TS (Single Row Tapered Roller Bearings) (Metric) X32209N-Y32209

TS (Single Row Tapered Roller Bearings) (Metric) X32209N-Y32209

The TSF 15123-15250-B is a single-row tapered roller bearing with a 1.25″ bore and 2.5″ outer diameter, built from sturdy chrome steel. It handles combined loads up to 13,500 lbf and is designed for smooth operation in various conditions.

Its flanged cup design ensures secure mounting, while the open seal allows for easy lubrication. The bearing works well in temperatures from -30°C to 110°C, making it versatile for different environments.

This model is interchangeable with Timken bearings, offering a reliable replacement option. Ideal for applications like automotive axles or industrial gearboxes where combined loads are common.

Weighing just 0.5 lb, it’s lightweight yet durable. Compliant with RoHS and REACH standards, it’s a safe choice for various industries. The ABEC-1 rating ensures consistent performance for general applications.

Get A Free Quote
    Description Features Application Q&A Featured Products Our Process

Product Parameters

  • Part Number X32209N-Y32209
  • Brand TFL
  • Interchangeable Brand Timken
  • System of Measurement Metric
  • Type Bearing
  • Sizes 45 mm x 85 mm x 24.75 mm
  • Cone Part Number X32209N
  • Cup Part Number Y32209
  • Bore Dia 45 mm
  • Bore Dia Tolerance -0.012mm to 0
  • Outer Dia 85 mm
  • Outer Dia Tolerance -0.018mm to 0
  • Cone Width 23 mm
  • Cone Width Tolerance -0.1mm to 0
  • Cup Width 19 mm
  • Cup Width Tolerance -0.2mm to 0
  • Width 24.75 mm
  • Width Tolerance +0.2mm to 0
  • Cone Backface ToClear Radius 1.52 mm
  • Cup Backface ToClear Radius 1.52 mm
  • Cone Frontface Backing Diameter 51 mm
  • Cone Backface Backing Diameter 54 mm
  • Cup Frontface Backing Diameter 82.00 mm
  • Cup Backface Backing Diameter 75.95 mm
  • Cage Cone Frontface Clearance 3 mm
  • Cage Cone Backface Clearance 1.3 mm
  • Effective Center Location -4.3 mm
  • Bearing Type Roller
  • Roller Bearing Type Tapered
  • For Load Direction Combined
  • Construction Single Row
  • Seal Type Open
  • Cups Type Standard
  • Series 32209
  • Ring Material Chrome Steel
  • Roller Material Chrome Steel
  • Cage Material Steel
  • Dynamic Radial Load 23400 lbf
  • Static Radial Load 22208 lbf
  • Dynamic Radial Rating(90 Million Revolutions)(C90) 6052.5 lbf
  • Dynamic Thrust Rating(90 Million Revolutions)(Ca90) 4207.5 lbf
  • Lubrication Required
  • Temperature Range -30° to 110 °C
  • ABEC Rating ABEC-1
  • Radial Clearance Standard (Available in C3/C4/C5)
  • RoHS Compliant
  • REACH Compliant
  • Weight 1.32 lb

Features

Performance Features of 15123-15250-B Bearing

15123-15250-B Bearing is built with chrome steel rings and rollers, offering strong resistance to combined loads.
Its dynamic radial load capacity reaches 13,500 lbf, ensuring reliable performance in various applications.

The flanged cup design provides better alignment and stability during operation.
With a standard radial clearance, it balances durability and efficiency for different working conditions.

15123-15250-B Bearing operates effectively within a temperature range of -30° to 110°C.
Its tapered roller design ensures smooth performance under both radial and thrust loads.

The steel cage maintains proper roller spacing, reducing wear and extending service life.
This bearing is interchangeable with Timken models, offering flexibility in replacements.

Application

Industrial Uses of 15123-15250-B Bearing
The 15123-15250-B Bearing is commonly used in heavy machinery, such as construction equipment and agricultural gear, where its tapered roller design handles combined loads effectively. The flanged cup adds stability, making it ideal for applications with axial displacement.

In automotive systems, 15123-15250-B Bearing fits well in wheel hubs and differentials, thanks to its inch sizing and compatibility with Timken designs. Its chrome steel construction ensures durability even under high stress and frequent use.

For conveyor systems, 15123-15250-B Bearing’s open seal allows easy lubrication, reducing downtime in industrial settings. The standard radial clearance offers flexibility for various load and speed requirements.

In power transmission units, 15123-15250-B Bearing’s steel cage and tapered rollers provide reliable performance under dynamic radial and thrust loads. Its ABEC-1 rating balances precision and cost for general machinery needs.
