Super Precision Angular Contact Ball Bearings S7014 FEGB/P4A

Super Precision Angular Contact Ball Bearings S7014 FEGB/P4A

The S7014 FEGB/P4A is a super precision angular contact ball bearing with a 70mm bore and 110mm outer diameter, crafted from durable chrome steel. Its compact 20mm width makes it suitable for tight spaces while maintaining high performance.

With a contact angle of 18°, it handles both radial and axial loads efficiently, supporting up to 5265 lbf dynamically. It spins smoothly at speeds up to 22,000 RPM, thanks to its phenolic cage and grease lubrication.

The sealed design keeps contaminants out, extending its lifespan in harsh conditions. It operates reliably in temperatures from -30°C to 110°C, making it versatile for various environments.

Ideal for precision applications like machine tool spindles or high-speed equipment. Weighing 0.64kg, it offers a good balance of strength and lightness. Compliant with P4A tolerance class for exceptional accuracy.

Get A Free Quote
    Description Features Application Q&A Featured Products Our Process

Product Parameters

  • Part Number S7014 FEGB/P4A
  • Brand TFL
  • Interchangeable SKF
  • Bore Dia 70 mm
  • Bore Dia Tolerance -0.004mm to 0
  • Outer Dia 110 mm
  • Outer Dia Tolerance -0.004mm to 0
  • Width 20 mm
  • Width Tolerance -0.2mm to 0
  • Ball Dia 9.525 mm
  • Ball Qty 25
  • Contact Angle 18°
  • Tolerance Class P4A
  • System of Measurement Metric
  • Seal Type Sealed
  • Matched Arrangement No
  • Number Of Bearings In Matched Set 2
  • Universal Matching Bearing Yes, back-to-back (<>), face-to-face (><) or tandem (>>)
  • Preload Light / Class B
  • For Load Direction Angular Contact
  • Ring Material Chrome Steel
  • Ball Material Chrome Steel
  • Cage Material Phenolic
  • Dynamic Radial Load 5265 lbf
  • Static Radial Load 4118 lbf
  • Lubrication Grease
  • Temperature Range - 30°C to 110 °C
  • Max Speed 22000 rpm
  • Weight 0.64 kg
  • Price（$） 132.975
Super Precision Angular Contact Ball Bearings S7014 FEGB/P4A dimension drawing
Download DWG Download PDF

Features

Performance Features of S7014 FEGB/P4A Bearing

S7014 FEGB/P4A Bearing is crafted with chrome steel rings and balls, offering excellent durability for precision tasks.
Its 18° contact angle ensures optimal load distribution, enhancing performance in angular contact applications.

The phenolic cage maintains ball alignment, reducing friction and noise during high-speed operation.
With a maximum speed of 22,000 rpm, it delivers smooth and efficient performance.

S7014 FEGB/P4A Bearing’s sealed design protects against contaminants, extending its service life.
Its light preload and P4A tolerance class ensure consistent accuracy in demanding conditions.

The bearing’s dynamic radial load capacity of 5265 lbf makes it suitable for heavy-duty applications.
Its grease lubrication simplifies maintenance while ensuring reliable operation.

S7014 FEGB/P4A Bearing operates in temperatures from -30°C to 110°C, adapting to various environments.
Its universal matching capability allows flexible configurations for different setups.

Application

Key Fields for S7014 FEGB/P4A Bearing
S7014 FEGB/P4A Bearing is commonly used in high-speed machine tools, where its precision angular contact design ensures accurate spindle rotation. The sealed construction helps keep contaminants out, extending service life in demanding workshop conditions.

In automotive applications, S7014 FEGB/P4A Bearing supports wheel hubs and transmission systems, handling both radial and axial loads efficiently. Its light preload and P4A tolerance make it suitable for performance vehicles requiring smooth operation.

For robotics, S7014 FEGB/P4A Bearing provides reliable motion control in articulated arms and joints. The phenolic cage material reduces friction, allowing for quiet operation in automated assembly lines.

Medical imaging devices benefit from S7014 FEGB/P4A Bearing’s stable performance at various speeds. The chrome steel construction maintains precision in sensitive equipment like CT scanners and MRI machines.

In aerospace applications, S7014 FEGB/P4A Bearing handles the rigorous demands of flight control systems. Its temperature stability and grease lubrication ensure consistent performance from -30°C to 110°C.
