Thin Section Ball Bearings 6808zz

Thin Section Ball Bearings 6808zz

The 6808zz is a slim, shielded ball bearing measuring 40mm by 52mm by 7mm, crafted from sturdy chrome steel for durability. It supports radial loads up to 1109 lbf and spins efficiently at speeds up to 14,000 RPM.

With its stainless steel cage and shielded design, it keeps dirt out while maintaining smooth operation. The bearing requires lubrication for optimal performance and works in temperatures from -30°C to 110°C.

Its compact, lightweight design (just 35g) makes it ideal for tight spaces in machinery or small devices. Compliant with RoHS and REACH standards, it’s a reliable choice for various industrial applications.

Get A Free Quote
    Description Features Application Q&A Featured Products Our Process

Product Parameters

  • Part Number 6808zz
  • Brand TFL
  • Bore Dia 40 mm
  • Bore Dia Tolerance -0.012mm to 0
  • Outer Dia 52 mm
  • Outer Dia Tolerance -0.013mm to 0
  • Width 7 mm
  • Width Tolerance -0.120mm to 0
  • Radial Clearance 0.006mm to 0.020mm
  • System of Measurement Metric
  • Bearing Type Ball
  • For Load Direction Radial
  • Construction Single Row
  • Seal Type Shielded
  • Tolerance Class ABEC-1
  • Radial Clearance Trade No C0
  • Ring Material Chrome Steel
  • Ball Material Chrome Steel
  • Cage Material Stainless Steel
  • Dynamic Radial Load 1109 lbf
  • Static Radial Load 940 lbf
  • Temperature Range -30°C to 110 °C
  • Lubrication Required
  • RoHS Compliant
  • REACH Compliant
  • Max Speed 14000 rpm
  • Weight 35 g
  • Price（$） 2.8
Thin Section Ball Bearings 6808zz dimension drawing
Download DWG Download PDF

Features

How Does 6808zz Bearing Reduce Friction?

6808zz Bearing features chrome steel rings and balls, ensuring smooth operation with minimal friction.
Its shielded design helps keep contaminants out, maintaining consistent performance over time.
With a dynamic radial load capacity of 1109 lbf, it handles demanding applications efficiently.
The ABEC-1 tolerance class ensures reliable precision for various industrial uses.

Application

Common Applications of 6808zz Bearing
In industrial settings, 6808zz Bearing is often used in compact machinery like packaging equipment and small conveyors, where its thin section design saves space without compromising performance. The shielded seals help keep contaminants out, extending service life in dusty environments.

Where Is 6808zz Bearing Used?
You’ll find 6808zz Bearing in automotive applications such as electric window mechanisms and small gearboxes, where its radial load capacity and smooth operation are key. Its metric sizing makes it a straightforward fit for many European and Asian vehicle designs.

Perfect Fit for Automation: 6808zz Bearing
6808zz Bearing works well in robotic arms and precision automation systems, thanks to its low-profile design and reliable radial load handling. The stainless steel cage ensures durability even with frequent directional changes.

Light-Duty vs Heavy-Duty: Best Uses for 6808zz Bearing
For light-duty tasks like office printers or small fans, 6808zz Bearing offers quiet operation and efficient performance. In more demanding scenarios, such as medical imaging devices, its chrome steel construction provides the necessary reliability for consistent use.
