TS (Single Row Tapered Roller Bearings) (Imperial) 33262-33472

TS (Single Row Tapered Roller Bearings) (Imperial) 33262-33472

The 33262-33472 is a single-row tapered roller bearing with a 2.625″ bore and 4.7244″ outer diameter, crafted from sturdy chrome steel. It handles combined loads up to 31100 lbf radially and 6020 lbf thrust, making it versatile for various applications.

Its open design allows easy lubrication, while the steel cage ensures durability under heavy use. The bearing operates smoothly in temperatures from -30°C to 110°C, suitable for demanding environments.

This model is interchangeable with Timken bearings, offering a reliable replacement option. Ideal for industrial machinery, gearboxes, or heavy equipment where combined loads are common.

Weighing 3.1 lb, it’s robust yet manageable for its size. Compliant with RoHS and REACH standards, it meets safety and environmental requirements.

Get A Free Quote
    Description Features Application Q&A Featured Products Our Process

Product Parameters

  • Part Number 33262-33472
  • Brand TFL
  • Interchangeable Timken
  • Size 2.625" x 4.7244" x 1.173"
  • Bore Dia 2.625"
  • Bore Dia Tolerance +0.005" to 0
  • Outer Dia 4.7244"
  • Outer Dia Tolerance +0.001" to 0
  • Cone Width 1.1875"
  • Cone Width Tolerance +0.003" to -0.01
  • Cup Width 0.923"
  • Cup Width Tolerance +0.002" to -0.01
  • Width 1.173"
  • Width Tolerance +0.008" to 0
  • Cone Backface ToClear Radius 0.14"
  • Cup Backface ToClear Radius 0.03"
  • Cone Frontface Backing Diameter 3.57"
  • Cone Backface Backing Diameter 3.19"
  • Cup Frontface Backing Diameter 4.49"
  • Cup Backface Backing Diameter 4.21"
  • Cage Cone Frontface Clearance 0.07"
  • Cage Cone Backface Clearance 0.07"
  • Effective Center Location -0.11"
  • System of Measurement Inch
  • Type Bearing
  • Cone Part Number 33262
  • Cup Part Number 33472
  • Bearing Type Roller
  • Roller Bearing Type Tapered
  • For Load Direction Combined
  • Construction Single Row
  • Seal Type Open
  • Cups Type Standard
  • Series 33000
  • Ring Material Chrome Steel
  • Roller Material Chrome Steel
  • Cage Material Steel
  • Dynamic Radial Load 31100 lbf
  • Static Radial Load 44300 lbf
  • Dynamic Radial Rating(90 Million Revolutions)(C90) 8060 lbf
  • Dynamic Thrust Rating(90 Million Revolutions)(Ca90) 6020 lbf
  • Lubrication Required
  • Temperature Range -30° to 110 °C
  • ABEC Rating ABEC-1
  • Radial Clearance Standard (Available in C3/C4/C5)
  • RoHS Compliant
  • REACH Compliant
  • Weight 3.1 lb

Features

Performance Features of 33262-33472 Bearing

33262-33472 Bearing is built with chrome steel rings and rollers, offering strong resistance to combined loads.
Its dynamic radial load capacity reaches 31,100 lbf, making it suitable for heavy-duty applications.

The steel cage ensures proper roller alignment, reducing friction and enhancing durability.
With a temperature range of -30° to 110°C, it performs reliably in various operating conditions.

The tapered roller design provides efficient load distribution, extending the bearing’s service life.
Its standard radial clearance allows for smooth operation in diverse industrial settings.

Application

Industrial Uses of 33262-33472 Bearing
You’ll often spot 33262-33472 Bearing in heavy machinery like construction equipment, where its tapered roller design handles combined radial and thrust loads effortlessly. The chrome steel construction gives it solid durability for tough working conditions.

What Makes 33262-33472 Bearing a Preferred Choice?
In automotive applications, 33262-33472 Bearing works well in wheel hubs and differentials due to its precise imperial sizing. The steel cage keeps everything running smoothly even under heavy loads.

Built for Heavy-Duty Use: 33262-33472 Bearing
This bearing shines in industrial gearboxes where reliability matters most. Its standard radial clearance makes installation straightforward while maintaining good performance.

Automotive vs Industrial: Where 33262-33472 Bearing Excels
Whether in truck axles or conveyor systems, 33262-33472 Bearing delivers consistent performance. The ABEC-1 rating ensures it meets basic precision needs for most applications.

Practical Applications of 33262-33472 Bearing
Farm equipment benefits from 33262-33472 Bearing’s ability to handle dirt and debris thanks to its open design. Regular lubrication keeps it running smoothly season after season.
