Stainless Steel Deep Groove Ball Bearings W 6006-2RS1/W64F

The W 6006-2RS1/W64F is a stainless steel deep groove ball bearing with a 30mm bore and 55mm outer diameter, measuring 13mm wide. Its sealed design keeps dirt out and solid oil lubrication ensures smooth operation.

This bearing handles radial loads up to 2563 lbf and can spin at speeds up to 17000 RPM. Made entirely from stainless steel, it resists corrosion and works in temperatures from -30°C to 120°C.

The chrome steel cage provides durability, while the ABEC 1 precision rating offers reliable performance. It’s interchangeable with SKF bearings for easy replacement.

Ideal for food processing equipment or marine applications where rust resistance is important. Weighing just 0.1kg, it’s a lightweight solution for radial load situations. Compliant with REACH standards.

Get A Free Quote

Description

Features

Application

Q&A

Product Parameters

Part Number W 6006-2RS1/W64F
Brand TFL
Interchangeable SKF
Bore Dia 30 mm
Bore Dia Tolerance -0.01mm to 0
Outer Dia 55 mm
Outer Dia Tolerance -0.013mm to 0
Width 13 mm
Width Tolerance -0.12mm to 0
System of Measurement Metric
Bearing Type Ball
For Load Direction Radial
Construction Single Row
Seal Type Sealed
Tolerance Class ABEC 1 | ISO P0
Radial Clearance Trade No CN
Ring Material Stainless Steel
Ball Material Stainless Steel
Cage Material Chrome Steel
Dynamic Radial Load 2563 lbf
Static Radial Load 1832 lbf
Temperature Range -30°to 120 °C
Lubrication Soild Oil
REACH Compliant
Max Speed 17000 rpm
Weight 0.1 kg
Price（$） 31.75

Stainless Steel Deep Groove Ball Bearings W 6006-2RS1/W64F dimension drawing

Download DWG Download PDF

Features

How Does W 6006-2RS1/W64F Bearing Reduce Friction?

W 6006-2RS1/W64F Bearing features stainless steel rings and balls, designed to minimise friction during operation.
Its solid oil lubrication ensures smooth performance, even at high speeds up to 17,000 rpm.

The sealed design of W 6006-2RS1/W64F Bearing keeps contaminants out, reducing wear and maintenance needs.
With a dynamic radial load capacity of 2563 lbf, it handles demanding radial loads reliably.

W 6006-2RS1/W64F Bearing operates efficiently in temperatures ranging from -30°C to 120°C.
Its stainless steel construction offers excellent corrosion resistance, ideal for harsh environments.

Application

Industrial Uses of W 6006-2RS1/W64F Bearing
W 6006-2RS1/W64F Bearing is commonly used in food processing equipment, where its stainless steel construction resists corrosion from frequent washdowns. The sealed design also keeps contaminants out, ensuring smooth operation in demanding environments.

In automotive applications, W 6006-2RS1/W64F Bearing fits well in electric motors and pumps, thanks to its radial load capacity and solid oil lubrication. Its metric sizing makes it a versatile choice for various vehicle models.

For home appliances like washing machines, W 6006-2RS1/W64F Bearing provides reliable performance with minimal maintenance. The sealed feature helps prolong its lifespan, even with constant use.

Where Is W 6006-2RS1/W64F Bearing Used?
You’ll often find W 6006-2RS1/W64F Bearing in conveyor systems, where its durability handles continuous movement effortlessly. The stainless steel material also makes it suitable for humid or wet conditions.

In medical devices, W 6006-2RS1/W64F Bearing ensures quiet and smooth operation, ideal for diagnostic equipment. Its solid oil lubrication reduces friction, enhancing precision in sensitive applications.

Built for Versatility: W 6006-2RS1/W64F Bearing
W 6006-2RS1/W64F Bearing works well in both light industrial and consumer applications, from small machinery to power tools. Its balanced design offers consistent performance across different uses.

The sealed construction of W 6006-2RS1/W64F Bearing makes it a good fit for outdoor equipment, where dust and moisture are common. Stainless steel components add extra resistance to rust and wear.

Light-Duty vs Heavy-Duty: Best Uses for W 6006-2RS1/W64F Bearing
For light-duty tasks like office printers, W 6006-2RS1/W64F Bearing ensures quiet and efficient operation. Its compact size fits neatly into smaller devices without compromising reliability.

In heavier industrial settings, W 6006-2RS1/W64F Bearing handles radial loads in machinery like compressors. The solid oil lubrication keeps it running smoothly even under prolonged stress.
