Stainless Steel Deep Groove Ball Bearings W 608-2Z

Stainless Steel Deep Groove Ball Bearings W 608-2Z

The W 608-2Z is a compact stainless steel deep groove ball bearing, measuring 8mm by 22mm by 7mm. It handles radial loads up to 447 lbf and spins smoothly at speeds up to 38,000 RPM.

Its shielded design keeps dirt out while retaining grease, making it low-maintenance. The all-stainless construction resists corrosion and suits wet or harsh environments.

This bearing fits standard 8mm shafts and is interchangeable with SKF models. Ideal for small machinery, electric motors, or food processing equipment where hygiene matters.

Weighing just 12 grams, it’s lightweight yet durable. Works in temperatures from -30°C to 120°C and meets RoHS/REACH standards.

Get A Free Quote
    Description Features Application Q&A Featured Products Our Process

Product Parameters

  • Part Number W 608-2Z
  • Brand TFL
  • Interchangeable SKF
  • Bore Dia 8 mm
  • Bore Dia Tolerance -0.008mm to 0
  • Outer Dia 22 mm
  • Outer Dia Tolerance -0.009mm to 0
  • Width 7 mm
  • Width Tolerance -0.12mm to 0
  • System of Measurement Metric
  • Bearing Type Ball
  • For Load Direction Radial
  • Construction Single Row
  • Seal Type Shielded
  • Tolerance Class P0
  • Radial Clearance Trade No CN
  • Ring Material Stainless Steel
  • Ball Material Stainless Steel
  • Cage Material Stainless Steel
  • Dynamic Radial Load 447 lbf
  • Static Radial Load 175 lbf
  • Temperature Range -30° to 120 °C
  • Lubrication Grease
  • RoHS Compliant
  • REACH Compliant
  • Max Speed 38000 rpm
  • Weight 0.012 kg
  • Price（$） 3.59
Stainless Steel Deep Groove Ball Bearings W 608-2Z dimension drawing
Download DWG Download PDF

Features

Why Choose W 608-2Z Bearing for Precision Tasks?

W 608-2Z Bearing is crafted with stainless steel rings and balls, offering excellent corrosion resistance and durability.
Its shielded design keeps contaminants out while retaining lubrication for smooth operation.

The bearing handles dynamic radial loads up to 447 lbf, making it suitable for precision applications.
With a maximum speed of 38,000 rpm, it ensures efficient performance in high-speed scenarios.

W 608-2Z Bearing’s compact size (8 mm×22 mm×7 mm) allows for easy integration into various machinery.
Its stainless steel construction ensures reliability even in demanding environments.

Application

Practical Applications of W 608-2Z Bearing
W 608-2Z Bearing is commonly used in small electric motors, such as those found in household appliances like blenders and fans. Its stainless steel construction ensures resistance to rust, making it ideal for damp environments.

How Does W 608-2Z Bearing Improve Performance?
In automation systems, W 608-2Z Bearing provides smooth rotation for components like conveyor belts and robotic arms. The shielded design helps keep contaminants out, extending the bearing’s lifespan.

Ideal for Precision: W 608-2Z Bearing
Medical devices, such as dental drills and lab equipment, benefit from W 608-2Z Bearing’s reliable performance. Its compact size and low friction make it suitable for high-precision applications.

Light-Duty vs Heavy-Duty: Best Uses for W 608-2Z Bearing
For light-duty tasks like office printers, W 608-2Z Bearing ensures quiet operation and minimal maintenance. In contrast, it also handles moderate loads in industrial settings like packaging machines.

Where Is W 608-2Z Bearing Used?
You’ll often find W 608-2Z Bearing in bicycle hubs, where its durability and smooth rotation enhance riding comfort. The grease lubrication reduces wear, even during long rides.
