TS (Single Row Tapered Roller Bearings) (Imperial) 365-362A

TS (Single Row Tapered Roller Bearings) (Imperial) 365-362A

The 365-362A is a single-row tapered roller bearing with a 1.9685″ bore and 3.5″ outer diameter, crafted from sturdy chrome steel. It handles combined loads up to 22900 lbf radially and 3250 lbf thrust, making it versatile for various applications.

Its open design allows for easy lubrication, while the steel cage ensures durability under heavy use. The bearing operates smoothly in temperatures ranging from -30°C to 110°C.

This model is interchangeable with Timken bearings, offering a reliable replacement option. Ideal for industrial machinery or automotive systems where combined loads are common.

Weighing just 1.1 lb, it’s lightweight yet robust. Compliant with RoHS and REACH standards, it’s a safe choice for most environments. The standard radial clearance ensures easy installation and maintenance.

Get A Free Quote
    Description Features Application Q&A Featured Products Our Process

Product Parameters

  • Part Number 365-362A
  • Brand TFL
  • Interchangeable Timken
  • Size 1.9685" x 3.5" x 0.8125"
  • Bore Dia 1.9685"
  • Bore Dia Tolerance +0.005" to 0
  • Outer Dia 3.5"
  • Outer Dia Tolerance +0.001" to 0
  • Cone Width 0.875"
  • Cone Width Tolerance +0.003" to -0.01
  • Cup Width 0.6501"
  • Cup Width Tolerance +0.002" to -0.01
  • Width 0.8125"
  • Width Tolerance +0.008" to 0
  • Cone Backface ToClear Radius 0.080"
  • Cup Backface ToClear Radius 0.050"
  • Cone Frontface Backing Diameter 2.17"
  • Cone Backface Backing Diameter 2.28"
  • Cup Frontface Backing Diameter 3.34"
  • Cup Backface Backing Diameter 3.19"
  • Cage Cone Frontface Clearance 0.07"
  • Cage Cone Backface Clearance 0"
  • Effective Center Location -0.17"
  • System of Measurement Inch
  • Type Bearing
  • Cone Part Number 365
  • Cup Part Number 362A
  • Bearing Type Roller
  • Roller Bearing Type Tapered
  • For Load Direction Combined
  • Construction Single Row
  • Seal Type Open
  • Cups Type Standard
  • Series 365
  • Ring Material Chrome Steel
  • Roller Material Chrome Steel
  • Cage Material Steel
  • Dynamic Radial Load 22900 lbf
  • Static Radial Load 21500 lbf
  • Dynamic Radial Rating(90 Million Revolutions)(C90) 5930 lbf
  • Dynamic Thrust Rating(90 Million Revolutions)(Ca90) 3250 lbf
  • Lubrication Required
  • Temperature Range -30° to 110 °C
  • ABEC Rating ABEC-1
  • Radial Clearance Standard (Available in C3/C4/C5)
  • RoHS Compliant
  • REACH Compliant
  • Weight 1.1 lb

Features

Why Choose 365-362A Bearing for Precision Tasks?

365-362A Bearing is crafted with chrome steel rings and rollers, ensuring durability and precision in combined load applications.
Its dynamic radial load capacity reaches 22,900 lbf, making it suitable for demanding industrial uses.
The steel cage maintains roller alignment, reducing friction and extending operational life.
With a temperature range of -30° to 110°C, it performs reliably in various environments.

How Is 365-362A Bearing Engineered for Reliability?

365-362A Bearing features a single-row tapered roller design, optimised for both radial and thrust loads.
The chrome steel construction resists wear, while the standard radial clearance ensures smooth operation.
Its ABEC-1 rating guarantees consistent performance in precision applications.
The open seal design allows for easy lubrication, enhancing long-term reliability.

Built for Durability: 365-362A Bearing

365-362A Bearing’s robust chrome steel components withstand heavy loads up to 21,500 lbf static radial capacity.
The tapered roller design distributes stress evenly, reducing wear and extending service life.
Its effective centre location ensures stable performance in various mounting configurations.
With a weight of just 1.1 lb, it balances strength and portability.

Steel vs Ceramic Bearings: Strengths of 365-362A Bearing

365-362A Bearing uses chrome steel for both rollers and rings, offering a cost-effective yet durable solution.
The steel cage provides reliable roller guidance, minimising friction and noise.
Its dynamic thrust rating of 3,250 lbf ensures versatility in different load conditions.
The standard lubrication requirement simplifies maintenance without compromising performance.

Performance Features of 365-362A Bearing

365-362A Bearing’s tapered roller design excels in handling combined radial and thrust loads efficiently.
The precise cone and cup width tolerances ensure easy installation and consistent performance.
Its dynamic radial rating of 5,930 lbf at 90 million revolutions highlights long-term reliability.
The open seal design allows for straightforward lubrication, reducing downtime.

Application

Industrial Uses of 365-362A Bearing
365-362A Bearing is commonly used in heavy machinery like construction equipment, where its tapered roller design handles combined loads effectively. The chrome steel construction ensures durability even in demanding environments.

In automotive applications, 365-362A Bearing fits well in wheel hubs and differential systems, providing reliable performance under radial and thrust loads. Its imperial sizing makes it a convenient choice for North American vehicle models.

For industrial conveyor systems, 365-362A Bearing’s open design allows for easy lubrication, extending service life in high-use scenarios. The steel cage adds extra strength, making it suitable for continuous operation.

Where Is 365-362A Bearing Used?
You’ll often find 365-362A Bearing in agricultural machinery, where its robust design handles rough conditions. The tapered rollers distribute loads evenly, reducing wear over time.

In mining equipment, 365-362A Bearing’s ability to manage heavy radial and thrust loads makes it a reliable choice. The standard radial clearance ensures smooth operation even under varying temperatures.

Built for Heavy-Duty Use: 365-362A Bearing
365-362A Bearing excels in forestry equipment, where its chrome steel rollers withstand harsh conditions. The single-row construction simplifies maintenance, saving time and effort.

For railway applications, 365-362A Bearing’s durability ensures consistent performance in axle boxes. The ABEC-1 rating provides a balance of precision and cost-effectiveness for these uses.

Automotive vs Aerospace: Applications of 365-362A Bearing
In automotive systems, 365-362A Bearing is ideal for transmissions, offering smooth operation under combined loads. The imperial measurements align with many US-made components.

While not typically used in aerospace, 365-362A Bearing’s reliability makes it suitable for ground support equipment. Its temperature range covers most operational needs without issue.
