Standard Flanged Ball Bearings F6806

Standard Flanged Ball Bearings F6806

The F6806 is a compact flanged ball bearing with a 30mm bore and 42mm outer diameter, measuring just 7mm in width. Made from chrome steel, it’s designed for radial loads up to 1000 lbf and can handle speeds up to 15000 RPM.

Its open design allows for easy lubrication, while the stainless steel cage ensures durability. The flange adds stability, making it easier to mount in tight spaces.

This bearing operates smoothly in temperatures from -30°C to 110°C, suitable for various industrial applications. Ideal for small machinery or equipment where space is limited but performance is key.

Compliant with RoHS and REACH standards, it’s a reliable choice for engineers and maintenance teams. The ABEC-1 tolerance ensures consistent performance without unnecessary complexity.

Get A Free Quote
    Description Features Application Q&A Featured Products Our Process

Product Parameters

  • Part Number F6806
  • Brand TFL
  • Bore Dia 30 mm
  • Bore Dia Tolerance -0.010mm to 0
  • Outer Dia 42 mm
  • Outer Dia Tolerance -0.011 mm to 0
  • Width 7 mm
  • Width Tolerance -0.12 mm to 0
  • Flange Outer Dia 45 mm
  • Flange Thickness 1.5 mm
  • Ball Qty 16
  • Ball Dia 3.5 mm
  • Radial Clearance 0.002mm to 0.013mm
  • Tolerance Class ABEC-1
  • Radial Clearance Trade No C0
  • System of Measurement Metric
  • Bearing Type Ball
  • For Load Direction Radial
  • Construction Single Row
  • Inner Ring Type Standard
  • Seal Type Open
  • Ring Material Chrome Steel
  • Ball Material Chrome Steel
  • Cage Material Stainless Steel
  • Shield Material 300 Series Stainless Steel
  • Dynamic Radial Load 1000 lbf
  • Static Radial Load 773 lbf
  • Lubrication Required
  • Temperature Range -30° to 110°C
  • RoHS Compliant
  • REACH Compliant
  • Max Speed 15000 rpm
  • Price（$） 3.9
Standard Flanged Ball Bearings F6806 dimension drawing
Download DWG Download PDF

Features

How Does F6806 Bearing Reduce Friction?

F6806 Bearing features chrome steel rings and balls, ensuring smooth operation with minimal friction.
Its precision design includes 16 balls, each 3.5 mm in diameter, for balanced load distribution.

The stainless steel cage maintains ball alignment, reducing wear and enhancing efficiency.
With a maximum speed of 15,000 rpm, F6806 Bearing is ideal for high-speed applications.

Its open design allows for easy lubrication, further reducing friction and extending service life.
The ABEC-1 tolerance class ensures consistent performance in radial load conditions.

Application

Essential Roles of F6806 Bearing
F6806 Bearing is commonly used in industrial equipment like conveyor systems and small gearboxes, where its compact flanged design helps with precise alignment. The chrome steel construction ensures durability in continuous operation.

In automotive applications, F6806 Bearing fits well in electric motors and transmission systems, offering reliable radial load support. Its metric sizing makes it compatible with various vehicle components.

For automation projects, F6806 Bearing works smoothly in robotic arms and 3D printers, thanks to its low-friction performance. The open seal design allows for easy lubrication maintenance.

Around the home, F6806 Bearing can be found in appliances like cooling fans and small power tools. Its stainless steel cage resists wear, even with frequent use.

Medical devices like lab equipment benefit from F6806 Bearing’s consistent performance and ABEC-1 tolerance. The smooth operation is crucial for precision instruments.
