TS (Single Row Tapered Roller Bearings) (Metric) 33217

TS (Single Row Tapered Roller Bearings) (Metric) 33217

The 368A-362-B is a single row tapered roller bearing with a 2″ bore and 3.5433″ outer diameter, made from sturdy chrome steel. It handles combined loads up to 22900 lbf radially and 3250 lbf thrust, making it versatile for various applications.

Its flanged cup design ensures secure positioning, while the open seal allows for easy lubrication. The steel cage provides durability, and the bearing operates smoothly in temperatures from -30°C to 110°C.

This model is interchangeable with Timken bearings, offering a reliable replacement option. Ideal for heavy-duty machinery or automotive systems where combined loads are common.

Weighing 1.2 lb, it’s robust yet manageable for its size, and complies with RoHS and REACH standards for safe use.

Get A Free Quote
    Description Features Application Q&A Featured Products Our Process

Product Parameters

  • Part Number 33217
  • Brand TFL
  • Interchangeable Brand Timken
  • System of Measurement Metric
  • Type Bearing
  • Sizes 85 mm x 150 mm x 49 mm
  • Cone Part Number X33217
  • Cup Part Number Y33217
  • Bore Dia 85 mm
  • Bore Dia Tolerance -0.02mm to 0
  • Outer Dia 150 mm
  • Outer Dia Tolerance -0.02mm to 0
  • Cone Width 49 mm
  • Cone Width Tolerance -0.15mm to 0
  • Cup Width 37 mm
  • Cup Width Tolerance -0.2mm to 0
  • Width 49 mm
  • Width Tolerance +0.2mm to -0.2mm
  • Cone Backface ToClear Radius 2.54 mm
  • Cup Backface ToClear Radius 2.03 mm
  • Cone Frontface Backing Diameter 94 mm
  • Cone Backface Backing Diameter 103 mm
  • Cup Frontface Backing Diameter 145.03 mm
  • Cup Backface Backing Diameter 134.11 mm
  • Cage Cone Frontface Clearance 4.1 mm
  • Cage Cone Backface Clearance 4.8 mm
  • Effective Center Location -11.7 mm
  • Bearing Type Roller
  • Roller Bearing Type Tapered
  • For Load Direction Combined
  • Construction Single Row
  • Seal Type Open
  • Cups Type Standard
  • Series 33217
  • Ring Material Chrome Steel
  • Roller Material Chrome Steel
  • Cage Material Steel
  • Dynamic Radial Load 93600 lbf
  • Static Radial Load 108675 lbf
  • Dynamic Radial Rating(90 Million Revolutions)(C90) 24300 lbf
  • Dynamic Thrust Rating(90 Million Revolutions)(Ca90) 17392.5 lbf
  • Lubrication Required
  • Temperature Range -30° to 110 °C
  • ABEC Rating ABEC-1
  • Radial Clearance Standard (Available in C3/C4/C5)
  • RoHS Compliant
  • REACH Compliant
  • Weight 7.94 lb

Features

Performance Features of 368A-362-B Bearing

368A-362-B Bearing is built with chrome steel rings and rollers, offering strong resistance to combined loads.
Its dynamic radial load capacity reaches 22,900 lbf, ensuring reliable performance in demanding conditions.

The flanged cup design provides better alignment and stability during operation.
With a temperature range of -30° to 110°C, it performs well in various environments.

The tapered roller design reduces friction and extends service life.
Standard radial clearance options make it versatile for different applications.

Application

Industrial Uses of 368A-362-B Bearing
368A-362-B Bearing is commonly used in heavy machinery, such as construction equipment and agricultural gear, where its tapered roller design handles combined loads effectively. The flanged cup adds stability, making it suitable for applications requiring precise alignment.

In automotive systems, 368A-362-B Bearing supports wheel hubs and differentials, thanks to its robust chrome steel construction. Its inch sizing ensures compatibility with many North American vehicle models, offering reliable performance under varying loads.

For industrial conveyors, 368A-362-B Bearing’s open design allows for easy lubrication, extending service life in high-demand environments. The steel cage enhances durability, making it a practical choice for continuous operation.

Where Is 368A-362-B Bearing Used?
You’ll often find 368A-362-B Bearing in mining equipment, where its ability to handle radial and thrust loads is crucial. The flange design helps maintain alignment in rugged conditions, reducing wear over time.

In manufacturing plants, 368A-362-B Bearing is a go-to for gearboxes and pulley systems. Its standard radial clearance and ABEC-1 rating provide consistent performance without needing frequent adjustments.

Built for Heavy-Duty Use: 368A-362-B Bearing
368A-362-B Bearing excels in forestry machinery, where its tapered rollers manage uneven loads and shocks. The chrome steel components resist wear, even in dusty or wet environments.

For power transmission systems, 368A-362-B Bearing’s dynamic load capacity ensures smooth operation. Its temperature range of -30° to 110°C makes it versatile for both indoor and outdoor applications.

Automotive vs Aerospace: Applications of 368A-362-B Bearing
In automotive settings, 368A-362-B Bearing is ideal for drivetrains, offering durability under high stress. Its inch measurements simplify replacements in older vehicle models.

For aerospace ground equipment, 368A-362-B Bearing provides reliable performance in landing gear systems. The steel cage and chrome steel rollers ensure longevity, even with frequent use.
