Thin Section Ball Bearings 6810zz

Thin Section Ball Bearings 6810zz

The 6810zz is a slim, shielded ball bearing measuring 50mm by 65mm by 7mm, crafted from sturdy chrome steel for reliable radial load handling. It supports dynamic loads up to 1388 lbf and spins smoothly at speeds reaching 11,000 RPM.

Its stainless steel cage and shielded design help keep dirt out while maintaining smooth operation. The bearing requires lubrication and performs well in temperatures from -30°C to 110°C.

With a compact width of just 7mm, it fits neatly into tight spaces without sacrificing strength. Ideal for applications like small motors or precision equipment where space and performance matter.

Weighing only 52g, it’s lightweight yet durable. Compliant with RoHS and REACH standards, it’s a practical choice for various industrial uses.

Get A Free Quote
    Description Features Application Q&A Featured Products Our Process

Product Parameters

  • Part Number 6810zz
  • Brand TFL
  • Bore Dia 50 mm
  • Bore Dia Tolerance -0.012mm to 0
  • Outer Dia 65 mm
  • Outer Dia Tolerance -0.013mm to 0
  • Width 7 mm
  • Width Tolerance -0.120mm to 0
  • Radial Clearance 0.006mm to 0.023mm
  • System of Measurement Metric
  • Bearing Type Ball
  • For Load Direction Radial
  • Construction Single Row
  • Seal Type Shielded
  • Tolerance Class ABEC-1
  • Radial Clearance Trade No C0
  • Ring Material Chrome Steel
  • Ball Material Chrome Steel
  • Cage Material Stainless Steel
  • Dynamic Radial Load 1388 lbf
  • Static Radial Load 1296 lbf
  • Temperature Range -30°C to 110 °C
  • Lubrication Required
  • RoHS Compliant
  • REACH Compliant
  • Max Speed 11000 rpm
  • Weight 52 g
  • Price（$） 2.3
Thin Section Ball Bearings 6810zz dimension drawing
Download DWG Download PDF

Features

How Does 6810zz Bearing Reduce Friction?

6810zz Bearing features chrome steel rings and balls, designed to minimise friction during radial load operations.
Its shielded construction helps retain lubrication, ensuring smooth and efficient performance over time.
With a maximum speed of 11,000 rpm, it maintains reliability in high-speed applications.
The stainless steel cage provides stability, reducing wear and extending the bearing’s lifespan.

Application

Common Applications of 6810zz Bearing
In industrial machinery, 6810zz Bearing is often used in compact spaces where thin-section design matters, such as packaging equipment or small conveyors. Its shielded seals help keep contaminants out while maintaining smooth rotation.

For automation systems, 6810zz Bearing fits well in robotic joints or linear guides, thanks to its low-profile build and reliable radial load capacity. The chrome steel construction ensures durability even with frequent movement.

In medical devices like dental handpieces, 6810zz Bearing provides quiet operation and precision. The ABEC-1 tolerance makes it suitable for applications where consistent performance is needed without excessive vibration.

Where Is 6810zz Bearing Used?
You’ll find 6810zz Bearing in office printers, where its slim profile supports paper feed mechanisms without adding bulk. The stainless steel cage also helps resist wear from constant use.

In electric scooters, 6810zz Bearing handles wheel rotation smoothly, even at higher speeds. Its lightweight design (just 52g) doesn’t add unnecessary weight to portable devices.

Built for Versatility: 6810zz Bearing
This bearing works well in 3D printers, particularly for guiding belts or pulleys where space is tight. The C0 clearance offers a balance between precision and ease of movement.

For small fans or cooling systems, 6810zz Bearing’s shielded design helps prolong life by reducing dust ingress. The temperature range (-30°C to 110°C) covers most everyday operating conditions.
