Stainless Steel Deep Groove Ball Bearings W 61701

Stainless Steel Deep Groove Ball Bearings W 61701

The W 61701 is a compact stainless steel deep groove ball bearing, measuring 12mm by 18mm by 4mm. It handles radial loads up to 118 lbf and spins smoothly at speeds up to 48,000 RPM.

Made entirely from stainless steel, it resists corrosion and works in temperatures from -30°C to 120°C. Its open design allows for easy lubrication when needed.

This single-row bearing is interchangeable with SKF models, making it a practical choice for replacements. Ideal for small machinery or instruments where space is limited.

Weighing just 0.0026kg, it’s lightweight yet durable. Compliant with RoHS and REACH standards for safe use.

Get A Free Quote
    Description Features Application Q&A Featured Products Our Process

Product Parameters

  • Part Number W 61701
  • Brand TFL
  • Interchangeable SKF
  • Bore Dia 12 mm
  • Bore Dia Tolerance -0.008mm to 0
  • Outer Dia 18 mm
  • Outer Dia Tolerance -0.008mm to 0
  • Width 4 mm
  • Width Tolerance -0.12mm to 0
  • System of Measurement Metric
  • Bearing Type Ball
  • For Load Direction Radial
  • Construction Single Row
  • Seal Type Open
  • Tolerance Class P0
  • Radial Clearance Trade No CN
  • Ring Material Stainless Steel
  • Ball Material Stainless Steel
  • Cage Material Stainless Steel
  • Dynamic Radial Load 118 lbf
  • Static Radial Load 60 lbf
  • Temperature Range -30° to 120 °C
  • RoHS Compliant
  • REACH Compliant
  • Max Speed 48000 rpm
  • Weight 0.0026 kg
Stainless Steel Deep Groove Ball Bearings W 61701 dimension drawing
Download DWG Download PDF

Features

Why Choose W 61701 Bearing for Precision Tasks?

W 61701 Bearing is crafted from stainless steel, offering excellent resistance to corrosion and wear.
Its compact size of 12 mm×18 mm×4 mm makes it ideal for applications where space is limited.

The open design allows for easy lubrication, ensuring smooth operation even at high speeds.
With a maximum speed of 48,000 rpm, it delivers reliable performance in precision instruments.

W 61701 Bearing’s single-row construction provides consistent radial load support.
Its dynamic radial load capacity of 118 lbf ensures durability in various applications.

The stainless steel cage maintains ball alignment, reducing friction and noise.
This makes W 61701 Bearing a practical choice for quiet and efficient operation.

Application

Industrial Uses of W 61701 Bearing
W 61701 Bearing is commonly used in small industrial equipment like compact pumps and electric motors, where its stainless steel construction resists corrosion in humid environments.
The open design allows for easy lubrication, extending its lifespan in continuous operation scenarios.

What Makes W 61701 Bearing a Preferred Choice?
In automotive applications, W 61701 Bearing fits well in small electric components such as window regulators or wiper motors.
Its metric sizing ensures compatibility with a variety of international vehicle designs.

Perfect Fit for Automation: W 61701 Bearing
For automated systems, W 61701 Bearing works efficiently in robotic arms and small conveyor belts due to its lightweight and durable build.
The high-speed capability makes it suitable for precision tasks in manufacturing lines.

Medical vs Industrial: Where W 61701 Bearing Excels
In medical devices, W 61701 Bearing is often found in handheld surgical tools where hygiene and reliability are key.
Its stainless steel material meets strict cleanliness standards while maintaining smooth operation.

Key Fields for W 61701 Bearing
Consumer electronics like small fans and printers benefit from W 61701 Bearing’s compact size and quiet performance.
The low maintenance requirement makes it ideal for household devices that need long-term reliability.
