Stainless Steel Deep Groove Ball Bearings W 6209-2RS1/VT378

Stainless Steel Deep Groove Ball Bearings W 6209-2RS1/VT378

The W 6209-2RS1/VT378 is a stainless steel deep groove ball bearing with a 45mm bore and 85mm outer diameter, measuring 19mm in width. Its sealed design keeps out dust and moisture, making it low-maintenance.

This bearing handles radial loads up to 6317 lbf and can spin at speeds up to 11000 RPM. The stainless steel construction offers good corrosion resistance for harsh environments.

With ABEC 1 precision and ISO P0 tolerance, it provides reliable performance for general applications. The chrome steel cage adds durability under continuous use.

Suitable for use in food processing equipment or marine applications where rust resistance is needed. It operates in temperatures from -30°C to 120°C and weighs 0.37kg.

Get A Free Quote
    Description Features Application Q&A Featured Products Our Process

Product Parameters

  • Part Number W 6209-2RS1/VT378
  • Brand TFL
  • Interchangeable SKF
  • Bore Dia 45 mm
  • Bore Dia Tolerance -0.012mm to 0
  • Outer Dia 85 mm
  • Outer Dia Tolerance -0.015mm to 0
  • Width 19 mm
  • Width Tolerance -0.12mm to 0
  • System of Measurement Metric
  • Bearing Type Ball
  • For Load Direction Radial
  • Construction Single Row
  • Seal Type Sealed
  • Tolerance Class ABEC 1 | ISO P0
  • Radial Clearance Trade No CN
  • Ring Material Stainless Steel
  • Ball Material Stainless Steel
  • Cage Material Chrome Steel
  • Dynamic Radial Load 6317 lbf
  • Static Radial Load 4586 lbf
  • Temperature Range -30°to 120 °C
  • REACH Compliant
  • Max Speed 11000 rpm
  • Weight 0.37 kg
  • Price（$） 139.83
Stainless Steel Deep Groove Ball Bearings W 6209-2RS1/VT378 dimension drawing
Download DWG Download PDF

Features

Why Choose W 6209-2RS1/VT378 Bearing for Precision Tasks?

W 6209-2RS1/VT378 Bearing is crafted with stainless steel rings and balls, offering excellent resistance to corrosion and wear.
Its sealed design ensures protection against dust and moisture, making it suitable for various environments.

The bearing handles dynamic radial loads up to 6317 lbf, providing reliable performance in demanding applications.
With a maximum speed of 11,000 rpm, it balances efficiency and durability for precision tasks.

W 6209-2RS1/VT378 Bearing’s ABEC 1 tolerance ensures consistent performance, ideal for applications requiring accuracy.
The chrome steel cage maintains ball alignment, reducing friction and extending service life.

Application

Industrial Uses of W 6209-2RS1/VT378 Bearing
W 6209-2RS1/VT378 Bearing is commonly used in industrial machinery, especially in environments where corrosion resistance is needed. Its sealed design helps keep contaminants out, making it reliable for long-term use.

Where Is W 6209-2RS1/VT378 Bearing Used?
In automotive applications, W 6209-2RS1/VT378 Bearing works well in electric motors and pumps due to its stainless steel construction. The ABEC 1 tolerance ensures smooth operation under radial loads.

Perfect Fit for Automation: W 6209-2RS1/VT378 Bearing
This bearing fits nicely in robotic arms and conveyor systems, where its durability and low maintenance are key. The chrome steel cage adds extra strength for high-speed operations.

Medical vs Industrial: Where W 6209-2RS1/VT378 Bearing Excels
While suitable for industrial gear, W 6209-2RS1/VT378 Bearing also performs well in medical devices like lab equipment. Its temperature range allows for stable performance in varied conditions.
