TS (Single Row Tapered Roller Bearings) (Imperial) 95491-95962

TS (Single Row Tapered Roller Bearings) (Imperial) 95491-95962

The 95491-95962 is a single-row tapered roller bearing with a 4.919″ bore and 9.625″ outer diameter, built from sturdy chrome steel. It handles combined loads up to 141,000 lbf radially and 23,200 lbf thrust, making it robust for heavy-duty use.

Its open design allows easy lubrication, while the steel cage ensures durability under high stress. The bearing operates smoothly in temperatures from -30°C to 110°C.

This model is interchangeable with Timken bearings, offering a reliable replacement option. Ideal for industrial machinery or vehicle axles where combined loads are common.

Weighing 29.3 lb, it’s designed for long-lasting performance with standard radial clearance options. Compliant with RoHS and REACH standards for safe use.

Get A Free Quote
    Description Features Application Q&A Featured Products Our Process

Product Parameters

  • Part Number 95491-95962
  • Brand TFL
  • Interchangeable Timken
  • Size 4.919" x 9.625" x 2.5"
  • Bore Dia 4.919"
  • Bore Dia Tolerance +0.001" to 0
  • Outer Dia 9.625"
  • Outer Dia Tolerance +0.001" to 0
  • Cone Width 2.5"
  • Cone Width Tolerance +0.003" to -0.01
  • Cup Width 1.9375"
  • Cup Width Tolerance +0.002" to -0.01
  • Width 2.5"
  • Width Tolerance +0.014" to -0.01"
  • Cone Backface ToClear Radius 0.25"
  • Cup Backface ToClear Radius 0.130"
  • Cone Frontface Backing Diameter 6.46"
  • Cone Backface Backing Diameter 5.98"
  • Cup Frontface Backing Diameter 8.58"
  • Cup Backface Backing Diameter 8.39"
  • Cage Cone Frontface Clearance 0.19"
  • Cage Cone Backface Clearance 0.22"
  • Effective Center Location -0.55"
  • System of Measurement Inch
  • Type Bearing
  • Cone Part Number 95491
  • Cup Part Number 95962
  • Bearing Type Roller
  • Roller Bearing Type Tapered
  • For Load Direction Combined
  • Construction Single Row
  • Seal Type Open
  • Cups Type Standard
  • Series 95000
  • Ring Material Chrome Steel
  • Roller Material Chrome Steel
  • Cage Material Steel
  • Dynamic Radial Load 141000 lbf
  • Static Radial Load 209000 lbf
  • Dynamic Radial Rating(90 Million Revolutions)(C90) 36700 lbf
  • Dynamic Thrust Rating(90 Million Revolutions)(Ca90) 23200 lbf
  • Lubrication Required
  • Temperature Range -30° to 110 °C
  • ABEC Rating ABEC-1
  • Radial Clearance Standard (Available in C3/C4/C5)
  • RoHS Compliant
  • REACH Compliant
  • Weight 29.3 lb

Features

Performance Features of 95491-95962 Bearing

95491-95962 Bearing is built with chrome steel rings and rollers, offering strong resistance to combined loads.
Its dynamic radial load capacity reaches 141,000 lbf, making it suitable for heavy-duty applications.

The steel cage ensures proper roller alignment, reducing friction and extending operational life.
With a temperature range of -30° to 110°C, it performs reliably in various environments.

95491-95962 Bearing’s standard radial clearance allows for smooth operation under different conditions.
Its tapered roller design efficiently handles both radial and thrust loads.

The bearing requires lubrication to maintain optimal performance over time.
Weighing 29.3 lb, it balances durability and functionality in industrial settings.

Application

Industrial Uses of 95491-95962 Bearing
The 95491-95962 Bearing is widely used in heavy machinery, such as construction equipment and mining tools, where its tapered roller design handles combined loads effectively. Its chrome steel construction ensures durability even in demanding environments.

In automotive applications, 95491-95962 Bearing is commonly found in truck wheel hubs and differential systems, providing reliable performance under high radial and thrust loads. The inch sizing makes it a preferred choice for American-made vehicles.

For industrial gearboxes, 95491-95962 Bearing’s open design allows for easy lubrication, extending its service life in continuous operation. The steel cage adds stability, making it suitable for high-speed scenarios.

Where Is 95491-95962 Bearing Used?
You’ll often spot 95491-95962 Bearing in agricultural machinery, like tractors and harvesters, where its robust design withstands rough conditions. The standard radial clearance ensures smooth operation even with varying loads.

In conveyor systems, 95491-95962 Bearing supports heavy rollers, thanks to its high dynamic radial load capacity. The ABEC-1 rating balances precision and cost-effectiveness for industrial applications.

Built for Heavy-Duty Use: 95491-95962 Bearing
95491-95962 Bearing excels in forestry equipment, such as log splitters, where its tapered rollers manage intense combined loads. The chrome steel rollers resist wear, reducing maintenance needs.

For railway applications, 95491-95962 Bearing’s inch sizing and compatibility with Timken designs make it a reliable choice for axle boxes. Its temperature range suits both cold and moderate climates.

Automotive vs Aerospace: Applications of 95491-95962 Bearing
In automotive settings, 95491-95962 Bearing handles wheel and transmission loads, while its aerospace use is limited due to weight. The inch measurements align with North American manufacturing standards.

For industrial pumps, 95491-95962 Bearing’s single-row design simplifies installation and maintenance. The steel cage ensures consistent performance in high-vibration environments.
