22220 CCY W33 Double Row Spherical Roller Bearing

22220 CCY W33 Double Row Spherical Roller Bearing

The 22220 CCY W33 is a double-row spherical roller bearing with a 100mm bore and 180mm outer diameter, crafted from sturdy chrome steel. It manages combined loads up to 97342 lbf and runs smoothly at speeds up to 4500 RPM.

Its brass cage enhances durability, while the open design allows for easy lubrication. The bearing operates efficiently in temperatures ranging from -30°C to 200°C.

This model is interchangeable with SKF bearings, making it a practical choice for replacements. Suitable for heavy-duty applications like industrial gearboxes or mining equipment where high radial loads are common.

Weighing 4.95kg, it offers a robust build for demanding environments. Compliant with RoHS and REACH standards for safe and reliable use.

Get A Free Quote
    Description Features Application Q&A Featured Products Our Process

Product Parameters

  • Part Number 22220 CCY W33
  • Brand TFL
  • Interchangeable SKF
  • Size 100 x 180 x 46 mm
  • Bore Dia 100 mm
  • Bore Dia Tolerance -0.02mm to 0
  • Outer Dia 180 mm
  • Outer Dia Tolerance -0.025mm to 0
  • Width 46 mm
  • Width Tolerance -0.08mm to 0
  • Shoulder Dia Of Inner Ring 118 mm
  • Shoulder/Recess Dia Of Outer Ring 159 mm
  • Width Of Lubrication Groove 8.3 mm
  • Diameter Of Lubrication Hole 4.5 mm
  • Chamfer Dimension min.2.1 mm
  • System of Measurement Metric
  • Radial run-out Standard
  • Bearing Type Roller
  • Roller Bearing Type Spherical
  • Bore Type Cylindrical
  • For Load Direction Combined
  • Construction Double Row
  • Seal Type Open
  • Ring Material Chrome Steel
  • Roller Material Chrome Steel
  • Cage Material Brass
  • Dynamic Radial Load 97342 lbf
  • Static Radial Load 110156 lbf
  • Max Speed 4500 rpm
  • Lubrication Required
  • Temperature Range -30° to 200 °C
  • Radial Clearance CN
  • RoHs Compliant
  • REACH Compliant
  • Weight 4.95 kg
  • Price （US$） 89.1

Features

Performance Features of 22220 CCY W33 Bearing

22220 CCY W33 Bearing is built with chrome steel rings and rollers, offering excellent resistance to combined loads.
Its dynamic radial load capacity reaches 97342 lbf, making it suitable for heavy-duty applications.

The brass cage ensures smooth roller movement, reducing friction and enhancing durability.
With a maximum speed of 4500 rpm, it delivers reliable performance under high-speed conditions.

22220 CCY W33 Bearing operates efficiently in temperatures ranging from -30° to 200°C.
Its double-row spherical design accommodates misalignment, ensuring consistent performance.

The lubrication groove and hole design in 22220 CCY W33 Bearing simplify maintenance.
This feature helps extend service life and reduces downtime.

Application

Industrial Uses of 22220 CCY W33 Bearing
22220 CCY W33 Bearing is commonly used in heavy machinery like crushers and vibrating screens, where its double-row design handles high radial loads with ease. The brass cage ensures smooth operation even under demanding conditions.

Where Is 22220 CCY W33 Bearing Used?
You’ll find 22220 CCY W33 Bearing in mining equipment, where its spherical roller design compensates for misalignment. Its high dynamic load capacity makes it ideal for rugged environments.

Built for Heavy-Duty Use: 22220 CCY W33 Bearing
22220 CCY W33 Bearing excels in paper mills and steel plants, thanks to its chrome steel construction. The lubrication groove design extends service life in high-temperature settings.

Automotive vs Aerospace: Applications of 22220 CCY W33 Bearing
In automotive applications, 22220 CCY W33 Bearing supports drivetrain components, while in aerospace, it’s used in auxiliary systems. Its metric sizing fits standard industrial and transport equipment.

Essential Roles of 22220 CCY W33 Bearing
22220 CCY W33 Bearing is vital in wind turbines, where it handles variable loads and misalignment. The open seal type allows for easy re-lubrication, reducing maintenance downtime.
