Stainless Steel Deep Groove Ball Bearings W 608/W64

Stainless Steel Deep Groove Ball Bearings W 608/W64

The W 608/W64 is a compact stainless steel deep groove ball bearing, measuring 8mm by 22mm by 7mm. It handles radial loads up to 447 lbf and spins smoothly at speeds up to 48,000 RPM.

Its open design and solid oil lubrication make maintenance simple, while the stainless steel construction resists corrosion. The bearing operates well in temperatures from -30°C to 120°C.

This model is interchangeable with SKF bearings, offering a reliable replacement option. It’s suitable for small machinery, electric motors, or appliances where corrosion resistance is needed.

Weighing just 0.011kg, it’s lightweight yet durable for its size. Compliant with REACH standards for safe use.

Get A Free Quote
    Description Features Application Q&A Featured Products Our Process

Product Parameters

  • Part Number W 608/W64
  • Brand TFL
  • Interchangeable SKF
  • Bore Dia 8 mm
  • Bore Dia Tolerance -0.008mm to 0
  • Outer Dia 22 mm
  • Outer Dia Tolerance -0.009mm to 0
  • Width 7 mm
  • Width Tolerance -0.12mm to 0
  • System of Measurement Metric
  • Bearing Type Ball
  • For Load Direction Radial
  • Construction Single Row
  • Seal Type Open
  • Tolerance Class ABEC 1 | ISO P0
  • Radial Clearance Trade No CN
  • Ring Material Stainless Steel
  • Ball Material Stainless Steel
  • Cage Material Chrome Steel
  • Dynamic Radial Load 447 lbf
  • Static Radial Load 175 lbf
  • Temperature Range -30°to 120 °C
  • Lubrication Soild Oil
  • REACH Compliant
  • Max Speed 48000 rpm
  • Weight 0.011 kg
Stainless Steel Deep Groove Ball Bearings W 608/W64 dimension drawing
Download DWG Download PDF

Features

Why Choose W 608/W64 Bearing for Precision Tasks?

W 608/W64 Bearing is crafted with stainless steel rings and balls, ensuring smooth radial load handling.
Its dynamic radial load capacity of 447 lbf makes it suitable for various applications.
The chrome steel cage maintains ball alignment, enhancing durability and reducing friction.
With a maximum speed of 48,000 rpm, it offers efficient performance in precision tasks.

Application

Common Applications of W 608/W64 Bearing
W 608/W64 Bearing is widely used in small electric motors, such as those found in household appliances like fans and blenders. Its stainless steel construction makes it resistant to corrosion, ideal for damp environments.

In automation systems, W 608/W64 Bearing ensures smooth operation in lightweight robotic arms and conveyor belts. The open design allows for easy lubrication, extending its service life in continuous-use scenarios.

For medical devices, W 608/W64 Bearing provides reliable performance in equipment like dental drills and lab instruments. The solid oil lubrication reduces maintenance needs, ensuring consistent operation in sterile environments.

Where Is W 608/W64 Bearing Used?
You’ll often find W 608/W64 Bearing in office equipment like printers and scanners, where its compact size and quiet operation are valued. The ABEC 1 tolerance ensures sufficient precision for these applications.

In DIY tools, W 608/W64 Bearing is a go-to choice for rotary tools and small grinders. Its durability and affordability make it popular among hobbyists and professionals alike.

Built for Versatility: W 608/W64 Bearing
W 608/W64 Bearing fits perfectly in skateboards and inline skates, offering smooth rolling with minimal friction. The stainless steel balls withstand outdoor conditions without rusting.

In food processing equipment, W 608/W64 Bearing meets hygiene standards while handling light radial loads. Its easy-to-clean design is a plus in washdown environments.

Light-Duty vs Heavy-Duty: Best Uses for W 608/W64 Bearing
For light-duty tasks like model-making machinery, W 608/W64 Bearing provides just the right balance of precision and affordability. The 48,000 rpm max speed handles high-speed rotations effortlessly.

In contrast, avoid overloading W 608/W64 Bearing in heavy industrial settings—it’s better suited for smaller, frequent-motion applications like packaging machines. The 7mm width keeps it compact yet functional.
