Thin Section Ball Bearings S6710 2rs

Thin Section Ball Bearings S6710 2rs

The S6710 2RS is a slim, sealed ball bearing measuring 50mm by 62mm by 6mm, crafted entirely from stainless steel for durability. It handles radial loads up to 540 lbf and operates smoothly at speeds up to 3690 RPM.

Its sealed design keeps dirt out and lubrication in, making it low-maintenance for long-term use. The bearing works in a wide temperature range, from -86°F to 230°F.

With ABEC-1 precision and C0 clearance, it offers reliable performance for light to moderate loads. Ideal for applications like small motors or precision instruments where space is limited.

Weighing just 64g, it’s lightweight yet sturdy. Compliant with RoHS and REACH standards for safe use in various industries.

Get A Free Quote
    Description Features Application Q&A Featured Products Our Process

Product Parameters

  • Part Number S6710 2rs
  • Brand TFL
  • Bore Dia 50 mm
  • Bore Dia Tolerance -0.012mm to 0
  • Outer Dia 62 mm
  • Outer Dia Tolerance -0.013mm to 0
  • Width 6 mm
  • Width Tolerance -0.120mm to 0
  • Radial Clearance 0.006mm to 0.023mm
  • System of Measurement Metric
  • Bearing Type Ball
  • For Load Direction Radial
  • Construction Single Row
  • Seal Type Sealed
  • Tolerance Class ABEC-1
  • Radial Clearance Trade No C0
  • Ring Material Stainless Steel
  • Ball Material Stainless Steel
  • Cage Material Stainless Steel
  • Dynamic Radial Load 540 lbf
  • Static Radial Load 536 lbf
  • Temperature Range -86 to 230 °F
  • Lubrication Required
  • RoHS Compliant
  • REACH Compliant
  • Max Speed 3690 rpm
  • Weight 64 g
  • Price（$） 2.5
Thin Section Ball Bearings S6710 2rs dimension drawing
Download DWG Download PDF

Features

How Is S6710 2rs Bearing Engineered for Reliability?

S6710 2rs Bearing features stainless steel rings and balls, offering excellent resistance to wear and corrosion.
Its sealed design protects against contaminants, ensuring smooth operation in various environments.
With a dynamic radial load capacity of 540 lbf, it handles moderate loads efficiently.
The bearing operates within a wide temperature range of -86 to 230 °F, making it versatile for different applications.

Why Choose S6710 2rs Bearing for Precision Tasks?

S6710 2rs Bearing is designed with a single-row construction, providing precise radial load support.
Its ABEC-1 tolerance ensures consistent performance, ideal for applications requiring accuracy.
The sealed design keeps lubrication intact, reducing maintenance needs.
With a maximum speed of 3,690 rpm, it balances precision and durability.

Built for Durability: S6710 2rs Bearing

S6710 2rs Bearing is crafted from stainless steel, enhancing its resistance to rust and wear.
The sealed construction prevents dirt and moisture from entering, prolonging its lifespan.
It supports dynamic radial loads up to 540 lbf, making it suitable for various industrial uses.
The bearing’s compact width of 6 mm allows for easy integration into tight spaces.

Application

Common Applications of S6710 2rs Bearing
S6710 2rs Bearing works well in industrial settings, especially for compact machinery where space is limited. Its thin section design fits neatly into tight spots without sacrificing performance.

In automotive applications, S6710 2rs Bearing is often used in small electric motors or gear mechanisms. The sealed design keeps out dust and moisture, making it reliable for long-term use.

For medical devices like portable scanners, S6710 2rs Bearing offers smooth rotation thanks to its stainless steel construction. The ABEC-1 tolerance ensures consistent precision in sensitive equipment.

Automation systems benefit from S6710 2rs Bearing in robotic arms or conveyor guides. Its lightweight design helps reduce overall system load while maintaining stability.

Around the home, S6710 2rs Bearing can be found in appliances like blenders or small fans. The sealed feature means less maintenance and quieter operation over time.
