24126 CC/W513 Double Row Spherical Roller Bearing

24126 CC/W513 Double Row Spherical Roller Bearing

The 24126 CC/W513 is a double-row spherical roller bearing with a 130mm bore and 210mm outer diameter, crafted from sturdy chrome steel. It manages combined loads up to 157141 lbf and operates smoothly at speeds up to 2400 RPM.

Its spherical roller design allows for slight misalignment, while the steel cage ensures durability. The open construction requires regular lubrication for optimal performance.

This bearing suits high-load applications like heavy machinery or industrial gearboxes, with a temperature range of -30°C to 200°C. It’s interchangeable with SKF models for easy replacement.

Weighing 10.5kg, it’s built for robust performance. Compliant with RoHS and REACH standards, it’s a reliable choice for demanding environments.

Get A Free Quote
    Description Features Application Q&A Featured Products Our Process

Product Parameters

  • Part Number 24126 CC/W513
  • Brand TFL
  • Interchangeable SKF
  • Size 130 x 210 x 80 mm
  • Bore Dia 130 mm
  • Bore Dia Tolerance -0.025mm to 0
  • Outer Dia 210 mm
  • Outer Dia Tolerance -0.030mm to 0
  • Width 80 mm
  • Width Tolerance -0.08mm to 0
  • Shoulder Dia Of Inner Ring 146 mm
  • Shoulder/Recess Dia Of Outer Ring 180 mm
  • Width Of Lubrication Groove 6 mm
  • Diameter Of Lubrication Hole 3 mm
  • Chamfer Dimension min.2 mm
  • System of Measurement Metric
  • Radial run-out Standard
  • Bearing Type Roller
  • Roller Bearing Type Spherical
  • Bore Type Cylindrical
  • For Load Direction Combined
  • Construction Double Row
  • Seal Type Open
  • Ring Material Chrome Steel
  • Roller Material Chrome Steel
  • Cage Material Steel
  • Dynamic Radial Load 157141 lbf
  • Static Radial Load 224809 lbf
  • Max Speed 2400 rpm
  • Lubrication Required
  • Temperature Range -30° to 200 °C
  • Radial Clearance CN
  • RoHs Compliant
  • REACH Compliant
  • Weight 10.5 kg
  • Price （US$） US$484.84

Features

Performance Features of 24126 CC/W513 Bearing

24126 CC/W513 Bearing is built with chrome steel rings and rollers, offering strong resistance to combined loads.
Its dynamic radial load capacity reaches 157141 lbf, ensuring reliable performance in heavy-duty applications.

The double-row spherical roller design allows for slight misalignment, reducing stress on the bearing.
This feature enhances durability and extends the service life even under challenging conditions.

24126 CC/W513 Bearing operates efficiently within a temperature range of -30° to 200°C.
Its open design simplifies lubrication, ensuring smooth performance at speeds up to 2400 rpm.

The steel cage maintains roller alignment, minimising wear and improving overall stability.
With a weight of 10.5 kg, it balances strength and practicality for industrial use.

Application

Industrial Uses of 24126 CC/W513 Bearing
The 24126 CC/W513 Bearing is commonly used in heavy machinery like crushers and vibrating screens, where its double-row design handles both radial and axial loads efficiently. Its chrome steel construction ensures durability in demanding industrial environments.

Where Is 24126 CC/W513 Bearing Used?
You’ll often find 24126 CC/W513 Bearing in mining equipment, where its high load capacity and spherical roller design accommodate misalignment. The open seal type allows for easy lubrication, extending its service life.

Built for Heavy-Duty Use: 24126 CC/W513 Bearing
24126 CC/W513 Bearing excels in construction equipment like cranes and excavators, thanks to its robust steel cage and high dynamic load rating. Its wide temperature range makes it suitable for both hot and cold working conditions.

Automotive vs Aerospace: Applications of 24126 CC/W513 Bearing
In automotive applications, 24126 CC/W513 Bearing supports heavy axles and gearboxes, while in aerospace, its precision and reliability are valued in landing gear systems. The metric sizing ensures compatibility across various industries.

Practical Applications of 24126 CC/W513 Bearing
For wind turbines, 24126 CC/W513 Bearing’s ability to handle misalignment and heavy loads makes it a reliable choice. The steel cage and chrome steel rollers provide long-lasting performance in high-speed rotations.
