Stainless Steel Deep Groove Ball Bearings W 607-2RS1/VT378

Stainless Steel Deep Groove Ball Bearings W 607-2RS1/VT378

The W 607-2RS1/VT378 is a compact stainless steel deep groove ball bearing, measuring 7mm by 19mm by 6mm. It handles radial loads up to 344 lbf and spins smoothly at speeds up to 56,000 RPM.

Its sealed design keeps dirt out and lubrication in, making it low-maintenance. The stainless steel construction resists corrosion, ideal for damp or harsh environments.

This bearing fits applications like small motors, fans, or medical devices where reliability is key. It’s interchangeable with SKF models for easy replacement.

Weighing just 6.7 grams, it’s lightweight yet durable. Suitable for temperatures from -30°C to 120°C, it’s a versatile choice for various industries.

Get A Free Quote
    Description Features Application Q&A Featured Products Our Process

Product Parameters

  • Part Number W 607-2RS1/VT378
  • Brand TFL
  • Interchangeable SKF
  • Bore Dia 7 mm
  • Bore Dia Tolerance -0.008mm to 0
  • Outer Dia 19 mm
  • Outer Dia Tolerance -0.009mm to 0
  • Width 6 mm
  • Width Tolerance -0.12mm to 0
  • System of Measurement Metric
  • Bearing Type Ball
  • For Load Direction Radial
  • Construction Single Row
  • Seal Type Sealed
  • Tolerance Class ABEC 1 | ISO P0
  • Radial Clearance Trade No CN
  • Ring Material Stainless Steel
  • Ball Material Stainless Steel
  • Cage Material Chrome Steel
  • Dynamic Radial Load 344 lbf
  • Static Radial Load 132 lbf
  • Temperature Range -30°to 120 °C
  • REACH Compliant
  • Max Speed 56000 rpm
  • Weight 0.0067 kg
Stainless Steel Deep Groove Ball Bearings W 607-2RS1/VT378 dimension drawing
Download DWG Download PDF

Features

Why Choose W 607-2RS1/VT378 Bearing for Precision Tasks?

W 607-2RS1/VT378 Bearing is crafted with stainless steel rings and balls, offering excellent corrosion resistance.
Its sealed design protects against dust and moisture, ensuring reliable performance in various environments.
With a dynamic radial load capacity of 344 lbf, it handles demanding radial loads efficiently.
The bearing’s ABEC 1 tolerance class ensures consistent precision for smooth operation.

Application

Common Applications of W 607-2RS1/VT378 Bearing
W 607-2RS1/VT378 Bearing works well in small electric motors, such as those found in household appliances like blenders or fans. Its sealed design keeps out dust and moisture, ensuring longer service life in everyday use.

How Does W 607-2RS1/VT378 Bearing Improve Performance?
In automation equipment, W 607-2RS1/VT378 Bearing reduces friction in rotating parts, helping machinery run more smoothly. The stainless steel construction also resists corrosion, making it suitable for humid environments.

Built for Versatility: W 607-2RS1/VT378 Bearing
This bearing fits nicely into medical devices like dental tools, where its compact size and reliable performance are valued. The ABEC 1 tolerance ensures consistent operation without being overly precise for general applications.

Light-Duty vs Heavy-Duty: Best Uses for W 607-2RS1/VT378 Bearing
For light loads, W 607-2RS1/VT378 Bearing is ideal in office equipment like printers or scanners. Its 56,000 rpm limit handles high-speed tasks easily, while the radial load capacity suits smaller mechanisms.

Where Is W 607-2RS1/VT378 Bearing Used?
You’ll often find W 607-2RS1/VT378 Bearing in hobbyist projects, such as RC cars or DIY gadgets. The metric sizing and stainless steel materials make it a go-to for makers who need durable, small-scale components.
