24060 CCK 30 W33 C2 Double Row Spherical Roller Bearing

24060 CCK 30 W33 C2 Double Row Spherical Roller Bearing

The 24060 CCK 30 W33 C2 is a double-row spherical roller bearing with a 300mm bore and 460mm outer diameter, built from sturdy chrome steel. It handles combined loads up to 614852 lbf and operates smoothly at speeds up to 1200 RPM.

Its tapered bore design ensures a secure fit, while the open structure allows for easy lubrication. The steel cage adds durability, making it suitable for heavy-duty use.

This bearing works in temperatures from -30°C to 200°C and features a C2 radial clearance for precise performance. It’s interchangeable with SKF models, ideal for replacements in industrial settings.

Weighing 97kg, it’s robust for large machinery like crushers or gearboxes. Compliant with RoHS and REACH standards, it’s a reliable choice for demanding applications.

Get A Free Quote
    Description Features Application Q&A Featured Products Our Process

Product Parameters

  • Part Number 24060 CCK 30 W33 C2
  • Brand TFL
  • Interchangeable SKF
  • Size 300 x 460 x 160 mm
  • Bore Dia 300 mm
  • Bore Dia Tolerance +0.052mm to 0
  • Outer Dia 460 mm
  • Outer Dia Tolerance -0.045mm to 0
  • Width 160 mm
  • Width Tolerance -0.1mm to 0
  • Shoulder Dia Of Inner Ring 344 mm
  • Shoulder/Recess Dia Of Outer Ring 400 mm
  • Width Of Lubrication Groove 13.9 mm
  • Diameter Of Lubrication Hole 7.5 mm
  • Chamfer Dimension min.4 mm
  • System of Measurement Metric
  • Radial run-out Standard
  • Bearing Type Roller
  • Roller Bearing Type Spherical
  • Bore Type Taper 1:12
  • For Load Direction Combined
  • Construction Double Row
  • Seal Type Open
  • Ring Material Chrome Steel
  • Roller Material Chrome Steel
  • Cage Material Steel
  • Dynamic Radial Load 614852 lbf
  • Static Radial Load 101164 lbf
  • Max Speed 1200 rpm
  • Lubrication Required
  • Temperature Range -30° to 200 °C
  • Radial Clearance C2
  • RoHs Compliant
  • REACH Compliant
  • Weight 97 kg
  • Price （US$） US$2,983.50

Features

Performance Features of 24060 CCK 30 W33 C2 Bearing

24060 CCK 30 W33 C2 Bearing is built with chrome steel rings and rollers, offering high resistance to combined loads.
Its dynamic radial load capacity reaches 614852 lbf, ensuring robust performance in heavy-duty applications.

The double-row spherical roller design allows for slight misalignment, maintaining smooth operation.
With a maximum speed of 1200 rpm, it balances durability and efficiency in demanding conditions.

24060 CCK 30 W33 C2 Bearing operates in temperatures from -30° to 200°C, suitable for varied environments.
The steel cage ensures proper roller alignment, reducing wear and extending service life.

Lubrication grooves and holes in 24060 CCK 30 W33 C2 Bearing facilitate easy maintenance.
Its tapered bore design simplifies installation, saving time and effort.

Application

Industrial Uses of 24060 CCK 30 W33 C2 Bearing
24060 CCK 30 W33 C2 Bearing is commonly used in heavy machinery, such as mining equipment and crushers, where its double-row design handles high radial and axial loads. The tapered bore ensures a secure fit, reducing slippage during operation.

In wind turbines, 24060 CCK 30 W33 C2 Bearing supports the main shaft, offering reliability in harsh weather conditions. Its chrome steel construction and lubrication grooves help maintain performance over long periods.

For paper mills, this bearing is ideal for rollers that require smooth rotation under heavy loads. The C2 radial clearance provides just enough play for thermal expansion without compromising stability.

Where Is 24060 CCK 30 W33 C2 Bearing Used?
You’ll often find 24060 CCK 30 W33 C2 Bearing in construction equipment like cranes and excavators, where its robust design handles uneven loads. The steel cage adds durability, even in dusty environments.

In marine applications, this bearing works well in propeller shafts due to its corrosion-resistant materials. The wide temperature range makes it suitable for both cold and hot climates.

Built for Heavy-Duty Use: 24060 CCK 30 W33 C2 Bearing
24060 CCK 30 W33 C2 Bearing is a go-to for steel mills, where rollers face extreme heat and pressure. Its dynamic load capacity ensures it won’t falter under continuous stress.

In power generation, this bearing supports turbines that convert energy efficiently. The lubrication holes make maintenance straightforward, reducing downtime.

Automotive vs Aerospace: Applications of 24060 CCK 30 W33 C2 Bearing
In large trucks, 24060 CCK 30 W33 C2 Bearing handles the heavy loads of axles and transmissions. Its metric sizing fits standard commercial vehicle designs.

For aerospace ground equipment, this bearing aids in landing gear testing rigs. The high static load rating ensures safety during critical operations.
