Super Precision Angular Contact Ball Bearings 7026 CD/P4ADGA

Super Precision Angular Contact Ball Bearings 7026 CD/P4ADGA

The 7026 CD/P4ADGA is a super precision angular contact ball bearing with a 130mm bore and 200mm outer diameter, crafted from high-quality chrome steel. Its 15° contact angle and extra light preload ensure smooth operation under radial and angular loads.

This bearing can handle dynamic radial loads up to 54450 lbf and spins efficiently at speeds up to 11000 RPM. The phenolic cage offers durability while keeping the weight manageable at 6.47kg.

Its universal matching design allows flexible arrangements like back-to-back or face-to-face, making it versatile for various setups. The open seal type simplifies maintenance and lubrication.

Ideal for high-precision applications such as machine tool spindles or industrial pumps, it performs reliably in temperatures from -30°C to 110°C. Compliant with P4A tolerance class for exceptional accuracy.

Weighing 6.47kg, it’s robust yet suitable for demanding environments. Interchangeable with SKF bearings, offering a practical replacement option.

Get A Free Quote
    Description Features Application Q&A Featured Products Our Process

Product Parameters

  • Part Number 7026 CD/P4ADGA
  • Brand TFL
  • Interchangeable SKF
  • Bore Dia 130 mm
  • Bore Dia Tolerance -0.004mm to 0
  • Outer Dia 200 mm
  • Outer Dia Tolerance -0.004mm to 0
  • Width 66 mm
  • Width Tolerance -0.2mm to 0
  • Ball Dia 22.225 mm
  • Ball Qty 21
  • Contact Angle 15°
  • Tolerance Class P4A
  • System of Measurement Metric
  • Seal Type Open
  • Matched Arrangement Universal matching
  • Number Of Bearings In Matched Set 2
  • Universal Matching Bearing Yes, back-to-back (<>), face-to-face (><) or tandem (>>)
  • Preload Extra light / Class A
  • For Load Direction Angular Contact
  • Ring Material Chrome Steel
  • Ball Material Chrome Steel
  • Cage Material Phenolic
  • Dynamic Radial Load 54450 lbf
  • Static Radial Load 69750 lbf
  • Lubrication Lubricated
  • Temperature Range - 30°C to 110 °C
  • Max Speed 11000 rpm
  • Weight 6.47 kg
  • Price（$） 121.131
Super Precision Angular Contact Ball Bearings 7026 CD/P4ADGA dimension drawing
Download DWG Download PDF

Features

Performance Features of 7026 CD/P4ADGA Bearing

7026 CD/P4ADGA Bearing is crafted with chrome steel rings and balls, offering high precision for angular contact applications.
Its 15° contact angle ensures optimal load distribution, enhancing performance in demanding setups.

The phenolic cage maintains ball alignment, reducing friction and extending operational life.
With a dynamic radial load capacity of 54,450 lbf, it handles heavy loads reliably.

Designed for universal matching, 7026 CD/P4ADGA Bearing supports various configurations like back-to-back or tandem arrangements.
Its extra light preload (Class A) ensures smooth operation at speeds up to 11,000 rpm.

The open design allows easy lubrication, maintaining efficiency across a temperature range of -30°C to 110°C.
This makes 7026 CD/P4ADGA Bearing suitable for high-speed, precision environments.

Application

Industrial Uses of 7026 CD/P4ADGA Bearing
This bearing is commonly used in high-precision machine tools, where its angular contact design ensures accurate spindle rotation. The universal matching feature allows flexible arrangement in back-to-back or face-to-face configurations.

Where Is 7026 CD/P4ADGA Bearing Used?
You’ll find it in automotive testing equipment, supporting smooth operation under radial and axial loads. Its phenolic cage reduces friction, making it suitable for high-speed applications.

Built for Heavy-Duty Use: 7026 CD/P4ADGA Bearing
It handles heavy loads in industrial gearboxes, thanks to its chrome steel construction. The extra-light preload ensures minimal vibration, even at maximum speeds.

Automotive vs Aerospace: Applications of 7026 CD/P4ADGA Bearing
In automotive systems, it’s ideal for wheel hubs and transmissions, while aerospace uses include actuator systems. The P4A tolerance class guarantees precision in both fields.

Perfect Fit for Automation: 7026 CD/P4ADGA Bearing
Robotic arms benefit from its low-friction design and high-speed capability. The matched set simplifies installation, reducing downtime in production lines.
