23228 CC/C2W33 Double Row Spherical Roller Bearing

23228 CC/C2W33 Double Row Spherical Roller Bearing

The 23228 CC/C2W33 is a double-row spherical roller bearing with a 140mm bore and 250mm outer diameter, crafted from sturdy chrome steel. It manages combined loads up to 216266 lbf and runs smoothly at speeds up to 2400 RPM.

Its open design and steel cage ensure durability, while the spherical rollers accommodate misalignment. The bearing operates in temperatures from -30°C to 200°C, making it versatile for various conditions.

This model is interchangeable with SKF bearings, offering a reliable replacement option. Ideal for heavy machinery like gearboxes or industrial equipment where high radial loads are present.

Weighing 18.5kg, it’s robust yet manageable for its size. Compliant with RoHS and REACH standards, it’s a safe choice for demanding applications.

Get A Free Quote
    Description Features Application Q&A Featured Products Our Process

Product Parameters

  • Part Number 23228 CC/C2W33
  • Brand TFL
  • Interchangeable SKF
  • Size 140 x 250 x 88 mm
  • Bore Dia 140 mm
  • Bore Dia Tolerance -0.025mm to 0
  • Outer Dia 250 mm
  • Outer Dia Tolerance -0.030mm to 0
  • Width 88 mm
  • Width Tolerance -0.08mm to 0
  • Shoulder Dia Of Inner Ring 165 mm
  • Shoulder/Recess Dia Of Outer Ring 212 mm
  • Width Of Lubrication Groove 11.1 mm
  • Diameter Of Lubrication Hole 6 mm
  • Chamfer Dimension min.3 mm
  • System of Measurement Metric
  • Radial run-out Standard
  • Bearing Type Roller
  • Roller Bearing Type Spherical
  • Bore Type Cylindrical
  • For Load Direction Combined
  • Construction Double Row
  • Seal Type Open
  • Ring Material Chrome Steel
  • Roller Material Chrome Steel
  • Cage Material Steel
  • Dynamic Radial Load 216266 lbf
  • Static Radial Load 281011 lbf
  • Max Speed 2400 rpm
  • Lubrication Required
  • Temperature Range -30° to 200 °C
  • Radial Clearance C2
  • RoHs Compliant
  • REACH Compliant
  • Weight 18.5 kg
  • Price （US$） US$428.26

Features

Performance Features of 23228 CC/C2W33 Bearing

23228 CC/C2W33 Bearing is built with chrome steel rings and rollers, offering robust resistance to combined loads.
Its dynamic radial load capacity reaches 216266 lbf, ensuring reliable operation in heavy-duty applications.

The double-row spherical roller design allows for slight misalignment, enhancing performance in challenging conditions.
With a maximum speed of 2400 rpm, it balances durability and efficiency.

23228 CC/C2W33 Bearing operates in temperatures from -30° to 200°C, making it suitable for varied environments.
The steel cage maintains roller alignment, reducing wear and extending service life.

Lubrication grooves and holes in 23228 CC/C2W33 Bearing ensure consistent lubrication, minimising maintenance needs.
Its C2 radial clearance provides optimal performance for precision applications.

Application

Industrial Uses of 23228 CC/C2W33 Bearing
23228 CC/C2W33 Bearing is commonly used in heavy machinery like crushers and vibrating screens, where its double-row design handles high radial loads with ease. The spherical roller construction also accommodates misalignment, ensuring reliable performance in rugged conditions.

Where Is 23228 CC/C2W33 Bearing Used?
You’ll often find 23228 CC/C2W33 Bearing in mining equipment, where its robust chrome steel rollers withstand constant stress. Its C2 radial clearance makes it suitable for applications requiring precise alignment under heavy loads.

Built for Heavy-Duty Use: 23228 CC/C2W33 Bearing
23228 CC/C2W33 Bearing excels in paper mills and steel plants, thanks to its high dynamic radial load capacity. The steel cage adds durability, making it a dependable choice for continuous operation.

Automotive vs Aerospace: Applications of 23228 CC/C2W33 Bearing
In automotive applications, 23228 CC/C2W33 Bearing supports large drivetrain components, while in aerospace, it’s used in auxiliary systems requiring high load tolerance. Its temperature range up to 200°C ensures versatility across industries.

Perfect Fit for Automation: 23228 CC/C2W33 Bearing
23228 CC/C2W33 Bearing is ideal for robotic arms in manufacturing lines, where its combined load handling improves precision. The open design simplifies lubrication, reducing downtime in automated systems.
