TS (Single Row Tapered Roller Bearings) (Imperial) 365-S-362A

TS (Single Row Tapered Roller Bearings) (Imperial) 365-S-362A

The 365-S-362A is a single-row tapered roller bearing with a 1.9375″ bore and 3.5″ outer diameter, crafted from sturdy chrome steel. It manages combined loads up to 22900 lbf radially and 3250 lbf thrust, suitable for demanding applications.

Its open design allows for easy lubrication, while the steel cage ensures durability. The bearing operates smoothly in temperatures ranging from -30°C to 110°C.

This model is interchangeable with Timken bearings, making it a practical choice for replacements. Ideal for use in heavy machinery or automotive systems where combined loads are common.

Weighing just 1.2 lb, it’s a robust yet lightweight option. Compliant with RoHS and REACH standards for safe and reliable performance.

Get A Free Quote
    Description Features Application Q&A Featured Products Our Process

Product Parameters

  • Part Number 365-S-362A
  • Brand TFL
  • Interchangeable Timken
  • Size 1.9375" x 3.5" x 0.8125"
  • Bore Dia 1.9375"
  • Bore Dia Tolerance +0.005" to 0
  • Outer Dia 3.5"
  • Outer Dia Tolerance +0.001" to 0
  • Cone Width 0.875"
  • Cone Width Tolerance +0.003" to -0.01
  • Cup Width 0.6501"
  • Cup Width Tolerance +0.002" to -0.01
  • Width 0.8125"
  • Width Tolerance +0.008" to 0
  • Cone Backface ToClear Radius 0.03"
  • Cup Backface ToClear Radius 0.050"
  • Cone Frontface Backing Diameter 2.13"
  • Cone Backface Backing Diameter 2.17"
  • Cup Frontface Backing Diameter 3.34"
  • Cup Backface Backing Diameter 3.19"
  • Cage Cone Frontface Clearance 0.07"
  • Cage Cone Backface Clearance 0"
  • Effective Center Location -0.17"
  • System of Measurement Inch
  • Type Bearing
  • Cone Part Number 365-S
  • Cup Part Number 362A
  • Bearing Type Roller
  • Roller Bearing Type Tapered
  • For Load Direction Combined
  • Construction Single Row
  • Seal Type Open
  • Cups Type Standard
  • Series 365
  • Ring Material Chrome Steel
  • Roller Material Chrome Steel
  • Cage Material Steel
  • Dynamic Radial Load 22900 lbf
  • Static Radial Load 21500 lbf
  • Dynamic Radial Rating(90 Million Revolutions)(C90) 5930 lbf
  • Dynamic Thrust Rating(90 Million Revolutions)(Ca90) 3250 lbf
  • Lubrication Required
  • Temperature Range -30° to 110 °C
  • ABEC Rating ABEC-1
  • Radial Clearance Standard (Available in C3/C4/C5)
  • RoHS Compliant
  • REACH Compliant
  • Weight 1.2 lb

Features

Performance Features of 365-S-362A Bearing

365-S-362A Bearing is built with chrome steel rings and rollers, offering strong resistance to combined loads.
Its dynamic radial load capacity reaches 22,900 lbf, making it suitable for heavy-duty applications.
The steel cage ensures proper roller alignment, enhancing durability and performance.
With a temperature range of -30° to 110°C, it operates reliably in various conditions.

How Does 365-S-362A Bearing Reduce Friction?

365-S-362A Bearing’s tapered roller design minimises friction, ensuring smooth operation under combined loads.
The chrome steel construction provides excellent wear resistance, extending its service life.
Proper lubrication is required to maintain optimal performance and reduce maintenance needs.
Its standard radial clearance allows for efficient load distribution and reduced heat generation.

Engineered for Precision: 365-S-362A Bearing

365-S-362A Bearing features precise dimensions, with a bore diameter tolerance of +0.005″ to 0.
The effective center location of -0.17″ ensures accurate alignment in various applications.
Its ABEC-1 rating guarantees consistent performance for general precision needs.
The single-row construction simplifies installation while maintaining reliability.

Steel vs Ceramic Bearings: Strengths of 365-S-362A Bearing

365-S-362A Bearing uses chrome steel for both rings and rollers, offering a balance of strength and affordability.
This material choice provides good resistance to wear and fatigue in demanding conditions.
The steel cage further enhances durability while keeping costs reasonable.
With a static radial load of 21,500 lbf, it delivers reliable performance for industrial applications.

Application

Industrial Uses of 365-S-362A Bearing
365-S-362A Bearing is commonly used in heavy machinery like construction equipment, where its tapered roller design handles combined radial and thrust loads effectively. The chrome steel construction ensures durability in demanding environments.

In automotive applications, 365-S-362A Bearing fits well in wheel hubs and differential systems, providing reliable performance under varying loads. Its imperial sizing makes it a practical choice for North American vehicle models.

For industrial conveyor systems, 365-S-362A Bearing’s open design allows for easy lubrication, extending its service life in continuous operation. The steel cage adds stability, reducing wear over time.

What Makes 365-S-362A Bearing a Preferred Choice?
365-S-362A Bearing is often selected for agricultural machinery due to its ability to withstand harsh conditions like dust and moisture. The standard radial clearance offers flexibility in various setups.

In mining equipment, 365-S-362A Bearing’s robust design ensures consistent performance under heavy loads. Its compatibility with Timken models simplifies maintenance and replacement.

Built for Heavy-Duty Use: 365-S-362A Bearing
365-S-362A Bearing excels in forestry machinery, where its tapered rollers manage uneven loads smoothly. The ABEC-1 rating balances precision and cost-effectiveness for these applications.

For railway applications, 365-S-362A Bearing provides reliable support in axle boxes, handling both radial and axial forces. The chrome steel rollers resist wear, even under constant vibration.

Automotive vs Aerospace: Applications of 365-S-362A Bearing
In automotive drivetrains, 365-S-362A Bearing offers dependable performance for gearboxes and transmissions. Its imperial measurements align with standard US automotive components.

For aerospace ground equipment, 365-S-362A Bearing is used in loading systems, where its combined load capacity is beneficial. The temperature range suits both indoor and outdoor use.
