Stainless Steel Deep Groove Ball Bearings W 617/6

Stainless Steel Deep Groove Ball Bearings W 617/6

The W 617/6 is a compact stainless steel deep groove ball bearing, measuring just 6mm by 10mm by 2.5mm. Its single-row design handles radial loads up to 64 lbf and spins smoothly at speeds up to 75,000 RPM.

Made entirely from stainless steel, it resists corrosion and works in temperatures from -30°C to 120°C. The open design allows easy access for lubrication when needed.

This bearing is interchangeable with SKF models, making it a practical choice for replacements. Ideal for small devices like medical instruments or precision tools where space is limited.

Weighing only 0.0006kg, it’s lightweight yet durable. Compliant with RoHS and REACH standards for safe use in various applications.

Get A Free Quote
    Description Features Application Q&A Featured Products Our Process

Product Parameters

  • Part Number W 617/6
  • Brand TFL
  • Interchangeable SKF
  • Bore Dia 6 mm
  • Bore Dia Tolerance -0.008mm to 0
  • Outer Dia 10 mm
  • Outer Dia Tolerance -0.008mm to 0
  • Width 2.5 mm
  • Width Tolerance -0.12mm to 0
  • System of Measurement Metric
  • Bearing Type Ball
  • For Load Direction Radial
  • Construction Single Row
  • Seal Type Open
  • Tolerance Class P0
  • Radial Clearance Trade No CN
  • Ring Material Stainless Steel
  • Ball Material Stainless Steel
  • Cage Material Stainless Steel
  • Dynamic Radial Load 64 lbf
  • Static Radial Load 25 lbf
  • Temperature Range -30° to 120 °C
  • RoHS Compliant
  • REACH Compliant
  • Max Speed 75000 rpm
  • Weight 0.0006 kg
Stainless Steel Deep Groove Ball Bearings W 617/6 dimension drawing
Download DWG Download PDF

Features

How Does W 617/6 Bearing Reduce Friction?

W 617/6 Bearing features a stainless steel construction, ensuring smooth operation with minimal friction.

Its single-row deep groove design enhances radial load distribution, improving efficiency in compact applications.

The open seal type allows for easy lubrication, maintaining performance over time.

With a maximum speed of 75,000 rpm, it delivers reliable performance in high-speed scenarios.

Application

Where Is W 617/6 Bearing Used?
W 617/6 Bearing is commonly found in small electric motors, such as those used in cooling fans or miniature appliances. Its compact size and stainless steel construction make it ideal for tight spaces where corrosion resistance is needed.

In medical devices like dental handpieces or laboratory equipment, W 617/6 Bearing ensures smooth, quiet operation. The open design allows for easy cleaning, which is essential in sterile environments.

For precision instruments like optical devices or small gauges, W 617/6 Bearing provides reliable radial load support. Its lightweight design helps maintain accuracy without adding unnecessary bulk.

Automotive applications, such as sensors or small actuators, benefit from W 617/6 Bearing’s durability. The high-speed capability ensures consistent performance even in demanding conditions.

In consumer electronics like cameras or handheld gadgets, W 617/6 Bearing offers long-lasting performance. The stainless steel materials prevent wear and extend the lifespan of delicate components.
