Stainless Steel Deep Groove Ball Bearings W 606

Stainless Steel Deep Groove Ball Bearings W 606

The W 606 is a compact stainless steel deep groove ball bearing, measuring 6mm by 17mm by 6mm. It handles radial loads up to 438 lbf and spins smoothly at speeds up to 60,000 RPM.

Made entirely from stainless steel, it resists corrosion and works in temperatures from -30°C to 120°C. Its open design allows for easy lubrication when needed.

This bearing is interchangeable with SKF models, making replacements straightforward. Ideal for small machinery, medical devices, or food processing equipment where hygiene matters.

Weighing just 5.4 grams, it’s lightweight yet durable. Compliant with RoHS and REACH standards for safe use in various industries.

Get A Free Quote
    Description Features Application Q&A Featured Products Our Process

Product Parameters

  • Part Number W 606
  • Brand TFL
  • Interchangeable SKF
  • Bore Dia 6 mm
  • Bore Dia Tolerance -0.008mm to 0
  • Outer Dia 17 mm
  • Outer Dia Tolerance -0.008mm to 0
  • Width 6 mm
  • Width Tolerance -0.12mm to 0
  • System of Measurement Metric
  • Bearing Type Ball
  • For Load Direction Radial
  • Construction Single Row
  • Seal Type Open
  • Tolerance Class P0
  • Radial Clearance Trade No CN
  • Ring Material Stainless Steel
  • Ball Material Stainless Steel
  • Cage Material Stainless Steel
  • Dynamic Radial Load 438 lbf
  • Static Radial Load 187 lbf
  • Temperature Range -30° to 120 °C
  • RoHS Compliant
  • REACH Compliant
  • Max Speed 60000 rpm
  • Weight 0.0054 kg
Stainless Steel Deep Groove Ball Bearings W 606 dimension drawing
Download DWG Download PDF

Features

Why Choose W 606 Bearing for Precision Tasks?

W 606 Bearing is crafted from stainless steel, offering excellent resistance to corrosion and wear.

Its compact size of 6 mm×17 mm×6 mm makes it ideal for applications where space is limited.

With a dynamic radial load capacity of 438 lbf, it handles demanding radial loads efficiently.

The open design ensures easy maintenance, while the P0 tolerance class guarantees precision performance.

Application

Common Applications of W 606 Bearing
W 606 Bearing is widely used in small electric motors, such as those found in household appliances like blenders and fans. Its stainless steel construction ensures resistance to rust, making it ideal for damp environments.

In industrial settings, W 606 Bearing fits well in light machinery where space is limited but reliability is key. The open design allows for easy lubrication, extending its service life in continuous operation.

For medical devices, W 606 Bearing’s smooth operation is perfect for precision instruments like dental drills. The P0 tolerance class ensures consistent performance, crucial for sensitive applications.

Automotive applications include small components like window regulators, where W 606 Bearing’s compact size and durability shine. Its metric dimensions make it a versatile choice for various vehicle models.
