Thin Section Ball Bearings S6910zz

Thin Section Ball Bearings S6910zz

The S6910zz is a slim, shielded ball bearing measuring 50mm by 72mm by 12mm, crafted entirely from stainless steel for durability. It handles radial loads up to 2934 lbf and spins smoothly at speeds reaching 8100 RPM.

Its compact, single-row design makes it ideal for tight spaces, while the shielded seals help keep out dust and debris. The bearing operates efficiently in temperatures ranging from -86°F to 230°F.

With a C0 radial clearance, it offers reliable performance in applications requiring precision. Perfect for use in small machinery or medical devices where space is limited.

Weighing just 133g, it’s lightweight yet sturdy. Compliant with RoHS and REACH standards, it requires regular lubrication for optimal performance.

Get A Free Quote
    Description Features Application Q&A Featured Products Our Process

Product Parameters

  • Part Number S6910zz
  • Brand TFL
  • Bore Dia 50 mm
  • Bore Dia Tolerance -0.012mm to 0
  • Outer Dia 72 mm
  • Outer Dia Tolerance -0.013mm to 0
  • Width 12 mm
  • Width Tolerance -0.120mm to 0
  • Radial Clearance 0.006mm to 0.023mm
  • System of Measurement Metric
  • Bearing Type Ball
  • For Load Direction Radial
  • Construction Single Row
  • Seal Type Shielded
  • Tolerance Class ABEC-1
  • Radial Clearance Trade No C0
  • Ring Material Stainless Steel
  • Ball Material Stainless Steel
  • Cage Material Stainless Steel
  • Dynamic Radial Load 2934 lbf
  • Static Radial Load 2367 lbf
  • Temperature Range -86 to 230 °F
  • Lubrication Required
  • RoHS Compliant
  • REACH Compliant
  • Max Speed 8100 rpm
  • Weight 133 g
  • Price（$） 2.5
Thin Section Ball Bearings S6910zz dimension drawing
Download DWG Download PDF

Features

Performance Features of S6910zz Bearing

S6910zz Bearing is crafted with stainless steel rings and balls, offering excellent resistance to corrosion.
Its shielded design helps keep contaminants out while retaining lubrication for smooth operation.

The single-row construction ensures reliable radial load handling, with a dynamic radial load capacity of 2934 lbf.
With a maximum speed of 8,100 rpm, it delivers consistent performance in various applications.

S6910zz Bearing operates efficiently within a wide temperature range of -86 to 230°F.
Its compact thin-section design makes it suitable for space-constrained installations.

The ABEC-1 tolerance and C0 radial clearance provide a balance of precision and affordability.
This bearing is ideal for applications requiring durability and low maintenance.

Application

Industrial Uses of S6910zz Bearing
S6910zz Bearing is commonly used in industrial machinery where space is limited, such as packaging equipment and small conveyors. Its thin section design allows for compact installations without sacrificing performance.

What Makes S6910zz Bearing a Preferred Choice?
In robotics, S6910zz Bearing provides smooth rotation in joints and arms, thanks to its stainless steel construction and shielded design. The ABEC-1 tolerance ensures reliable precision for automated tasks.

Built for Heavy-Duty Use: S6910zz Bearing
For automotive applications, S6910zz Bearing fits well in steering systems and small gearboxes. Its ability to handle radial loads makes it a dependable option for vehicle components.

Medical vs Industrial: Where S6910zz Bearing Excels
In medical devices like dental drills, S6910zz Bearing offers quiet operation and resistance to corrosion. The same qualities make it useful in food processing equipment where hygiene is key.

Automation and Robotics: S6910zz Bearing in Action
S6910zz Bearing works efficiently in 3D printers and CNC machines, ensuring precise movements. Its lightweight design helps reduce overall machine weight while maintaining durability.
