24,750 lbf
Max Speed4,500 rpm
Temperature Range-30° to 110 °C
Characteristics
System of MeasurementMetric
Bearing TypeBall
For Load DirectionAngular Contact
ConstructionDouble Row
Seal TypeShielded
Distance Pressure Point (a)84 mm
LubricationLubricated
Tolerance ClassP6 (ABEC-3)
Weight4.1 kg
Material
Ring MaterialChrome Steel
Ball MaterialChrome Steel
Cage MaterialStainless Steel
Compliance
ROHSCompliant
REACHCompliant
Dimension drawing · click to enlarge

Description

The 3313 A-2Z is a double-row angular contact ball bearing with a 65mm bore and 140mm outer diameter, crafted from sturdy chrome steel. It handles radial loads up to 32850 lbf and operates smoothly at speeds up to 4500 RPM.

Its shielded design keeps dirt out while the stainless steel cage ensures durability. The bearing is pre-lubricated for easy use and performs well in temperatures from -30°C to 110°C.

This model is interchangeable with SKF bearings, making it a reliable replacement option. Ideal for applications like pumps or gearboxes where angular contact and radial loads are common.

Weighing 4.1kg, it’s robust yet manageable for its size. Compliant with RoHS and REACH standards, it’s a safe choice for various industrial uses. The P6 tolerance class ensures precise performance.

Features

Performance Features of 3313 A-2Z Bearing

3313 A-2Z Bearing is built with chrome steel rings and balls, offering strong resistance to radial loads.
Its dynamic radial load capacity reaches 32850 lbf, ensuring reliable performance in demanding conditions.

The double-row design of 3313 A-2Z Bearing provides enhanced stability and load distribution.
Shielded seals protect against contaminants, extending the bearing’s service life.

3313 A-2Z Bearing operates smoothly at speeds up to 4,500 rpm, balancing efficiency and durability.
Its P6 tolerance class ensures precision and consistent performance in angular contact applications.

With a temperature range of -30° to 110°C, 3313 A-2Z Bearing performs well in various environments.
The stainless steel cage maintains ball alignment, reducing wear and improving longevity.

Application

Common Applications of 3313 A-2Z Bearing
3313 A-2Z Bearing is widely used in industrial machinery, especially in applications needing high radial and axial load capacity, such as gearboxes and pumps. Its double-row design ensures stability, making it suitable for heavy-duty operations.

In automotive systems, 3313 A-2Z Bearing is often found in wheel hubs and transmissions, where its angular contact feature helps manage combined loads effectively. The shielded seals also protect against contaminants, extending service life.

For automation equipment, 3313 A-2Z Bearing provides reliable performance in robotic arms and CNC machines. The chrome steel construction and P6 tolerance class ensure precision in high-speed applications.

Medical imaging devices benefit from 3313 A-2Z Bearing’s smooth operation and low noise. The stainless steel cage adds durability, making it ideal for sensitive environments where reliability is key.

In household appliances like washing machines, 3313 A-2Z Bearing handles moderate loads with ease. Its lubricated design reduces maintenance needs, offering long-lasting performance for everyday use.
