TS (Single Row Tapered Roller Bearings) (Metric) 32204

TS (Single Row Tapered Roller Bearings) (Metric) 32204

The A6062-A6157-B is a single-row tapered roller bearing with a flange, measuring 0.625″ x 1.5745″ x 0.4391″. Made from chrome steel, it handles combined loads with a dynamic radial load capacity of 3020 lbf.

Its flanged cup design ensures secure positioning, while the open seal allows easy lubrication. The bearing operates smoothly in temperatures from -30°C to 110°C.

This model is interchangeable with Timken bearings, making it a practical choice for replacements. Ideal for applications like axles or gearboxes where combined loads are common.

Weighing just 0.200 lb, it’s lightweight yet durable. Compliant with RoHS and REACH standards for safe use.

Get A Free Quote
    Description Features Application Q&A Featured Products Our Process

Product Parameters

  • Part Number 32204
  • Brand TFL
  • Interchangeable Brand Timken
  • System of Measurement Metric
  • Type Bearing
  • Sizes 20 mm x 47 mm x 19.25 mm
  • Cone Part Number X32204
  • Cup Part Number Y32204
  • Bore Dia 20 mm
  • Bore Dia Tolerance -0.012mm to 0
  • Outer Dia 47 mm
  • Outer Dia Tolerance -0.014mm to 0
  • Cone Width 18 mm
  • Cone Width Tolerance -0.1mm to 0
  • Cup Width 15 mm
  • Cup Width Tolerance -0.15mm to 0
  • Width 19.25 mm
  • Width Tolerance +0.2mm to 0
  • Cone Backface ToClear Radius 1.02 mm
  • Cup Backface ToClear Radius 1.02 mm
  • Cone Frontface Backing Diameter 26.5 mm
  • Cone Backface Backing Diameter 28.5 mm
  • Cup Frontface Backing Diameter 43.94 mm
  • Cup Backface Backing Diameter 40.39 mm
  • Cage Cone Frontface Clearance 2.5 mm
  • Cage Cone Backface Clearance 0 mm
  • Effective Center Location -6.6 mm
  • Bearing Type Roller
  • Roller Bearing Type Tapered
  • For Load Direction Combined
  • Construction Single Row
  • Seal Type Open
  • Cups Type Standard
  • Series 32204
  • Ring Material Chrome Steel
  • Roller Material Chrome Steel
  • Cage Material Steel
  • Dynamic Radial Load 11138 lbf
  • Static Radial Load 9675 lbf
  • Dynamic Radial Rating(90 Million Revolutions)(C90) 2880 lbf
  • Dynamic Thrust Rating(90 Million Revolutions)(Ca90) 1638 lbf
  • Lubrication Required
  • Temperature Range -30° to 110 °C
  • ABEC Rating ABEC-1
  • Radial Clearance Standard (Available in C3/C4/C5)
  • RoHS Compliant
  • REACH Compliant
  • Weight 0.44 lb

Features

Performance Features of A6062-A6157-B Bearing

A6062-A6157-B Bearing is crafted with chrome steel rings and rollers, offering strong resistance to combined loads.
Its dynamic radial load capacity reaches 3020 lbf, ensuring reliable performance in various applications.

The tapered roller design enhances load distribution, reducing wear and extending service life.
With a flanged cup, A6062-A6157-B Bearing provides secure mounting and alignment in assemblies.

A6062-A6157-B Bearing operates efficiently within a temperature range of -30° to 110°C.
Its standard radial clearance and ABEC-1 rating make it suitable for general precision needs.

Application

Industrial Uses of A6062-A6157-B Bearing
A6062-A6157-B Bearing is commonly used in industrial gearboxes, where its tapered roller design efficiently handles combined radial and thrust loads. The flanged cup ensures secure mounting, reducing misalignment risks in heavy machinery.

In automotive applications, A6062-A6157-B Bearing supports wheel hubs and differential systems, offering reliable performance under varying loads. Its inch sizing makes it a straightforward replacement for Timken equivalents in older vehicles.

For conveyor systems, A6062-A6157-B Bearing’s chrome steel construction provides durability in dusty or high-load environments. The open seal design allows for easy relubrication, extending service life in continuous operation.

What Makes A6062-A6157-B Bearing a Preferred Choice?
A6062-A6157-B Bearing is ideal for agricultural equipment, where its robust design withstands rough terrain and shock loads. The steel cage ensures smooth roller movement, even in demanding conditions.

In construction machinery, A6062-A6157-B Bearing’s tapered rollers distribute loads evenly, reducing wear on critical components. Its ABEC-1 rating balances precision and cost-effectiveness for general industrial use.
