TS (Single Row Tapered Roller Bearings) (Imperial) 540-532X

TS (Single Row Tapered Roller Bearings) (Imperial) 540-532X

The 540-532X is a single-row tapered roller bearing with a 2.0625″ bore and 4.25″ outer diameter, crafted from sturdy chrome steel. It manages combined loads up to 38700 lbf radially and 5090 lbf thrust, suitable for demanding applications.

Its open design allows for easy lubrication, while the steel cage ensures durability. The bearing operates smoothly in temperatures ranging from -30°C to 110°C.

This model is interchangeable with Timken bearings, making it a practical choice for replacements. Ideal for use in heavy machinery or automotive systems where combined loads are common.

Weighing 3.3 lb, it offers a robust build without being overly heavy. Compliant with RoHS and REACH standards, it’s a reliable and safe option for various industrial needs.

Get A Free Quote
    Description Features Application Q&A Featured Products Our Process

Product Parameters

  • Part Number 540-532X
  • Brand TFL
  • Interchangeable Timken
  • Size 2.0625" x 4.25" x 1.4375"
  • Bore Dia 2.0625"
  • Bore Dia Tolerance +0.005" to 0
  • Outer Dia 4.25"
  • Outer Dia Tolerance +0.001" to 0
  • Cone Width 1.455"
  • Cone Width Tolerance +0.003" to -0.01
  • Cup Width 1.125"
  • Cup Width Tolerance +0.002" to -0.01
  • Width 1.4375"
  • Width Tolerance +0.008" to 0
  • Cone Backface ToClear Radius 0.14"
  • Cup Backface ToClear Radius 0.130"
  • Cone Frontface Backing Diameter 2.36"
  • Cone Backface Backing Diameter 2.64"
  • Cup Frontface Backing Diameter 3.96"
  • Cup Backface Backing Diameter 3.70"
  • Cage Cone Frontface Clearance 0.07"
  • Cage Cone Backface Clearance 0.08"
  • Effective Center Location -0.48"
  • System of Measurement Inch
  • Type Bearing
  • Cone Part Number 540
  • Cup Part Number 532X
  • Bearing Type Roller
  • Roller Bearing Type Tapered
  • For Load Direction Combined
  • Construction Single Row
  • Seal Type Open
  • Cups Type Standard
  • Series 535
  • Ring Material Chrome Steel
  • Roller Material Chrome Steel
  • Cage Material Steel
  • Dynamic Radial Load 38700 lbf
  • Static Radial Load 46200 lbf
  • Dynamic Radial Rating(90 Million Revolutions)(C90) 10000 lbf
  • Dynamic Thrust Rating(90 Million Revolutions)(Ca90) 5090 lbf
  • Lubrication Required
  • Temperature Range -30° to 110 °C
  • ABEC Rating ABEC-1
  • Radial Clearance Standard (Available in C3/C4/C5)
  • RoHS Compliant
  • REACH Compliant
  • Weight 3.3 lb

Features

Performance Features of 540-532X Bearing

540-532X Bearing is constructed with chrome steel rings and rollers, offering strong resistance to combined loads.
Its dynamic radial load capacity reaches 38,700 lbf, making it suitable for heavy-duty applications.
The steel cage ensures proper roller alignment, enhancing durability and reducing wear.
With a temperature range of -30° to 110°C, it performs reliably in various conditions.

How Is 540-532X Bearing Engineered for Reliability?

540-532X Bearing features a single-row tapered roller design, optimised for combined load handling.
The chrome steel construction provides excellent strength and resistance to wear.
Its standard radial clearance ensures smooth operation, even under demanding conditions.
The bearing’s ABEC-1 rating confirms its precision and reliability.

Built for Durability: 540-532X Bearing

540-532X Bearing’s chrome steel rollers and rings enhance its load-bearing capacity and longevity.
The steel cage maintains roller alignment, reducing friction and extending service life.
With a static radial load of 46,200 lbf, it handles heavy loads with ease.
Its open design allows for easy lubrication, ensuring consistent performance.

Steel vs Ceramic Bearings: Strengths of 540-532X Bearing

540-532X Bearing uses chrome steel for both rollers and rings, providing excellent durability.
This material choice ensures high resistance to wear and tear in demanding applications.
The bearing’s dynamic thrust rating of 5,090 lbf highlights its versatility.
Its standard radial clearance option makes it adaptable to various operational needs.

Application

Essential Roles of 540-532X Bearing
540-532X Bearing is commonly used in industrial gearboxes, where its tapered roller design handles both radial and thrust loads efficiently. The chrome steel construction ensures durability in demanding environments like mining equipment.

In automotive applications, 540-532X Bearing supports heavy-duty axles and wheel hubs, providing reliable performance under combined loads. Its imperial sizing makes it a straightforward replacement for Timken bearings in North American vehicles.

For construction machinery, 540-532X Bearing’s robust design withstands the rigours of cranes and excavators. The open seal type allows for easy lubrication, extending service life in dusty conditions.

540-532X Bearing also fits well in agricultural equipment, such as tractors and harvesters, where its ABEC-1 rating balances precision and cost-effectiveness. The standard radial clearance offers flexibility for various load conditions.
