TS (Single Row Tapered Roller Bearings) (Imperial) 799-792

TS (Single Row Tapered Roller Bearings) (Imperial) 799-792

The 799-792 is a single-row tapered roller bearing with a 5.0625″ bore and 8.125″ outer diameter, crafted from sturdy chrome steel. It handles combined loads up to 85,000 lbf radially and 17,300 lbf thrust, making it a robust choice for heavy-duty applications.

Its open design allows for easy lubrication, while the steel cage ensures durability under high stress. The bearing operates smoothly in temperatures ranging from -30°C to 110°C.

This model is interchangeable with Timken bearings, offering a reliable replacement option. Ideal for industrial machinery, gearboxes, or automotive systems where combined loads are common.

Weighing 12.7 lb, it’s built to last with standard radial clearance options. Compliant with RoHS and REACH standards for safe and eco-friendly use.

Get A Free Quote
    Description Features Application Q&A Featured Products Our Process

Product Parameters

  • Part Number 799-792
  • Brand TFL
  • Interchangeable Timken
  • Size 5.0625" x 8.125" x 1.875"
  • Bore Dia 5.0625"
  • Bore Dia Tolerance +0.001" to 0
  • Outer Dia 8.125"
  • Outer Dia Tolerance +0.001" to 0
  • Cone Width 1.875"
  • Cone Width Tolerance +0.003" to -0.01
  • Cup Width 1.375"
  • Cup Width Tolerance +0.002" to -0.01
  • Width 1.875"
  • Width Tolerance +0.014" to -0.01"
  • Cone Backface ToClear Radius 0.13"
  • Cup Backface ToClear Radius 0.130"
  • Cone Frontface Backing Diameter 6.46"
  • Cone Backface Backing Diameter 5.75"
  • Cup Frontface Backing Diameter 7.76"
  • Cup Backface Backing Diameter 7.32"
  • Cage Cone Frontface Clearance 0.16"
  • Cage Cone Backface Clearance 0.18"
  • Effective Center Location -0.07"
  • System of Measurement Inch
  • Type Bearing
  • Cone Part Number 799
  • Cup Part Number 792
  • Bearing Type Roller
  • Roller Bearing Type Tapered
  • For Load Direction Combined
  • Construction Single Row
  • Seal Type Open
  • Cups Type Standard
  • Series 795
  • Ring Material Chrome Steel
  • Roller Material Chrome Steel
  • Cage Material Steel
  • Dynamic Radial Load 85000 lbf
  • Static Radial Load 133000 lbf
  • Dynamic Radial Rating(90 Million Revolutions)(C90) 22000 lbf
  • Dynamic Thrust Rating(90 Million Revolutions)(Ca90) 17300 lbf
  • Lubrication Required
  • Temperature Range -30° to 110 °C
  • ABEC Rating ABEC-1
  • Radial Clearance Standard (Available in C3/C4/C5)
  • RoHS Compliant
  • REACH Compliant
  • Weight 12.700 lb

Features

Performance Features of 799-792 Bearing

799-792 Bearing is built with chrome steel rings and rollers, offering strong resistance to combined loads.
Its dynamic radial load capacity reaches 85,000 lbf, ensuring reliable performance in heavy-duty applications.
The steel cage maintains roller alignment, reducing friction and extending operational life.
With a temperature range of -30° to 110°C, it performs well in various environments.

How Does 799-792 Bearing Reduce Friction?

799-792 Bearing’s tapered roller design minimises friction, allowing smooth operation under combined loads.
The chrome steel construction enhances durability, while the steel cage ensures proper roller alignment.
Its dynamic thrust rating of 17,300 lbf at 90 million revolutions highlights its efficiency.
This design also supports easy lubrication, further reducing wear over time.

Engineered for Precision: 799-792 Bearing

799-792 Bearing features precise dimensions, with bore and outer diameter tolerances of +0.001″ to 0.
Its effective center location of -0.07″ ensures accurate alignment in assemblies.
The standard radial clearance option is available in C3, C4, and C5 for tailored performance.
This attention to detail makes it suitable for applications requiring high precision.

Why Choose 799-792 Bearing for Combined Loads?

799-792 Bearing handles both radial and thrust loads efficiently, thanks to its tapered roller design.
With a static radial load capacity of 133,000 lbf, it excels in demanding industrial settings.
The open seal type allows for easy lubrication, maintaining performance over time.
Its ABEC-1 rating ensures consistent quality and reliability in various applications.

Application

Essential Roles of 799-792 Bearing
The 799-792 Bearing is commonly used in heavy machinery, such as construction equipment and mining tools, where its tapered roller design handles combined loads effectively. Its chrome steel construction ensures durability in demanding environments.

In automotive applications, 799-792 Bearing is ideal for wheel hubs and differential systems, providing reliable performance under high radial and thrust loads. The inch sizing makes it compatible with many North American vehicle models.

For industrial gearboxes, 799-792 Bearing’s open design and steel cage allow for easy lubrication and maintenance. Its standard radial clearance ensures smooth operation in various temperature conditions.

Where Is 799-792 Bearing Used?
You’ll often find 799-792 Bearing in agricultural machinery, like tractors and harvesters, where its robust design withstands heavy loads and rough conditions. The tapered rollers distribute stress evenly for longer service life.

In conveyor systems, 799-792 Bearing supports high-speed operations with minimal friction. Its ABEC-1 rating ensures consistent performance without the need for precision tolerances.

Built for Heavy-Duty Use: 799-792 Bearing
The 799-792 Bearing excels in forestry equipment, such as log splitters and sawmills, thanks to its high static radial load capacity. The steel cage adds extra strength for shock resistance.

In material handling equipment, 799-792 Bearing’s tapered rollers provide stability under uneven loads. Its standard lubrication requirement makes it easy to maintain in busy industrial settings.

Automotive vs Aerospace: Applications of 799-792 Bearing
In automotive systems, 799-792 Bearing is a go-to for drivetrain components, offering reliable performance in trucks and off-road vehicles. Its inch measurements simplify replacements in older models.

For aerospace ground support equipment, 799-792 Bearing handles heavy loads while maintaining precision. The chrome steel rollers ensure smooth operation even in temperature extremes.
