Super Precision Angular Contact Ball Bearings S7024 CD/P4ADGB

Super Precision Angular Contact Ball Bearings S7024 CD/P4ADGB

The S7024 CD/P4ADGB is a super precision angular contact ball bearing with a 120mm bore and 180mm outer diameter, crafted from durable chrome steel. It handles radial loads up to 42750 lbf and operates smoothly at speeds up to 10000 RPM.

Its sealed design keeps grease in and contaminants out, while the phenolic cage ensures quiet, long-lasting performance. The 15° contact angle and universal matching allow flexible arrangements like back-to-back or face-to-face.

This bearing is ideal for high-precision applications like machine tool spindles or robotics, where accuracy and reliability are key. It works in temperatures from -30°C to 110°C and comes pre-lubricated for easy installation.

Weighing 4.31kg, it’s robust yet manageable for its size. Compliant with P4A tolerance standards, it’s interchangeable with SKF bearings for hassle-free replacements.

Get A Free Quote
    Description Features Application Q&A Featured Products Our Process

Product Parameters

  • Part Number S7024 CD/P4ADGB
  • Brand TFL
  • Interchangeable SKF
  • Bore Dia 120 mm
  • Bore Dia Tolerance -0.004mm to 0
  • Outer Dia 180 mm
  • Outer Dia Tolerance -0.004mm to 0
  • Width 56 mm
  • Width Tolerance -0.2mm to 0
  • Ball Dia 19.05 mm
  • Ball Qty 22
  • Contact Angle 15°
  • Tolerance Class P4A
  • System of Measurement Metric
  • Seal Type Sealed
  • Matched Arrangement Universal matching
  • Number Of Bearings In Matched Set 2
  • Universal Matching Bearing Yes, back-to-back (<>), face-to-face (><) or tandem (>>)
  • Preload Light / Class B
  • For Load Direction Angular Contact
  • Ring Material Chrome Steel
  • Ball Material Chrome Steel
  • Cage Material Phenolic
  • Dynamic Radial Load 42750 lbf
  • Static Radial Load 55125 lbf
  • Lubrication Grease
  • Temperature Range - 30°C to 110 °C
  • Max Speed 10000 rpm
  • Weight 4.31 kg
Super Precision Angular Contact Ball Bearings S7024 CD/P4ADGB dimension drawing
Download DWG Download PDF
