Super Precision Angular Contact Ball Bearings S7013 CE/P4BVG275

Super Precision Angular Contact Ball Bearings S7013 CE/P4BVG275

The S7013 CE/P4BVG275 is a super precision angular contact ball bearing with a 65mm bore and 100mm outer diameter, crafted from durable chrome steel. Its 15° contact angle and sealed design ensure smooth operation under angular loads.

With a dynamic radial load capacity of 4568 lbf and speeds up to 19,000 RPM, it performs reliably in demanding conditions. The phenolic cage adds strength while keeping the bearing lightweight at just 0.45kg.

Preload and matched arrangements are available for enhanced stability in high-precision applications. Ideal for machine tools or spindle systems where accuracy is key.

Operating between -30°C to 110°C, this bearing meets P4 tolerance standards (ABEC-7) for consistent performance. Interchangeable with SKF models for easy replacement.

Get A Free Quote
    Description Features Application Q&A Featured Products Our Process

Product Parameters

  • Part Number S7013 CE/P4BVG275
  • Brand TFL
  • Interchangeable SKF
  • Bore Dia 65 mm
  • Bore Dia Tolerance -0.007mm to 0
  • Outer Dia 100 mm
  • Outer Dia Tolerance -0.008mm to 0
  • Width 18 mm
  • Width Tolerance -0.2mm to 0
  • Ball Dia 8.731 mm
  • Ball Qty 25
  • Contact Angle 15°
  • Tolerance Class P4 (ABEC-7)
  • System of Measurement Metric
  • Seal Type Sealed
  • Matched Arrangement Available
  • Preload Available
  • For Load Direction Angular Contact
  • Ring Material Chrome Steel
  • Ball Material Chrome Steel
  • Cage Material Phenolic
  • Dynamic Radial Load 4568 lbf
  • Static Radial Load 3510 lbf
  • Lubrication Lubricated
  • Temperature Range -30° to 110 °C
  • Max Speed 19000 rpm
  • Weight 0.45 kg
  • Price（$） 515.241
Super Precision Angular Contact Ball Bearings S7013 CE/P4BVG275 dimension drawing
Download DWG Download PDF

Features

Why Choose S7013 CE/P4BVG275 Bearing for Precision Tasks?

S7013 CE/P4BVG275 Bearing features a 15° contact angle, optimised for high-precision angular contact applications.
Its chrome steel rings and balls ensure durability, while the phenolic cage reduces friction for smoother operation.

With a dynamic radial load capacity of 4568 lbf, it handles demanding tasks reliably.
The P4 tolerance class (ABEC-7) guarantees exceptional precision, making it suitable for high-speed applications up to 19,000 rpm.

Sealed design and built-in lubrication enhance its performance in varied temperature ranges (-30° to 110°C).
This reduces maintenance needs while ensuring consistent operation over time.

Application

Industrial Uses of S7013 CE/P4BVG275 Bearing
S7013 CE/P4BVG275 Bearing is commonly used in high-speed machine tools, where its precision and angular contact design ensure accurate performance. The sealed construction helps maintain lubrication, reducing maintenance needs in demanding environments.

What Makes S7013 CE/P4BVG275 Bearing a Preferred Choice?
In automotive applications, S7013 CE/P4BVG275 Bearing supports components like electric motors and transmissions, thanks to its high-speed capability and durability. The phenolic cage adds stability, making it suitable for varied temperature conditions.

Perfect Fit for Automation: S7013 CE/P4BVG275 Bearing
For robotics and automation systems, S7013 CE/P4BVG275 Bearing provides smooth motion control in robotic arms and CNC machines. Its P4 tolerance class ensures minimal vibration, enhancing operational precision.

Medical vs Industrial: Where S7013 CE/P4BVG275 Bearing Excels
In medical imaging devices, S7013 CE/P4BVG275 Bearing offers reliable performance with low noise, crucial for sensitive equipment. Meanwhile, in industrial settings, its robust design handles heavy loads with ease.
