TS (Single Row Tapered Roller Bearings) (Metric) X30206CM-Y30206CM

TS (Single Row Tapered Roller Bearings) (Metric) X30206CM-Y30206CM

The 07087X-07210XB is a single-row tapered roller bearing with a flange, measuring 0.875″ x 2″ x 0.5614″. Made from chrome steel, it’s built to handle combined loads with a dynamic radial load capacity of 6540 lbf.

Its flanged cup design keeps it securely in place, while the open seal allows for easy lubrication. The bearing operates smoothly in temperatures from -30°C to 110°C.

This model is interchangeable with Timken bearings, making it a practical choice for replacements. Ideal for applications like wheel hubs or gearboxes where combined loads are common.

Weighing just 0.3 lb, it’s lightweight yet durable. Compliant with RoHS and REACH standards for safe use.

Get A Free Quote
    Description Features Application Q&A Featured Products Our Process

Product Parameters

  • Part Number X30206CM-Y30206CM
  • Brand TFL
  • Interchangeable Brand Timken
  • System of Measurement Metric
  • Type Bearing
  • Sizes 30 mm x 62 mm x 17.25 mm
  • Cone Part Number X30206CM
  • Cup Part Number Y30206CM
  • Bore Dia 30 mm
  • Bore Dia Tolerance -0.012mm to 0
  • Outer Dia 62 mm
  • Outer Dia Tolerance -0.016mm to 0
  • Cone Width 16 mm
  • Cone Width Tolerance -0.1mm to 0
  • Cup Width 14 mm
  • Cup Width Tolerance -0.15mm to 0
  • Width 17.25 mm
  • Width Tolerance +0.2mm to 0
  • Cone Backface ToClear Radius 1.02 mm
  • Cup Backface ToClear Radius 1.02 mm
  • Cone Frontface Backing Diameter 36.5 mm
  • Cone Backface Backing Diameter 38 mm
  • Cup Frontface Backing Diameter 58.42 mm
  • Cup Backface Backing Diameter 55.12 mm
  • Cage Cone Frontface Clearance 2.8 mm
  • Cage Cone Backface Clearance 0 mm
  • Effective Center Location -3.6 mm
  • Bearing Type Roller
  • Roller Bearing Type Tapered
  • For Load Direction Combined
  • Construction Single Row
  • Seal Type Open
  • Cups Type Standard
  • Series 30206C
  • Ring Material Chrome Steel
  • Roller Material Chrome Steel
  • Cage Material Steel
  • Dynamic Radial Load 11092 lbf
  • Static Radial Load 11655 lbf
  • Dynamic Radial Rating(90 Million Revolutions)(C90) 2880 lbf
  • Dynamic Thrust Rating(90 Million Revolutions)(Ca90) 1847.25 lbf
  • Lubrication Required
  • Temperature Range -30° to 110 °C
  • ABEC Rating ABEC-1
  • Radial Clearance Standard (Available in C3/C4/C5)
  • RoHS Compliant
  • REACH Compliant
  • Weight 0.44 lb

Features

Performance Features of 07087X-07210XB Bearing

07087X-07210XB Bearing is built with chrome steel rings and rollers, offering strong resistance to combined loads.
Its dynamic radial load capacity reaches 6540 lbf, ensuring reliable performance in various applications.

The tapered roller design of 07087X-07210XB Bearing provides effective load distribution, reducing wear.
With a flanged cup, it ensures secure mounting and alignment in assemblies.

07087X-07210XB Bearing operates efficiently within a temperature range of -30° to 110°C.
Its standard radial clearance makes it versatile for different operational needs.

The steel cage in 07087X-07210XB Bearing maintains roller alignment, enhancing durability.
This design also contributes to smoother operation under heavy loads.

Application

Industrial Uses of 07087X-07210XB Bearing
07087X-07210XB Bearing is commonly used in heavy machinery like construction equipment and agricultural gear, where its tapered roller design handles combined loads efficiently. The flanged cup adds stability, making it ideal for applications with frequent alignment adjustments.

In automotive settings, 07087X-07210XB Bearing fits well in wheel hubs and drivetrains, thanks to its inch sizing and compatibility with Timken designs. Its chrome steel construction ensures durability even under constant stress.

For industrial conveyor systems, 07087X-07210XB Bearing’s open design simplifies lubrication, while the steel cage maintains roller alignment during high-load operations. The ABEC-1 rating balances precision and cost-effectiveness for general machinery.

In power transmission units, 07087X-07210XB Bearing’s effective center location helps manage radial and thrust loads smoothly. The standard radial clearance option makes it adaptable to various operational temperatures.
