24060 CACK30/C2W33 Double Row Spherical Roller Bearing

24060 CACK30/C2W33 Double Row Spherical Roller Bearing

The 24060 CACK30/C2W33 is a double-row spherical roller bearing with a 300mm bore and 460mm outer diameter, built from sturdy chrome steel. It handles combined loads up to 614852 lbf and operates smoothly at speeds up to 1200 RPM.

Its brass cage enhances durability, while the open design allows easy lubrication. The bearing performs reliably in temperatures from -30°C to 200°C, making it suitable for harsh environments.

With a tapered bore (1:30) and C2 radial clearance, it offers precise alignment and reduced friction. Ideal for heavy-duty applications like industrial gearboxes or mining equipment where high radial loads are common.

Weighing 97kg, it’s a robust choice for large machinery. Compliant with RoHS and REACH standards, it’s interchangeable with SKF bearings for easy replacement.

Get A Free Quote
    Description Features Application Q&A Featured Products Our Process

Product Parameters

  • Part Number 24060 CACK30/C2W33
  • Brand TFL
  • Interchangeable SKF
  • Size 300 x 460 x 160 mm
  • Bore Dia 300 mm
  • Bore Dia Tolerance +0.035mm to 0
  • Outer Dia 460 mm
  • Outer Dia Tolerance -0.045mm to 0
  • Width 160 mm
  • Width Tolerance -0.1mm to 0
  • Shoulder Dia Of Inner Ring 344 mm
  • Shoulder/Recess Dia Of Outer Ring 400 mm
  • Width Of Lubrication Groove 13.9 mm
  • Diameter Of Lubrication Hole 7.5 mm
  • Chamfer Dimension min.4 mm
  • System of Measurement Metric
  • Radial run-out Standard
  • Bearing Type Roller
  • Roller Bearing Type Spherical
  • Bore Type Taper 1:30
  • For Load Direction Combined
  • Construction Double Row
  • Seal Type Open
  • Ring Material Chrome Steel
  • Roller Material Chrome Steel
  • Cage Material Brass
  • Dynamic Radial Load 614852 lbf
  • Static Radial Load 101164 lbf
  • Max Speed 1200 rpm
  • Lubrication Required
  • Temperature Range -30° to 200 °C
  • Radial Clearance C2
  • RoHs Compliant
  • REACH Compliant
  • Weight 97 kg
  • Price （US$） US$3,878.88

Features

Performance Features of 24060 CACK30/C2W33 Bearing

24060 CACK30/C2W33 Bearing is built with chrome steel rings and rollers, offering robust resistance to combined loads.
Its dynamic radial load capacity reaches 614852 lbf, ensuring dependable performance in heavy-duty applications.

The brass cage maintains roller alignment, reducing friction and enhancing durability.
With a maximum speed of 1200 rpm, it delivers reliable operation under demanding conditions.

24060 CACK30/C2W33 Bearing operates efficiently in temperatures ranging from -30° to 200°C.
Its tapered bore design simplifies installation, making it suitable for various industrial uses.

The C2 radial clearance ensures smooth performance, even under varying thermal conditions.
This bearing’s open design allows for easy lubrication, extending its service life.

Application

Industrial Uses of 24060 CACK30/C2W33 Bearing
24060 CACK30/C2W33 Bearing is commonly used in heavy machinery like crushers and vibrating screens, where its double-row spherical design handles misalignment and heavy radial loads. The brass cage ensures smooth operation even under high stress.

What Makes 24060 CACK30/C2W33 Bearing a Preferred Choice?
In mining equipment, 24060 CACK30/C2W33 Bearing’s tapered bore provides secure fitting on shafts, reducing slippage during intense operations. Its high dynamic load capacity makes it reliable for continuous use.

Built for Heavy-Duty Use: 24060 CACK30/C2W33 Bearing
This bearing excels in paper mill machinery, where its chrome steel construction resists wear from constant friction. The C2 radial clearance allows for thermal expansion in high-temperature environments.

Automotive vs Aerospace: Applications of 24060 CACK30/C2W33 Bearing
In large trucks, 24060 CACK30/C2W33 Bearing supports axles and gearboxes, while in wind turbines, it handles variable loads with ease. The metric sizing ensures compatibility across global industries.

Perfect Fit for Automation: 24060 CACK30/C2W33 Bearing
24060 CACK30/C2W33 Bearing is ideal for robotic arms in manufacturing, where precision and durability are key. Its open design simplifies lubrication, extending service life in demanding setups.
