Thin Section Ball Bearings 6817zz

Thin Section Ball Bearings 6817zz

The 6817zz is a thin-section ball bearing with an 85mm bore and 110mm outer diameter, designed for radial loads. Its compact 13mm width makes it ideal for space-saving applications.

Shielded on both sides, it keeps contaminants out while maintaining smooth operation. The chrome steel construction ensures durability, and it handles speeds up to 6600 RPM.

With a dynamic radial load capacity of 4208 lbf, it’s suited for moderate loads in machinery or automation. The stainless steel cage adds stability during rotation.

This bearing works in temperatures from -30°C to 110°C and requires lubrication for optimal performance. Compliant with RoHS and REACH standards, it’s a reliable choice for industrial use.

Get A Free Quote
    Description Features Application Q&A Featured Products Our Process

Product Parameters

  • Part Number 6817zz
  • Brand TFL
  • Bore Dia 85 mm
  • Bore Dia Tolerance -0.02mm to 0
  • Outer Dia 110 mm
  • Outer Dia Tolerance -0.015mm to 0
  • Width 13 mm
  • Width Tolerance -0.200mm to 0
  • Radial Clearance 0.012mm to 0.036mm
  • System of Measurement Metric
  • Bearing Type Ball
  • For Load Direction Radial
  • Construction Single Row
  • Seal Type Shielded
  • Tolerance Class ABEC-1
  • Radial Clearance Trade No C0
  • Ring Material Chrome Steel
  • Ball Material Chrome Steel
  • Cage Material Stainless Steel
  • Dynamic Radial Load 4208 lbf
  • Static Radial Load 4275 lbf
  • Temperature Range -30°C to 110 °C
  • Lubrication Required
  • RoHS Compliant
  • REACH Compliant
  • Max Speed 6600 rpm
  • Weight 266 g
  • Price（$） 2.8
Thin Section Ball Bearings 6817zz dimension drawing
Download DWG Download PDF

Features

Performance Features of 6817zz Bearing

6817zz Bearing features a compact design with dimensions of 85 mm×110 mm×13 mm, making it ideal for space-constrained applications.
The shielded seal type helps protect against contaminants while maintaining smooth operation.

Constructed from chrome steel rings and balls, 6817zz Bearing offers reliable performance under radial loads.
Its dynamic radial load capacity of 4208 lbf ensures durability in various operating conditions.

With a maximum speed of 6,600 rpm, 6817zz Bearing balances efficiency and longevity.
The stainless steel cage keeps the balls properly aligned, reducing wear and extending service life.

6817zz Bearing operates effectively in temperatures ranging from -30°C to 110°C.
Its ABEC-1 tolerance class ensures consistent performance for precision applications.

Application

Industrial Uses of 6817zz Bearing
6817zz Bearing is commonly used in industrial machinery, such as conveyor systems and packaging equipment, where its thin section design saves space without compromising strength. The shielded seals help keep contaminants out, extending service life in dusty environments.

Where Is 6817zz Bearing Used?
You’ll often find 6817zz Bearing in automation systems, particularly in robotic arms and precision assembly lines, where its smooth rotation is essential. Its metric sizing makes it a versatile fit for various European and Asian machinery standards.

Perfect Fit for Automation: 6817zz Bearing
6817zz Bearing works well in 3D printers and CNC machines, thanks to its low-profile design and reliable radial load capacity. The chrome steel construction ensures durability, even in high-speed applications.

Medical vs Industrial: Where 6817zz Bearing Excels
In medical devices like MRI scanners, 6817zz Bearing provides quiet, precise movement, while in industrial settings, it handles heavier loads in gearboxes and pumps. The stainless steel cage adds corrosion resistance for both environments.

Essential Roles of 6817zz Bearing
6817zz Bearing supports radial loads in electric motors and fans, offering a balance of performance and compactness. Its ABEC-1 tolerance ensures consistent operation, making it a dependable choice for everyday machinery.
