23036 CC/C082W33 Double Row Spherical Roller Bearing

23036 CC/C082W33 Double Row Spherical Roller Bearing

The 23036 CC/C082W33 is a double-row spherical roller bearing with a 180mm bore and 280mm outer diameter, crafted from robust chrome steel. It manages combined loads up to 198506 lbf and operates smoothly at speeds up to 2600 RPM.

Its open design simplifies lubrication, while the steel cage ensures durability under heavy use. The bearing performs reliably in temperatures ranging from -30°C to 200°C.

This model is interchangeable with SKF bearings, making it a practical choice for replacements. Suitable for heavy-duty applications like industrial gearboxes or mining equipment where high radial loads are present.

Weighing 16.5kg, it’s built to handle demanding conditions. Compliant with RoHS and REACH standards for safe and eco-friendly use.

Get A Free Quote
    Description Features Application Q&A Featured Products Our Process

Product Parameters

  • Part Number 23036 CC/C082W33
  • Brand TFL
  • Interchangeable SKF
  • Size 180 x 280 x 74 mm
  • Bore Dia 180 mm
  • Bore Dia Tolerance -0.025mm to 0
  • Outer Dia 280 mm
  • Outer Dia Tolerance -0.035mm to 0
  • Width 74 mm
  • Width Tolerance -0.08mm to 0
  • Shoulder Dia Of Inner Ring 204 mm
  • Shoulder/Recess Dia Of Outer Ring 249 mm
  • Width Of Lubrication Groove 13.9 mm
  • Diameter Of Lubrication Hole 7.5 mm
  • Chamfer Dimension min.2.1 mm
  • System of Measurement Metric
  • Radial run-out P5
  • Bearing Type Roller
  • Roller Bearing Type Spherical
  • Bore Type Cylindrical
  • For Load Direction Combined
  • Construction Double Row
  • Seal Type Open
  • Ring Material Chrome Steel
  • Roller Material Chrome Steel
  • Cage Material Steel
  • Dynamic Radial Load 198506 lbf
  • Static Radial Load 281011 lbf
  • Max Speed 2600 rpm
  • Lubrication Required
  • Temperature Range -30° to 200 °C
  • Radial Clearance C2
  • RoHs Compliant
  • REACH Compliant
  • Weight 16.5 kg

Features

Performance Features of 23036 CC/C082W33 Bearing

23036 CC/C082W33 Bearing is built with chrome steel rings and rollers, offering high resistance to combined loads.
Its dynamic radial load capacity reaches 198506 lbf, making it suitable for heavy-duty applications.

The double-row spherical roller design ensures smooth operation even under misalignment conditions.
With a maximum speed of 2600 rpm, it delivers reliable performance in demanding environments.

23036 CC/C082W33 Bearing operates efficiently in temperatures ranging from -30° to 200 °C.
Its steel cage maintains roller alignment, reducing wear and extending service life.

The lubrication groove and hole design ensure proper lubrication, enhancing durability.
23036 CC/C082W33 Bearing’s radial clearance of C2 provides optimal performance for precision applications.

Application

Industrial Uses of 23036 CC/C082W33 Bearing
23036 CC/C082W33 Bearing is commonly used in heavy machinery like crushers and vibrating screens, where its double-row design handles combined loads effectively. The spherical roller type accommodates misalignment, ensuring reliable performance in rugged conditions.

In wind turbines, 23036 CC/C082W33 Bearing supports the main shaft, withstanding high radial loads and variable speeds. Its chrome steel construction and C2 radial clearance make it suitable for long-term operation in harsh environments.

For mining equipment, 23036 CC/C082W33 Bearing’s robust design ensures durability in conveyors and excavators. The lubrication groove and holes simplify maintenance, reducing downtime in critical applications.

What Makes 23036 CC/C082W33 Bearing a Preferred Choice?
23036 CC/C082W33 Bearing excels in paper mill machinery, where its high dynamic load capacity handles continuous operation. The steel cage provides stability, even under fluctuating temperatures.

In steel production, 23036 CC/C082W33 Bearing is ideal for rolling mills, thanks to its ability to manage heavy radial and axial forces. The metric sizing ensures compatibility with European and Asian industrial standards.

Built for Heavy-Duty Use: 23036 CC/C082W33 Bearing
23036 CC/C082W33 Bearing is a go-to for construction equipment like cranes, where its load-bearing capacity and durability are crucial. The open seal design allows for easy lubrication, extending service life.

In marine applications, 23036 CC/C082W33 Bearing performs well in propeller shafts, resisting corrosion and wear. Its temperature range suits both cold and warm operating conditions.
