TS (Single Row Tapered Roller Bearings) (Metric) 33205

TS (Single Row Tapered Roller Bearings) (Metric) 33205

The TSF 09074-09195AB is a single-row tapered roller bearing with a 0.75″ bore and 1.938″ outer diameter, made from sturdy chrome steel. It handles combined loads up to 9630 lbf and works well in temperatures from -30°C to 110°C.

Its flanged cup design keeps it securely in place, while the open seal allows for easy lubrication. The steel cage ensures smooth operation even under heavy loads.

This bearing is interchangeable with Timken models, making it a practical choice for replacements. Ideal for applications like wheel hubs or gearboxes where combined loads are common.

Weighing just 0.3 lb, it’s lightweight yet durable. Compliant with RoHS and REACH standards for safe use.

Get A Free Quote
    Description Features Application Q&A Featured Products Our Process

Product Parameters

  • Part Number 33205
  • Brand TFL
  • Interchangeable Brand Timken
  • System of Measurement Metric
  • Type Bearing
  • Sizes 25 mm x 52 mm x 22 mm
  • Cone Part Number X33205
  • Cup Part Number Y33205
  • Bore Dia 25 mm
  • Bore Dia Tolerance -0.012mm to 0
  • Outer Dia 52 mm
  • Outer Dia Tolerance -0.016mm to 0
  • Cone Width 22 mm
  • Cone Width Tolerance -0.1mm to 0
  • Cup Width 18 mm
  • Cup Width Tolerance -0.15mm to 0
  • Width 22 mm
  • Width Tolerance +0.2mm to 0
  • Cone Backface ToClear Radius 1.02 mm
  • Cup Backface ToClear Radius 1.02 mm
  • Cone Frontface Backing Diameter 30.5 mm
  • Cone Backface Backing Diameter 34 mm
  • Cup Frontface Backing Diameter 49.53 mm
  • Cup Backface Backing Diameter 44.45 mm
  • Cage Cone Frontface Clearance 2.5 mm
  • Cage Cone Backface Clearance 0.3 mm
  • Effective Center Location -7.6 mm
  • Bearing Type Roller
  • Roller Bearing Type Tapered
  • For Load Direction Combined
  • Construction Single Row
  • Seal Type Open
  • Cups Type Standard
  • Series 33205
  • Ring Material Chrome Steel
  • Roller Material Chrome Steel
  • Cage Material Steel
  • Dynamic Radial Load 14715 lbf
  • Static Radial Load 14310 lbf
  • Dynamic Radial Rating(90 Million Revolutions)(C90) 3802.5 lbf
  • Dynamic Thrust Rating(90 Million Revolutions)(Ca90) 2295 lbf
  • Lubrication Required
  • Temperature Range -30° to 110 °C
  • ABEC Rating ABEC-1
  • Radial Clearance Standard (Available in C3/C4/C5)
  • RoHS Compliant
  • REACH Compliant
  • Weight 0.44 lb

Features

How Is 09074-09195AB Bearing Engineered for Reliability?

09074-09195AB Bearing features a single row tapered roller design, ideal for handling combined loads with ease.
Its chrome steel construction ensures durability and resistance to wear in demanding applications.

The flanged cup design provides secure mounting, enhancing stability during operation.
With a dynamic radial load capacity of 9630 lbf, it delivers consistent performance under heavy loads.

09074-09195AB Bearing operates efficiently within a temperature range of -30° to 110 °C.
Its standard radial clearance and ABEC-1 rating make it suitable for various industrial uses.

Application

Industrial Uses of 09074-09195AB Bearing
09074-09195AB Bearing is commonly used in heavy machinery, such as construction equipment and agricultural tools, where its tapered roller design handles combined loads effectively. The flanged cup adds stability, making it suitable for applications with misalignment risks.

In automotive systems, 09074-09195AB Bearing fits well in wheel hubs and differentials, providing reliable performance under radial and thrust loads. Its inch sizing ensures compatibility with many North American vehicle models.

For industrial conveyors, 09074-09195AB Bearing’s chrome steel construction offers durability in high-load environments. The open design allows for easy lubrication, extending service life in demanding conditions.

Where Is 09074-09195AB Bearing Used?
09074-09195AB Bearing is ideal for gearboxes in mining equipment, where its robust design withstands heavy loads and vibrations. The steel cage ensures smooth operation even in harsh environments.

In power transmission systems, 09074-09195AB Bearing supports shafts and pulleys, thanks to its tapered rollers distributing loads evenly. The flange prevents axial displacement, enhancing reliability.

Built for Heavy-Duty Use: 09074-09195AB Bearing
09074-09195AB Bearing excels in forklifts and cranes, where its combined load capacity and flanged design provide stability. The chrome steel rollers resist wear, ensuring long-term performance.

For agricultural machinery, 09074-09195AB Bearing handles uneven loads in tillers and harvesters. Its standard radial clearance allows for thermal expansion, preventing premature failure.

Automotive vs Aerospace: Applications of 09074-09195AB Bearing
In automotive applications, 09074-09195AB Bearing is found in drivetrains, offering durability and ease of maintenance. The inch measurements align with many US-made components.

For aerospace ground equipment, 09074-09195AB Bearing supports loading mechanisms, where precision and reliability are critical. Its temperature range suits various operational conditions.
