24060 CCK30/C3 W33 Double Row Spherical Roller Bearing

24060 CCK30/C3 W33 Double Row Spherical Roller Bearing

The 24060 CCK30/C3 W33 is a double-row spherical roller bearing with a 300mm tapered bore and 460mm outer diameter, crafted from sturdy chrome steel. It manages combined loads up to 614852 lbf and operates smoothly at speeds up to 1200 RPM.

Its open design and C3 radial clearance allow for easy lubrication, while the steel cage ensures durability. The bearing performs reliably in temperatures ranging from -30°C to 200°C.

This model is interchangeable with SKF bearings, making it a practical choice for replacements. Suitable for heavy-duty applications like industrial gearboxes or mining equipment where high radial loads are common.

Weighing 97kg, it’s built for robust performance. Compliant with RoHS and REACH standards for safe and sustainable use.

Get A Free Quote
    Description Features Application Q&A Featured Products Our Process

Product Parameters

  • Part Number 24060 CCK30/C3 W33
  • Brand TFL
  • Interchangeable SKF
  • Size 300 x 460 x 160 mm
  • Bore Dia 300 mm
  • Bore Dia Tolerance +0.035mm to 0
  • Outer Dia 460 mm
  • Outer Dia Tolerance -0.045mm to 0
  • Width 160 mm
  • Width Tolerance -0.1mm to 0
  • Shoulder Dia Of Inner Ring 344 mm
  • Shoulder/Recess Dia Of Outer Ring 400 mm
  • Width Of Lubrication Groove 13.9 mm
  • Diameter Of Lubrication Hole 7.5 mm
  • Chamfer Dimension min.4 mm
  • System of Measurement Metric
  • Radial run-out Standard
  • Bearing Type Roller
  • Roller Bearing Type Spherical
  • Bore Type Taper 1:30
  • For Load Direction Combined
  • Construction Double Row
  • Seal Type Open
  • Ring Material Chrome Steel
  • Roller Material Chrome Steel
  • Cage Material Steel
  • Dynamic Radial Load 614852 lbf
  • Static Radial Load 101164 lbf
  • Max Speed 1200 rpm
  • Lubrication Required
  • Temperature Range -30° to 200 °C
  • Radial Clearance C3
  • RoHs Compliant
  • REACH Compliant
  • Weight 97 kg
  • Price （US$） US$2,983.50

Features

Performance Features of 24060 CCK30/C3 W33 Bearing

24060 CCK30/C3 W33 Bearing is built with chrome steel rings and rollers, offering robust performance under combined loads.
Its dynamic radial load capacity reaches 614852 lbf, making it suitable for heavy-duty industrial applications.

The double-row spherical roller design allows for slight misalignment, ensuring smooth operation.
With a maximum speed of 1200 rpm, it balances high load capacity and operational efficiency.

24060 CCK30/C3 W33 Bearing operates in temperatures from -30° to 200°C, adapting to various working conditions.
The C3 radial clearance provides flexibility in thermal expansion, enhancing reliability.

Maintenance is straightforward with its lubrication groove and hole design.
This reduces downtime and ensures consistent performance over time.

Application

Industrial Uses of 24060 CCK30/C3 W33 Bearing
24060 CCK30/C3 W33 Bearing is commonly used in heavy machinery like crushers and vibrating screens, where its double-row design handles high radial and axial loads. The spherical roller construction also compensates for misalignment, ensuring smooth operation in demanding environments.

In automotive applications, 24060 CCK30/C3 W33 Bearing supports large components such as truck axles and drivetrains. Its tapered bore design simplifies installation, while the chrome steel rollers provide long-lasting durability under heavy loads.

For wind turbines, 24060 CCK30/C3 W33 Bearing’s ability to withstand combined loads makes it ideal for rotor shafts. The lubrication groove and hole design ensure consistent performance even in remote or hard-to-access locations.

What Makes 24060 CCK30/C3 W33 Bearing a Preferred Choice?
24060 CCK30/C3 W33 Bearing excels in mining equipment, where its robust construction resists harsh conditions like dust and extreme temperatures. The C3 radial clearance allows for thermal expansion, preventing premature wear.

In paper mills, 24060 CCK30/C3 W33 Bearing’s high dynamic load capacity ensures reliable performance in rollers and dryers. The steel cage adds stability, reducing vibration and noise during high-speed operations.
