23048 CC/C2W33 Double Row Spherical Roller Bearing

23048 CC/C2W33 Double Row Spherical Roller Bearing

The 23048 CC/C2W33 is a double-row spherical roller bearing with a 240mm bore and 360mm outer diameter, crafted from sturdy chrome steel. It handles combined loads up to 301244 lbf and operates smoothly at speeds up to 1900 RPM.

Its open design and steel cage ensure durability, while the C2 radial clearance allows for thermal expansion. The bearing includes lubrication grooves and holes for easy maintenance.

This model is interchangeable with SKF bearings, making it a reliable replacement option. Suitable for heavy-duty applications like industrial gearboxes or mining equipment.

Weighing 32.5kg, it’s built to withstand temperatures from -30°C to 200°C. Compliant with RoHS and REACH standards for safe use.

Get A Free Quote
    Description Features Application Q&A Featured Products Our Process

Product Parameters

  • Part Number 23048 CC/C2W33
  • Brand TFL
  • Interchangeable SKF
  • Size 240 x 360 x 92 mm
  • Bore Dia 240 mm
  • Bore Dia Tolerance -0.03mm to 0
  • Outer Dia 360 mm
  • Outer Dia Tolerance -0.04mm to 0
  • Width 92 mm
  • Width Tolerance -0.08mm to 0
  • Shoulder Dia Of Inner Ring 271 mm
  • Shoulder/Recess Dia Of Outer Ring 326 mm
  • Width Of Lubrication Groove 13.9 mm
  • Diameter Of Lubrication Hole 7.5 mm
  • Chamfer Dimension min.3 mm
  • System of Measurement Metric
  • Radial run-out Standard
  • Bearing Type Roller
  • Roller Bearing Type Spherical
  • Bore Type Cylindrical
  • For Load Direction Combined
  • Construction Double Row
  • Seal Type Open
  • Ring Material Chrome Steel
  • Roller Material Chrome Steel
  • Cage Material Steel
  • Dynamic Radial Load 301244 lbf
  • Static Radial Load 467603 lbf
  • Max Speed 1900 rpm
  • Lubrication Required
  • Temperature Range -30° to 200 °C
  • Radial Clearance C2
  • RoHs Compliant
  • REACH Compliant
  • Weight 32.5 kg
  • Price （US$） US$803.24

Features

Why Choose 23048 CC/C2W33 Bearing for Precision Tasks?

23048 CC/C2W33 Bearing features a double-row spherical roller design, ideal for handling combined radial and thrust loads.
Its chrome steel construction ensures durability and resistance to wear in demanding applications.

The bearing’s dynamic radial load capacity of 301244 lbf makes it suitable for heavy-duty machinery.
With a maximum speed of 1900 rpm, it delivers reliable performance under high-speed conditions.

23048 CC/C2W33 Bearing operates efficiently in temperatures ranging from -30° to 200°C.
Its C2 radial clearance provides optimal performance for precision tasks.

The lubrication groove and hole design ensure consistent lubrication, reducing maintenance needs.
This bearing is interchangeable with SKF models, offering flexibility in replacements.

Application

Industrial Uses of 23048 CC/C2W33 Bearing
23048 CC/C2W33 Bearing is commonly used in heavy machinery like crushers and vibrating screens, where its double-row design handles both radial and axial loads efficiently. The spherical roller construction helps accommodate misalignment, reducing wear in demanding environments.

Where Is 23048 CC/C2W33 Bearing Used?
You’ll often find 23048 CC/C2W33 Bearing in mining equipment, where its high dynamic load capacity ensures reliable performance under extreme conditions. The steel cage and chrome steel rollers provide durability, even in dusty or high-temperature settings.

Built for Heavy-Duty Use: 23048 CC/C2W33 Bearing
23048 CC/C2W33 Bearing excels in paper mill machinery, supporting large rollers that require smooth rotation under heavy loads. Its C2 radial clearance offers optimal performance for applications with thermal expansion concerns.

Automotive vs Aerospace: Applications of 23048 CC/C2W33 Bearing
In large vehicles like trucks or buses, 23048 CC/C2W33 Bearing supports drivetrain components, while in aerospace, it’s used in ground support equipment. The metric sizing and high load capacity make it versatile across industries.

Essential Roles of 23048 CC/C2W33 Bearing
23048 CC/C2W33 Bearing is a go-to choice for wind turbine gearboxes, where its ability to handle misalignment and heavy loads ensures long service life. The open design simplifies lubrication, crucial for maintenance in remote installations.
