TS (Single Row Tapered Roller Bearings) (Metric) X30216-Y30216

TS (Single Row Tapered Roller Bearings) (Metric) X30216-Y30216

The 463-453XB is a single-row tapered roller bearing with a flange, measuring 1.875″ x 4.25″ x 1.1542″. Made from durable chrome steel, it handles combined loads up to 30500 lbf radially and 4540 lbf thrust.

Its flanged cup design keeps it securely in place, while the open seal allows for easy lubrication. The steel cage ensures smooth operation even under heavy loads.

This bearing is interchangeable with Timken models, making it a practical choice for replacements. It works well in temperatures from -30°C to 110°C, suitable for industrial machinery or automotive applications.

Weighing 2.9 lb, it’s robust yet manageable for its size. Compliant with RoHS and REACH standards, it meets safety and environmental requirements.

The standard radial clearance can be adjusted to C3, C4, or C5 for specific needs. Its ABEC-1 rating ensures reliable performance for general industrial use.

Get A Free Quote
    Description Features Application Q&A Featured Products Our Process

Product Parameters

  • Part Number X30216-Y30216
  • Brand TFL
  • Interchangeable Brand Timken
  • System of Measurement Metric
  • Type Bearing
  • Sizes 80 mm x 140 mm x 28.25 mm
  • Cone Part Number X30216
  • Cup Part Number Y30216
  • Bore Dia 80 mm
  • Bore Dia Tolerance -0.015mm to 0
  • Outer Dia 140 mm
  • Outer Dia Tolerance -0.02mm to 0
  • Cone Width 26 mm
  • Cone Width Tolerance -0.15mm to 0
  • Cup Width 22 mm
  • Cup Width Tolerance -0.2mm to 0
  • Width 28.25 mm
  • Width Tolerance +0.2mm to 0
  • Cone Backface ToClear Radius 2.54 mm
  • Cup Backface ToClear Radius 2.03 mm
  • Cone Frontface Backing Diameter 89 mm
  • Cone Backface Backing Diameter 93 mm
  • Cup Frontface Backing Diameter 133.35 mm
  • Cup Backface Backing Diameter 127.00 mm
  • Cage Cone Frontface Clearance 4.3 mm
  • Cage Cone Backface Clearance 1 mm
  • Effective Center Location 0 mm
  • Bearing Type Roller
  • Roller Bearing Type Tapered
  • For Load Direction Combined
  • Construction Single Row
  • Seal Type Open
  • Cups Type Standard
  • Series 30216
  • Ring Material Chrome Steel
  • Roller Material Chrome Steel
  • Cage Material Steel
  • Dynamic Radial Load 36900 lbf
  • Static Radial Load 42075 lbf
  • Dynamic Radial Rating(90 Million Revolutions)(C90) 9540 lbf
  • Dynamic Thrust Rating(90 Million Revolutions)(Ca90) 6862.5 lbf
  • Lubrication Required
  • Temperature Range -30° to 110 °C
  • ABEC Rating ABEC-1
  • Radial Clearance Standard (Available in C3/C4/C5)
  • RoHS Compliant
  • REACH Compliant
  • Weight 3.53 lb

Features

Performance Features of 463-453XB Bearing

463-453XB Bearing is crafted with chrome steel rings and rollers, ensuring strength and durability under combined loads.
Its dynamic radial load capacity reaches 30,500 lbf, making it suitable for heavy-duty applications.

The flanged cup design of 463-453XB Bearing provides secure mounting, reducing misalignment risks.
With a standard radial clearance, it offers reliable performance in various operating conditions.

463-453XB Bearing operates efficiently within a temperature range of -30° to 110°C.
Its steel cage maintains roller alignment, enhancing longevity and reducing wear.

The tapered roller design of 463-453XB Bearing ensures smooth operation under both radial and thrust loads.
Its ABEC-1 rating guarantees consistent precision for industrial applications.

Application

Industrial Uses of 463-453XB Bearing
The 463-453XB Bearing is commonly used in heavy machinery, such as construction equipment and agricultural gear, where its tapered roller design handles combined loads effectively. The flanged cup adds stability, making it ideal for applications with misalignment risks.

Where Is 463-453XB Bearing Used?
You’ll often find 463-453XB Bearing in automotive axles and wheel hubs, thanks to its robust chrome steel construction. Its inch sizing ensures compatibility with many North American vehicle designs.

Built for Heavy-Duty Use: 463-453XB Bearing
In conveyor systems, 463-453XB Bearing excels due to its high dynamic radial load capacity. The open seal design allows for easy lubrication, extending service life in dusty environments.

Automotive vs Aerospace: Applications of 463-453XB Bearing
While 463-453XB Bearing is popular in truck transmissions, its precision also suits aerospace landing gear components. The steel cage ensures durability under varying temperatures.

Key Fields for 463-453XB Bearing
For industrial pumps, 463-453XB Bearing offers reliable performance with its standard radial clearance. The tapered rollers distribute loads evenly, reducing wear over time.
