Thin Section Ball Bearings 6710zz

Thin Section Ball Bearings 6710zz

The 6710zz is a slim, shielded ball bearing measuring 50mm in bore and 62mm in outer diameter, with a compact width of just 6mm. Made from chrome steel, it offers reliable radial load support up to 601 lbf.

Its single-row design and stainless steel cage ensure smooth rotation at speeds up to 4100 RPM. The shielded seals help keep contaminants out while retaining lubrication.

This bearing operates well in temperatures from -30°C to 110°C, making it suitable for various environments. It’s lightweight at 64g, yet sturdy for its thin profile.

Ideal for applications where space is limited, such as robotics or small machinery. Compliant with RoHS and REACH standards for safe use.

Get A Free Quote
    Description Features Application Q&A Featured Products Our Process

Product Parameters

  • Part Number 6710zz
  • Brand TFL
  • Bore Dia 50 mm
  • Bore Dia Tolerance -0.012mm to 0
  • Outer Dia 62 mm
  • Outer Dia Tolerance -0.013mm to 0
  • Width 6 mm
  • Width Tolerance -0.120mm to 0
  • Radial Clearance 0.006mm to 0.023mm
  • System of Measurement Metric
  • Bearing Type Ball
  • For Load Direction Radial
  • Construction Single Row
  • Seal Type Shielded
  • Tolerance Class ABEC-1
  • Radial Clearance Trade No C0
  • Ring Material Chrome Steel
  • Ball Material Chrome Steel
  • Cage Material Stainless Steel
  • Dynamic Radial Load 601 lbf
  • Static Radial Load 596 lbf
  • Temperature Range -30°C to 110 °C
  • Lubrication Required
  • RoHS Compliant
  • REACH Compliant
  • Max Speed 4100 rpm
  • Weight 64 g
  • Price（$） 2.5
Thin Section Ball Bearings 6710zz dimension drawing
Download DWG Download PDF

Features

How Does 6710zz Bearing Reduce Friction?

6710zz Bearing features a shielded design with chrome steel rings and balls, ensuring smooth radial load handling.
Its ABEC-1 tolerance class and C0 radial clearance provide consistent performance with minimal friction.

The stainless steel cage maintains ball alignment, reducing wear and enhancing durability.
With a maximum speed of 4,100 rpm, it offers reliable operation in various applications.

6710zz Bearing’s compact 6 mm width makes it suitable for space-constrained installations.
Its dynamic radial load capacity of 601 lbf ensures dependable performance under stress.

Application

Common Applications of 6710zz Bearing
6710zz Bearing is widely used in industrial automation, particularly in robotic arms and conveyor systems where its slim profile saves space without compromising performance. The shielded design helps keep contaminants out, extending its service life.

In automotive applications, 6710zz Bearing fits well in compact electric motors and gear mechanisms, thanks to its radial load capacity and precise ABEC-1 tolerance. Its chrome steel construction ensures durability even in demanding conditions.

For medical devices like portable imaging units, 6710zz Bearing offers smooth operation due to its low radial clearance. The stainless steel cage adds corrosion resistance, making it suitable for sterile environments.

In consumer electronics, 6710zz Bearing is often found in printers and small appliances where quiet operation is key. Its lightweight design and reliable performance make it a popular choice for everyday devices.
