Thin Section Ball Bearings S6913 2rs

Thin Section Ball Bearings S6913 2rs

The S6913 2RS is a slim, sealed ball bearing measuring 65mm by 90mm by 13mm, crafted entirely from stainless steel for durability. It handles radial loads up to 3500 lbf and spins smoothly at speeds up to 6300 RPM.

Its sealed design keeps out dirt and moisture, making it low-maintenance, while the stainless steel construction resists corrosion. The bearing operates in temperatures from -86°F to 230°F, suitable for varied environments.

This model is ideal for applications where space is tight but performance is key, such as robotics or medical equipment. Its lightweight design at 211g ensures easy handling without sacrificing strength.

Compliant with RoHS and REACH standards, it’s a reliable choice for industries needing precision and longevity. Regular lubrication will keep it running smoothly for years.

Get A Free Quote
    Description Features Application Q&A Featured Products Our Process

Product Parameters

  • Part Number S6913 2rs
  • Brand TFL
  • Bore Dia 65 mm
  • Bore Dia Tolerance -0.015mm to 0
  • Outer Dia 90 mm
  • Outer Dia Tolerance -0.015mm to 0
  • Width 13 mm
  • Width Tolerance -0.150mm to 0
  • Radial Clearance 0.008mm to 0.028mm
  • System of Measurement Metric
  • Bearing Type Ball
  • For Load Direction Radial
  • Construction Single Row
  • Seal Type Sealed
  • Tolerance Class ABEC-1
  • Radial Clearance Trade No C0
  • Ring Material Stainless Steel
  • Ball Material Stainless Steel
  • Cage Material Stainless Steel
  • Dynamic Radial Load 3500 lbf
  • Static Radial Load 3237 lbf
  • Temperature Range -86 to 230 °F
  • Lubrication Required
  • RoHS Compliant
  • REACH Compliant
  • Max Speed 6300 rpm
  • Weight 211 g
  • Price（$） 3
Thin Section Ball Bearings S6913 2rs dimension drawing
Download DWG Download PDF

Features

How Does S6913 2rs Bearing Reduce Friction?

S6913 2rs Bearing features stainless steel rings and balls, ensuring smooth operation with minimal friction.
Its sealed design helps retain lubrication, reducing wear and maintenance needs.
The single-row construction and ABEC-1 tolerance class provide reliable radial load support.
With a dynamic radial load capacity of 3500 lbf, it performs well in various applications.

Application

Industrial Uses of S6913 2RS Bearing
S6913 2RS Bearing is commonly used in industrial machinery where space is limited, such as packaging equipment and printing presses. Its thin section design ensures it fits neatly into compact assemblies without compromising performance.

Where Is S6913 2RS Bearing Used?
In robotics, S6913 2RS Bearing provides smooth motion in joints and pivots, thanks to its sealed design which keeps contaminants out. The stainless steel construction also makes it suitable for environments where corrosion resistance is needed.

Perfect Fit for Automation: S6913 2RS Bearing
S6913 2RS Bearing works well in automated systems like conveyor belts and sorting machines. Its ABEC-1 tolerance ensures reliable operation, while the sealed design reduces maintenance needs.

Medical vs Industrial: Where S6913 2RS Bearing Excels
In medical devices, S6913 2RS Bearing offers quiet and precise movement, ideal for imaging equipment. For industrial applications, its durability handles radial loads in machinery like CNC routers.

Light-Duty vs Heavy-Duty: Best Uses for S6913 2RS Bearing
S6913 2RS Bearing is great for light-duty tasks in office printers and small appliances. For heavier tasks, it supports radial loads in agricultural equipment, proving its versatility.
