Super Precision Angular Contact Ball Bearings S7020 ACDGB/P4A

Super Precision Angular Contact Ball Bearings S7020 ACDGB/P4A

The S7020 ACDGB/P4A is a super precision angular contact ball bearing with a 100mm bore and 150mm outer diameter, crafted from high-grade chrome steel. It handles radial loads up to 17842 lbf and operates smoothly at speeds up to 16250 RPM.

Its sealed design keeps grease in and contaminants out, while the phenolic cage ensures quiet, long-lasting performance. The 25° contact angle provides excellent stability for angular loads.

This bearing is part of a universal matching set, allowing flexible arrangements like back-to-back or face-to-face. Ideal for high-precision applications such as machine tool spindles or high-speed rotary tables.

Weighing 1.27kg, it’s designed for temperatures from -30°C to 110°C and meets strict P4A tolerance standards for reliable operation.

Get A Free Quote
    Description Features Application Q&A Featured Products Our Process

Product Parameters

  • Part Number S7020 ACDGB/P4A
  • Brand TFL
  • Interchangeable SKF
  • Bore Dia 100 mm
  • Bore Dia Tolerance -0.004mm to 0
  • Outer Dia 150 mm
  • Outer Dia Tolerance -0.004mm to 0
  • Width 24 mm
  • Width Tolerance -0.2mm to 0
  • Ball Dia 15.875 mm
  • Ball Qty 22
  • Contact Angle 25°
  • Tolerance Class P4A
  • System of Measurement Metric
  • Seal Type Sealed
  • Matched Arrangement No
  • Number Of Bearings In Matched Set 3
  • Universal Matching Bearing Yes, back-to-back (<>), face-to-face (><) or tandem (>>)
  • Preload Light / Class B
  • For Load Direction Angular Contact
  • Ring Material Chrome Steel
  • Ball Material Chrome Steel
  • Cage Material Phenolic
  • Dynamic Radial Load 17842 lbf
  • Static Radial Load 18000 lbf
  • Lubrication Grease
  • Temperature Range - 30°C to 110 °C
  • Max Speed 16250 rpm
  • Weight 1.27 kg
Super Precision Angular Contact Ball Bearings S7020 ACDGB/P4A dimension drawing
Download DWG Download PDF

Features

How Does S7020 ACDGB/P4A Bearing Reduce Friction?

S7020 ACDGB/P4A Bearing features a 25° contact angle, optimising load distribution and reducing friction.
The chrome steel rings and balls ensure smooth operation, even at high speeds of up to 16,250 rpm.

Its phenolic cage minimises heat generation, enhancing efficiency and longevity.
The sealed design keeps lubrication in place, reducing maintenance needs.

With a dynamic radial load capacity of 17,842 lbf, it handles demanding applications with ease.
The P4A tolerance class ensures precision performance in critical setups.

Application

Key Fields for S7020 ACDGB/P4A Bearing
S7020 ACDGB/P4A Bearing is widely used in high-precision machine tools, where its angular contact design ensures accurate spindle rotation. The sealed construction helps maintain performance in environments with dust or debris.

In robotics, S7020 ACDGB/P4A Bearing provides smooth motion control for articulated arms, thanks to its light preload and phenolic cage. Its high-speed capability makes it suitable for automated assembly lines.

For aerospace applications, S7020 ACDGB/P4A Bearing handles radial and axial loads in avionics systems, where reliability is critical. The chrome steel rings and balls offer durability under varying temperatures.

In medical imaging devices, S7020 ACDGB/P4A Bearing ensures quiet and precise movement for components like gantry systems. The P4A tolerance class guarantees consistent performance over long periods.

S7020 ACDGB/P4A Bearing is also found in electric vehicle motors, supporting high-speed rotation with minimal friction. Its grease lubrication reduces maintenance needs in demanding automotive conditions.
