Super Precision Angular Contact Ball Bearings S7014 FE/P4ADT

Brand: TFL Bearing Interchangeable: SKF S7014 FE/P4ADT 70 mm × 110 mm × 40 mm Metric Sealed
Part number: S7014 FE/P4ADT
Super Precision Angular Contact Ball Bearings S7014 FE/P4ADT
In Stock
Price on request
Send your part number and quantity for a quote
Get a Quote WhatsApp
  • ISO 9001 quality system
  • Pre-shipment inspection
  • Lead time confirmed with your quote
Dimensions
Bore Dia70 mm
Bore Dia Tolerance-0.004mm to 0
Outer Dia110 mm
Outer Dia Tolerance-0.004mm to 0
Width40 mm
Width Tolerance-0.2mm to 0
Ball Dia9.525 mm
Performance
PreloadAvailable
Dynamic Radial Load8,482 lbf
Static Radial Load8,212 lbf
Temperature Range- 30°C to 110 °C
Max Speed22,000 rpm
Characteristics
Ball Qty25
Contact Angle18°
Tolerance ClassP4A
System of MeasurementMetric
Seal TypeSealed
Matched Arrangement2 bearings << DT
Number Of Bearings In Matched Set2
Universal Matching BearingNo
For Load DirectionAngular Contact
LubricationGrease
Weight1.28 kg
Material
Ring MaterialChrome Steel
Ball MaterialChrome Steel
Cage MaterialPhenolic
Dimension drawing · click to enlarge

Description

The S7014 FE/P4ADT is a super precision angular contact ball bearing with a 70mm bore and 110mm outer diameter, crafted from durable chrome steel. It features an 18° contact angle and comes sealed for protection, with two bearings in a matched <<DT arrangement. This model handles radial loads up to 8482 lbf and spins smoothly at speeds up to 22,000 RPM. Its phenolic cage ensures quiet operation and long service life, even under preload conditions. The sealed design keeps grease in and contaminants out, making maintenance hassle-free. It operates reliably in temperatures from -30°C to 110°C, suitable for demanding environments. Ideal for high-precision applications like machine tool spindles or robotics, where accuracy and speed are critical. Weighing 1.28kg, it’s robust yet manageable for its size. Interchangeable with SKF bearings for easy replacement.

Features

Performance Features of S7014 FE/P4ADT Bearing

S7014 FE/P4ADT Bearing is crafted with chrome steel rings and balls, ensuring high precision and durability.
Its 18° contact angle provides optimal load distribution, making it suitable for angular contact applications.
The phenolic cage enhances stability, reducing friction and noise during high-speed operation.
With a maximum speed of 22,000 rpm, it delivers reliable performance in demanding conditions.

Application

Key Fields for S7014 FE/P4ADT Bearing
S7014 FE/P4ADT Bearing is commonly used in high-precision machine tools, where its angular contact design ensures accurate spindle rotation. The sealed construction helps maintain performance in environments with dust or debris.

What Makes S7014 FE/P4ADT Bearing a Preferred Choice?
In robotics, S7014 FE/P4ADT Bearing provides smooth motion control for articulated arms, thanks to its matched arrangement and preload capability. The phenolic cage reduces friction, enhancing efficiency in repetitive movements.

Built for Heavy-Duty Use: S7014 FE/P4ADT Bearing
For automotive applications like electric vehicle motors, S7014 FE/P4ADT Bearing handles combined radial and axial loads reliably. Its grease lubrication ensures long service life even at high speeds.

Medical vs Industrial: Where S7014 FE/P4ADT Bearing Excels
In medical imaging devices, S7014 FE/P4ADT Bearing offers quiet operation and precision, critical for diagnostic accuracy. Industrial pumps benefit from its robust construction and tolerance for continuous operation.

Perfect Fit for Automation: S7014 FE/P4ADT Bearing
S7014 FE/P4ADT Bearing is ideal for CNC machinery, where its P4A tolerance class ensures minimal vibration. The chrome steel rings and balls provide durability under heavy cutting loads.
