23030 CC/C3W509 Double Row Spherical Roller Bearing

23030 CC/C3W509 Double Row Spherical Roller Bearing

The 23030 CC/C3W509 is a double-row spherical roller bearing with a 150mm bore and 225mm outer diameter, crafted from durable chrome steel. It handles combined loads up to 119374 lbf and operates smoothly at speeds up to 3200 RPM.

Its open design allows for easy lubrication, while the steel cage ensures reliable performance under heavy loads. The bearing works well in temperatures ranging from -30°C to 200°C.

This model is interchangeable with SKF bearings, making it a practical choice for replacements. Ideal for industrial machinery, gearboxes, or heavy equipment where robust performance is needed.

Weighing 7.65kg, it’s built to last and complies with RoHS and REACH standards for safe use. The C3 radial clearance offers flexibility in various applications.

Get A Free Quote
    Description Features Application Q&A Featured Products Our Process

Product Parameters

  • Part Number 23030 CC/C3W509
  • Brand TFL
  • Interchangeable SKF
  • Size 150 x 225 x 56 mm
  • Bore Dia 150 mm
  • Bore Dia Tolerance -0.025mm to 0
  • Outer Dia 225 mm
  • Outer Dia Tolerance -0.030mm to 0
  • Width 56 mm
  • Width Tolerance -0.08mm to 0
  • Shoulder Dia Of Inner Ring 169 mm
  • Shoulder/Recess Dia Of Outer Ring 203 mm
  • Width Of Lubrication Groove 8.3 mm
  • Diameter Of Lubrication Hole 4.5 mm
  • Chamfer Dimension min.2.1 mm
  • System of Measurement Metric
  • Radial run-out Standard
  • Bearing Type Roller
  • Roller Bearing Type Spherical
  • Bore Type Cylindrical
  • For Load Direction Combined
  • Construction Double Row
  • Seal Type Open
  • Ring Material Chrome Steel
  • Roller Material Chrome Steel
  • Cage Material Steel
  • Dynamic Radial Load 119374 lbf
  • Static Radial Load 168607 lbf
  • Max Speed 3200 rpm
  • Lubrication Required
  • Temperature Range -30° to 200 °C
  • Radial Clearance C3
  • RoHs Compliant
  • REACH Compliant
  • Weight 7.65 kg
  • Price （US$） US$103.03

Features

Why Choose 23030 CC/C3W509 Bearing for Precision Tasks?

23030 CC/C3W509 Bearing features a double-row spherical roller design, ideal for handling combined loads with precision.
Its chrome steel rings and rollers provide excellent resistance to wear, ensuring long-lasting performance.

The bearing’s C3 radial clearance allows for thermal expansion, making it suitable for high-temperature applications up to 200°C.
With a dynamic radial load capacity of 119374 lbf, it delivers reliable operation under heavy loads.

23030 CC/C3W509 Bearing’s lubrication groove and hole design ensure consistent lubrication, reducing maintenance needs.
Its robust steel cage keeps the rollers aligned, enhancing stability and efficiency.

The bearing’s wide temperature range and high-speed capability (3200 rpm) make it versatile for various industrial applications.
Its precise dimensions and tolerances ensure easy installation and optimal performance.

Application

Industrial Uses of 23030 CC/C3W509 Bearing
23030 CC/C3W509 Bearing is commonly used in heavy machinery like crushers and vibrating screens, where its double-row design handles both radial and axial loads efficiently. The spherical roller construction helps accommodate misalignment, reducing wear in demanding environments.

Where Is 23030 CC/C3W509 Bearing Used?
You’ll often find 23030 CC/C3W509 Bearing in mining equipment, where its high dynamic load capacity ensures reliable performance under extreme conditions. The C3 radial clearance also allows for thermal expansion in high-temperature operations.

Built for Heavy-Duty Use: 23030 CC/C3W509 Bearing
23030 CC/C3W509 Bearing excels in paper mill machinery, supporting heavy rolls with its robust chrome steel construction. The open design simplifies lubrication, making maintenance straightforward even in dusty environments.

Automotive vs Aerospace: Applications of 23030 CC/C3W509 Bearing
In automotive applications, 23030 CC/C3W509 Bearing is used in large truck transmissions, while in aerospace, it supports auxiliary equipment due to its high-speed capability. The steel cage ensures durability in both sectors.

Practical Applications of 23030 CC/C3W509 Bearing
23030 CC/C3W509 Bearing is a go-to choice for wind turbine gearboxes, where its combined load handling and temperature resistance are crucial. The metric sizing ensures compatibility with international designs.
