CRBF Crossed Roller Bearings CRBFV11528ATUU

CRBF Crossed Roller Bearings CRBFV11528ATUU

The CRBFV11528ATUU is a crossed roller bearing measuring 115mm in bore diameter, 240mm in outer diameter, and 28mm in width, crafted from sturdy steel for durability.

It handles combined loads with ease, offering a basic load rating of 80.3 kN, and operates smoothly in temperatures ranging from 0°C to 110°C.

The double-seal design keeps contaminants out while retaining lubrication, and the mounting holes (12-M8 inner, 12-φ9 outer) simplify installation.

Ideal for precision applications like robotics or rotary tables, this ABEC5-rated bearing is also available in higher precision grades (ABEC7/9) for specialised needs.

Weighing 6.8kg, it’s a robust choice for industrial machinery requiring reliable rotation under load. Compliant with RoHS and REACH standards.

Get A Free Quote
    Description Features Application Q&A Featured Products Our Process

Product Parameters

  • Part Number CRBFV11528ATUU
  • Brand TFL
  • Interchangeable brand IKO
  • Size 115 mm x 240 mm x 28 mm
  • System of Measurement Metric
  • Bearing Type Roller
  • Roller Bearing Type Crossed
  • For Load Direction Combined
  • Construction Single Row
  • Seal Type Double Seal
  • Bore Dia 115 mm
  • Outer Dia 240 mm
  • Width 28 mm
  • Inner Ring PCD1 139 mm
  • Outer Ring PCD2 217 mm
  • Holes With Holes
  • Inner Ring Mounting Hole 12-M8 through
  • Outer Ring Mounting Hole 12-φ9 through φ14 counter bore depth 13.5
  • Ring Material Steel
  • Roller Material Steel
  • Basic Load Rating C 80.3 kN
  • Basic Load Rating Co 135 kN
  • Lubrication Required
  • Shaft Mount Type Press Fit
  • Temperature Range 0 -230 °F
  • ABEC Rating ABEC5(Available in ABEC7/9)
  • RoHS Compliant
  • REACH Compliant
  • Weight 6.8 Kg

Features

How Does CRBFV11528ATUU Bearing Handle Combined Loads?

CRBFV11528ATUU Bearing is designed with a single-row crossed roller construction, ideal for handling combined loads efficiently.
Its steel rings and rollers provide a basic load rating of 80.3 kN, ensuring reliable performance under stress.

The double-seal design protects CRBFV11528ATUU Bearing from dust and contaminants, extending its service life.
With a temperature range of 0-230°F, it performs well in various operating conditions.

CRBFV11528ATUU Bearing features mounting holes for easy installation, saving time and effort.
Its ABEC5 rating ensures precision, making it suitable for high-accuracy applications.

Application

Industrial Uses of CRBFV11528ATUU Bearing
CRBFV11528ATUU Bearing is commonly used in machine tools, where its crossed roller design provides excellent rigidity and precision for rotary tables and indexing heads. The double seal helps keep contaminants out, ensuring long service life in demanding workshop conditions.

What Makes CRBFV11528ATUU Bearing a Preferred Choice?
In robotics, CRBFV11528ATUU Bearing offers smooth motion control for articulated arms, thanks to its high load capacity and compact profile. The press-fit mounting simplifies installation in tight spaces commonly found in automated systems.

Built for Heavy-Duty Use: CRBFV11528ATUU Bearing
CRBFV11528ATUU Bearing handles combined loads effectively in construction equipment like excavator slewing rings. Its steel construction withstands shock loads while the ABEC5 rating ensures reliable performance under continuous operation.

Medical vs Industrial: Where CRBFV11528ATUU Bearing Excels
CRBFV11528ATUU Bearing suits medical imaging devices requiring precise rotation, such as CT scanner gantries. In industrial settings, it’s equally at home in packaging machinery where consistent movement is key.

Automotive vs Aerospace: Applications of CRBFV11528ATUU Bearing
CRBFV11528ATUU Bearing supports steering systems in heavy vehicles due to its robust design. Aerospace applications include actuator mechanisms where its temperature range and reliability meet stringent safety standards.
