TS (Single Row Tapered Roller Bearings) (Metric) 30304

TS (Single Row Tapered Roller Bearings) (Metric) 30304

The 09062-09195AB is a single-row tapered roller bearing with a flange, measuring 0.625″ x 1.938″ x 0.848″. Made from durable chrome steel, it handles combined loads up to 9630 lbf and works well in temperatures from -30°C to 110°C.

Its flanged cup design keeps it securely in place, while the open seal allows for easy lubrication. The steel cage ensures smooth operation and long service life.

This bearing is interchangeable with Timken models, making it a practical choice for replacements. Ideal for applications like axles or gearboxes where combined loads are common.

Weighing just 0.3 lb, it’s lightweight yet robust. Compliant with RoHS and REACH standards, it meets ABEC-1 precision requirements.

Get A Free Quote
    Description Features Application Q&A Featured Products Our Process

Product Parameters

  • Part Number 30304
  • Brand TFL
  • Interchangeable Brand Timken
  • System of Measurement Metric
  • Type Bearing
  • Sizes 20 mm x 52 mm x 16.25 mm
  • Cone Part Number X30304
  • Cup Part Number Y30304
  • Bore Dia 20 mm
  • Bore Dia Tolerance -0.012mm to 0
  • Outer Dia 52 mm
  • Outer Dia Tolerance -0.016mm to 0
  • Cone Width 15 mm
  • Cone Width Tolerance -0.1mm to 0
  • Cup Width 13 mm
  • Cup Width Tolerance -0.15mm to 0
  • Width 16.25 mm
  • Width Tolerance +0.2mm to 0
  • Cone Backface ToClear Radius 1.52 mm
  • Cup Backface ToClear Radius 1.52 mm
  • Cone Frontface Backing Diameter 24.5 mm
  • Cone Backface Backing Diameter 27 mm
  • Cup Frontface Backing Diameter 48.01 mm
  • Cup Backface Backing Diameter 45.47 mm
  • Cage Cone Frontface Clearance 3.3 mm
  • Cage Cone Backface Clearance -1 mm
  • Effective Center Location -4.8 mm
  • Bearing Type Roller
  • Roller Bearing Type Tapered
  • For Load Direction Combined
  • Construction Single Row
  • Seal Type Open
  • Cups Type Standard
  • Series 30304
  • Ring Material Chrome Steel
  • Roller Material Chrome Steel
  • Cage Material Steel
  • Dynamic Radial Load 8662 lbf
  • Static Radial Load 7762 lbf
  • Dynamic Radial Rating(90 Million Revolutions)(C90) 2245.5 lbf
  • Dynamic Thrust Rating(90 Million Revolutions)(Ca90) 1154.25 lbf
  • Lubrication Required
  • Temperature Range -30° to 110 °C
  • ABEC Rating ABEC-1
  • Radial Clearance Standard (Available in C3/C4/C5)
  • RoHS Compliant
  • REACH Compliant
  • Weight 0.44 lb

Features

Performance Features of 09062-09195AB Bearing

09062-09195AB Bearing is built with chrome steel rings and rollers, offering strong resistance to combined loads.
Its dynamic radial load capacity reaches 9630 lbf, ensuring reliable performance in demanding applications.

The flanged cup design enhances stability, making it suitable for precise alignment needs.
With a standard radial clearance, it provides flexibility for various operational conditions.

09062-09195AB Bearing operates efficiently within a temperature range of -30° to 110°C.
Its steel cage maintains roller alignment, reducing wear and extending service life.

Application

Industrial Uses of 09062-09195AB Bearing
09062-09195AB Bearing is commonly used in heavy machinery like construction equipment, where its tapered roller design handles combined loads effectively. The flanged cup adds stability, making it suitable for rugged environments.

In automotive applications, 09062-09195AB Bearing fits well in wheel hubs and differential systems, thanks to its inch sizing and compatibility with Timken designs. Its chrome steel construction ensures durability under constant stress.

For industrial conveyor systems, 09062-09195AB Bearing’s open seal type allows easy lubrication, extending service life. The standard radial clearance offers flexibility for various load conditions.

In agricultural machinery, 09062-09195AB Bearing’s robust design withstands dust and debris. The steel cage provides added strength, making it reliable for long-term use.
