Thin Section Ball Bearings SER1634 ZZ

Thin Section Ball Bearings SER1634 ZZ

The SER1634 ZZ is a slim radial ball bearing measuring 0.75″ by 1″ with a thin 0.1562″ width, crafted entirely from stainless steel for corrosion resistance. It supports radial loads up to 227 lbf and spins smoothly at 8500 RPM.

Shielded on both sides, it keeps contaminants out while maintaining easy access for lubrication. The ABEC-1 tolerance ensures reliable performance without excessive precision demands.

With a temperature range of -86°F to 230°F, it suits environments from cold storage to warm machinery. Ideal for small mechanisms like medical devices or optical equipment where space is limited.

Weighing just 4.56 grams, this lightweight bearing meets RoHS and REACH standards. Its C0 clearance provides a balance between smooth rotation and load capacity.

Get A Free Quote
    Description Features Application Q&A Featured Products Our Process

Product Parameters

  • Part Number SER1634 ZZ
  • Brand TFL
  • Bore Dia 0.75"
  • Bore Dia Tolerance -0.01mm to 0
  • Outer Dia 1"
  • Outer Dia Tolerance -0.009mm to 0
  • Width 0.1562"
  • Width Tolerance -0.12mm to 0
  • Radial Clearance 0.006mm to 0.020mm
  • System of Measurement Inch
  • Bearing Type Ball
  • For Load Direction Radial
  • Construction Single Row
  • Seal Type Shielded
  • Tolerance Class ABEC-1
  • Radial Clearance Trade No C0
  • Ring Material Stainless Steel
  • Ball Material Stainless Steel
  • Cage Material Stainless Steel
  • Dynamic Radial Load 227 lbf
  • Static Radial Load 155 lbf
  • Temperature Range -86 to 230 °F
  • Lubrication Required
  • RoHS Compliant
  • REACH Compliant
  • Max Speed 8500 rpm
  • Weight 4.56 g
  • Price（$） 3
Thin Section Ball Bearings SER1634 ZZ dimension drawing
Download DWG Download PDF

Features

How Does SER1634 ZZ Bearing Ensure Smooth Operation?

SER1634 ZZ Bearing features stainless steel rings and balls, offering consistent performance in radial load applications.
Its dynamic radial load capacity of 227 lbf ensures reliable operation under stress.
The shielded design protects against contaminants while maintaining smooth rotation.
With a maximum speed of 8,500 rpm, it balances efficiency and durability in compact spaces.

Application

Common Applications of SER1634 ZZ Bearing
SER1634 ZZ Bearing is widely used in robotics, especially in compact robotic arms where its thin section design saves space without compromising performance. The shielded seals help keep contaminants out, making it reliable in dusty environments.

In medical devices like portable diagnostic tools, SER1634 ZZ Bearing offers smooth rotation due to its stainless steel construction. Its lightweight design is ideal for equipment that requires frequent movement.

For consumer electronics such as high-end printers, SER1634 ZZ Bearing ensures quiet operation and long service life. The ABEC-1 tolerance provides sufficient precision for most everyday applications.

Automotive enthusiasts appreciate SER1634 ZZ Bearing in custom gear mechanisms where its inch sizing fits older models perfectly. The stainless steel materials resist corrosion, even in humid conditions.

Industrial automation systems benefit from SER1634 ZZ Bearing’s ability to handle moderate radial loads at high speeds. Its compact dimensions allow for flexible integration into tight spaces.
